Metal Garden Display Shed
OWNER'S MANUAL /
Instructions for Assembly
Size 10 Ft x 2 Ft
• Tall Walk in Shed
• Quick & Easy Assembly
• Ridge Reinforced Walls
• Wide Double Doors
• Available in Various Sizes
S H E D S
Requires two people and takes 2-3 hours for Installation.
Customer
Service Hotline
(800) 483-4674
www.uspolymersinc.com
Call us for any missing or damaged parts.
Do not return to the store.

Advertisement

loading

Related Manuals for USP Duramax

Summary of Contents for USP Duramax

  • Page 1 A L L P U R P O S E M E T A L S T O R A G E S H E D S Metal Garden Display Shed OWNER’S MANUAL / Instructions for Assembly Size 10 Ft x 2 Ft Customer Service Hotline (800) 483-4674...

  • Page 2: Limits And Exclusions

    Duramax Storage Shed Limited Fifteen Year Warranty U.S. Polymer Inc. will send a replacement part free of charge, in the event of material defects and or workmanship for a period of fifteen years from the date of purchase. This warranty is extended only to the original purchaser. A purchase receipt or other proof of date of original purchase will be required before warranty service is rendered.

  • Page 3: Parts List

    Parts List PROFILES Note: Check all parts prior to installation. ACCESSORIES CODE DESCRIPTION CODE DESCRIPTION BASE BAR BACK LEFT BASE BAR BACK RIGHT BOTTOM SLIDER BASE BAR TOP ANGLE BACK BS2S BASE BAR SIDE LEFT / RIGHT (BLA, BRA, BS2S) (ABLA, ABRA) DOOR HANDLE BASE BAR...

  • Page 4: Exploded View

    Exploded View RFTS RF1A RF2A RF2A RF1A GPRA SB1A SB2A GPLA GPLA SB2A SB1A GPRA AS1S ABLA WCFS ABRA AS1S BS2S WCFS BS2S Left Door Right Door IMPORTANT: USE HAND GLOVES TO PREVENT INJURY.

  • Page 5: Parts Needed

    Pressure Treated - Wood Studs: DuraMax must be installed on a level wooden platform 2ea 2” x 4” x 125” (50mm x 88.9mm x 3175 mm) or a level concrete foundation. 5ea 2” x 4” x 16” (50mm x 88.9mm x 406.4 mm) Exterior Grade (CDX) - 3/4”...
  • Page 6 . Assemble base bar back left (BLA) and base bar back right (BRA) with four (S1) screws. See fig. 1 & 2. Note Take care of sharp edges. 1&2 Fig.1 Fig.2 . Place the base bar assembly on top of the foundation.
  • Page 7 . Using a carpenter square, line up the corners. Secure base bar side assembly to the foundation with (S2) screws. BS2S BS2S BS2S BS2S Fig.1 Fig.2 . Place the base bar (BBF) on top of the base bar side on both side. Secure with (S1) screws on 1&2 both corners.
  • Page 8 . Place the entrance taper channel (ECA) on top of the (BBF). Secure with (S2) screws to the foundation. See fig. 1 & 2. 1 & 2 Fig.1 Fig.2 . Measure in all direction as shown in figure. Make the base bar assembly in a perfect square. Concrete foundation .
  • Page 9 . Place the wall panel (WFR) on the base bar (BBF) front right side of the shed. Line up the holes with base bar. Secure with (S1) screws with washers from outside. Fig.1 . Place the wall panel corner left &right (WCFS) on the base bar (BS2S).
  • Page 10 . Place the sliding channel right (SRA) on top of the wall panel (WFR) from inside. See the position in fig.1. Line up the holes with wall panel. Use (S1) screws with washers to fix. See fig. 2 . 1&2 WCFS WCFS Fig.1...
  • Page 11 . Place the wall panel corner left & right (WCFS) on the base bar (BS2S). Line up the holes with base bar and use (S1) screws with washers to secure. Make sure the overlapping Note WCFS position is as shown in fig.1 BS2S WCFS Fig.2...
  • Page 12 . Insert two pieces of (TS) Top slider into the sliding channel. See blowup. Make sure the position of Note the projection on top slider towards inside. Front Fig.1 . Place the sliding channel support (SSA) in between the sliding Channels (SLA)& (SRA). Align the holes with sliding channel and secure with (S1) screws.
  • Page 13 . Place the top angle back left (ABLA) on top of the wall panel (WS) from inside. See the position ABLA in fig.1. Line up the holes with wall panel. Use (S1) screws with washers to fix. See fig. 2. 1 &...
  • Page 14 . Place the wall panel (WS) on the base bar (BRA). Line up the holes with the base bar and use (S1) screws with washers to secure. See fig. 2. Use (S3) nut and bolt with washer to join together the middle of the wall panel.
  • Page 15 . Place the top angle side (AS1S) on top of the wall panel (WCFS) from inside. Line up the holes with wall panel and secure with (S1) screws with washers. Top angle (AS1S) must slide Note 2 & 3 AS1S in between the sliding channel (SRA) and the wall panel (WCFS).
  • Page 16 . Follow the same way as item No. 20. Make sure the overlapping Note position is as shown in fig.1 & 2. Fig.2 Fig.1 Fig.3 . Place the left door column (DCL) on top of the base bar (BBF) and insert into the wall panel. See blowup.
  • Page 17 . Place the sliding channel cover (SCA) on top of the sliding support (SRA) and secure with (S1) screws. Fig.1 . Place the sliding channel cover (SCA) on top of the sliding support (SLA) and secure with (S1) screws. Fig.1 IMPORTANT: USE HAND GLOVES TO PREVENT INJURY.
  • Page 18 C. Roof Note All parts are clearly marked and care should be taken to use the correct one. Parts Needed: Roof flashing front right / back left (RF1A) (2) Gable panel left (GPLA) Roof flashing front left / back right (RF2A) (2) Gable panel right (GPRA)
  • Page 19 . Assemble the Gable panel (GPLA) & (GPRA) together with gable panel support (GPS) with (S3) GPLA bolt and nut. See fig1&2 . Fix.the (GPS) to the sliding channel (SLA) & (SRA) with (S1)screws.See fig 3. GPLA GPLA GPRA GPRA GPRA 1,2&...
  • Page 20 . Fix roof support brackets (SB1A) & (SB2A) on both ends of Roof Structure (RSS) with (S3) bolt & nut. See fig.Make two sets. SB1A SB2A . Assemble two roof structure(RSS) together with (S3) bolt and nut. See blowup. . Fix the roof structure one end with roof support bracket to the gable panel using (S3) bolt and nut.
  • Page 21 . Insert the one end of the roof structure assembly 1 & 2 to the Gable panel. The Gable panel should go in between roof structure assembly. Secure with (S3) bolt and nut. Continue the same for other end. 1 & 2 Make sure the taper side Note on roof structure must...
  • Page 22 . Place the roof panel (RPS) on top of Gable panel and roof structure. Line up the holes with Gable panel and secure with (S3) bolt and nut with washers. . Line up the holes with roof structure and top angle side and secure with (S1) screws with washers.
  • Page 23 . Assemble the roof flashing (RF1A) and (RF2A) RF2A RF1A with roof panel as shown in fig. Use (S1) screws with washers to secure. RF2A RF1A . Place the roof flashing top on top of the roof panel. Line up the holes and secure with (S1) screws with washers.
  • Page 24 . Place the roof flashing side (RFSS) and top corner RFSS 2&3 (TC) on the roof flashing joint and secure with (S2) screws. 1&3 RFSS RFSS RFSS 1&3 RF2A RF1A 2&3 Fig.1 Fig.2 Fig.3 . Insert the ventilation cover (VC) into the front Gable panel and secure with (S1) screws.
  • Page 25 the weather stripping tape till the end of roof panel. . Insert the ventilation cover (VC) into the back Gable panel and secure with (S1) screws. Back Fig.1 IMPORTANT: USE HAND GLOVES TO PREVENT INJURY.

  • Page 26: Right Door

    D. Door Parts Needed: (1) Door panel left (DPL1A) (1) Door panel left (DPL2A) (1) Door panel right (DPR1A) (1) Door panel left (DPR2A) (2) Door panel strips side left and right (DSS) (1) Door panel strip top left (TSLA) (1) Door panel strip top right (TSRA) (1) Door panel strip bottom left...
  • Page 27 Right Door Assembly 1 & 2 . Assemble the door panel (DPR1A) & (DPR2A) together with (S3) bolt and nut from inside. Note Remove the Polyethylene Film before assembling. DPR1A DPR2A DPR1A DPR2A Fig.2 Fig.1 Fix the door handle (DH) with door panel from front side with bolt and nut.
  • Page 28 . Assemble the door panel strip center (DSCRA) to the door panel from inside. Use (S1) and (S3) bolt and nut with washers. DPR2A DPR1A DPR2A DSCRA DSCRA DSCRA DPR2A DPR1A DPR1A DPR2A Step #3 Step #2 Step #5 Fig.3 Fig.1 DPR1A DPR1A...
  • Page 29 . Assemble the door panel strip (TSRA) with door panel. Make sure the door panel top edge to be inserted into the (TSRA). See fig.1. TSRA Secure the (TSRA) with (DSS) and door panel with (S1) screws. See fig. 2. 1&2 Use (S3) bolt and nut with washers to secure with door panel at the middle of (TSRA).
  • Page 30 Left Door Assembly 1 & 2 . Assemble the door panel (DPL1A) & (DPL2A) together with (S3) bolt and nut from inside. Note Remove the Polyethylene Film before assembling. DPL2A DPL1A DPL1A DPL2A Fig.1 Fig.2 Fix the door handle (DH) with door panel from front side with bolt and nut.
  • Page 31 . Assemble the door panel strip center (DSCLA) to the door panel from inside. Use (S1) and (S3) bolt and nut with washers. DPL2A DPL2A DPL1A DSCLA DSCLA DSCLA DPL2A DPL1A DPL2A DPL1A Step #3 Step #5 Step #2 Fig.3 Fig.1 DPL1A DPL1A...
  • Page 32 . Assemble the door panel strip (TSLA) with door Fig.3 panel. Make sure the door panel top edge to be TSLA inserted into the (TSLA). See fig.1. Secure the (TSLA) with (DSS) and door panel with Fig.1&2 (S1) screws. See fig. 2. Use (S3) bolt and nut with washers to secure with door panel at the middle of (TSLA).
  • Page 33 . Slide the door panel assembly into the base bar front (BBF). Make sure the bottom slider (BS) should slide inside the base bar front. See fig.1. Fix the door panel top to the top slider (TS) with (S1) screws. See fig.2 & 3 Fig.1 Fig.2 Door Panel...
