5. Verify that the T/R speed is set to 9600 by pressing SET and then 1.
•
Figure 5 appears with 9600 blinking. To change the option, press the SET
or ( - ) button until desired option is blinking. Select the blinking option by
pressing JOB.
T/R speed
Select
SET or -
6. Verify that the Device Maker is set to AUTO by pressing JOB, SET, 1, and 0.
•
Figure 6 appears with AUTO blinking. To change the option, press the
SET or ( - ) button until desired option is blinking. Select the blinking
option by pressing JOB. In approximately 10 seconds, the screen will
change to: Device Item No. > with options 0 – 3. At this time, press
JOB.
Device
Maker
Select
SET or -
7. Verify that the Check sum is set to Normal by pressing JOB and then 7.
•
Figure 7 appears with Normal blinking. To change the option, press the
SET or ( - ) button until desired option is blinking. Select the blinking
option by pressing JOB. If the screen displays "Device error," ignore this
message and continue.
Check sum
Select
SET or -
8. Verify that the Margn chk is set to Enable by pressing JOB, SET, and 3.
•
Figure 8 appears with Enable blinking. To change the option, press the
SET or ( - ) button until desired option is blinking. Select the blinking
option by pressing JOB.
Margn chk
Select
SET or -
3
firealarmresources.com
75
19200
> 9600
4800
Figure 5
ATMEL
AMD
> AUTO
XICOR
Figure 6
Reverse
> Normal
Figure 7
Disable
> Enable
Figure 8
