Introduction
Overview
The 4100 Programmer software does not support the Aval PKW1100 PROM Burner. This
publication will show you how to manually download software to the PROM burner and then
show you how to burn the PROMs.
•
Requirements
•
•
•
In this Publication
This publication discusses the following topics:
Setup
COM Port
At the C:\> prompt, type mode com1: 9600,n,8,1 to set up the correct communications
parameters for COM1.
PROM Burner
Connect one end of the download cable to COM1 on the 4100 Programming Unit and connect the
other end to the RS-232 port of the PROM burner.
Follows Steps 1 through 9 to verify the setup on the PROM burner. Figures 1 through 9 represent
screens displayed on the PROM burner's LCD.
NOTE: Actual screen information may differ from illustrations.
1.
2001 Simplex Time Recorder Co., Westminster, MA 01441 USA
All specifications and other information shown were current as of publication, and are subject to change without notice.
4100 Programming Unit with appropriate software.
Available communications port configured as COM1.
RS-232 Null Modem Cable.
Aval PWK1100 PROM Burner.
Introduction
Setup
Download
Turn the PROM burner ON.
•
Unit beeps and Figure 1 appears.
AUTO
Command >
Menu:
firealarmresources.com
Aval PKW1100 PROM Burner
Topic
A11
AUTO
[9] - [F]
Figure 1
User's Guide
See Page #
1
1
4
579-317
Rev. A
Advertisement
Table of Contents
Related Manuals for Simplex Aval PKW1100
Summary of Contents for Simplex Aval PKW1100
- Page 1 User’s Guide Introduction Overview The 4100 Programmer software does not support the Aval PKW1100 PROM Burner. This publication will show you how to manually download software to the PROM burner and then show you how to burn the PROMs. •...
- Page 2 Verify that the Bit Form selection is set to D8, S1, No by pressing SET and then 0. • Figure 2 appears with D8, S1, No blinking. To change the option, press the SET or ( - ) button until desired option is blinking. Select the blinking option by pressing JOB.
- Page 3 Verify that the T/R speed is set to 9600 by pressing SET and then 1. • Figure 5 appears with 9600 blinking. To change the option, press the SET or ( - ) button until desired option is blinking. Select the blinking option by pressing JOB.
- Page 4 Verify that the Word type is set to Even-Low by pressing JOB, SET, and 8. • Figure 9 appears with Even-Low blinking. To change the option, press the SET or ( - ) button until desired option is blinking. Select the blinking option by pressing JOB.
- Page 5 Set prog Even Select > All SET or - Series Figure 12 15. Set the PROM burner for serial download by pressing JOB, D, 0, and SET. • Figure 13 appears. RS recv Motorola 00000000 * Receiving… 9600 D8 S1 No Figure 13 16.
- Page 6 Clear finished AUTO AUTO Command > Menu: [9] - [F] Figure 16 21. Invert the PROM burner by pressing JOB, B, and SET. • Figure 17 appears. Invert finished AUTO AUTO Command > Menu: [9] - [F] Figure 17 22. Select the All option by pressing JOB, SET, and 2. This selection is used to burn the 4020 and 4100 Executive software.
- Page 7 25. Set the PROM burner for serial download by pressing JOB, D, 0, and SET. 26. At the DOS prompt C:\4100Px> (where x represents the software version), type the following: • type msglib.mot>com1: and then press Enter to download this file to the PROM burner.
- Page 8 32. Select the Word option by pressing JOB, SET, and 2. This selection is used to burn 4100+/UT Executive software. • Figure 24 appears with Word blinking. To change the option, press the SET or ( - ) button until desired option is blinking. Select the blinking option by pressing JOB.
