Simplex 4100-5124 Installation Instructions

Class a adapter card

This publication describes the installation procedure for the 4100-5124 Class A Adapter Card.

Introduction

This card mounts to a TrueAlert Power Supply (TPS) and converts the three standard Class B

Signaling Line Circuits (SLCs) on the TPS to Class A SLCs.

Refer to the 4100-5120/5121/5124 TrueAlert Power Supply Installation Instructions (579-336) for

information on installing the TPS and wiring Class A SLCs.

Inspecting Contents

Upon unpacking your Simplex product, inspect the contents of the carton for shipping damage. If

of Shipment

damage is apparent, immediately file a claim with the carrier and notify Simplex.

In this Publication

This publication discusses the following topics:

Specifications and other information shown were current as of publication and are subject to change without notice.

Simplex and the Simplex logo are trademarks of Tyco International Ltd. and its affiliates and are used under license.

Cautions and Warnings

Mounting to the TPS

firealarmresources.com

4100-5124 Class A Adapter Card

Installation Instructions

Topic

See Page #

579-337

Rev. B

Table of Contents

Need help?

Do you have a question about the 4100-5124 and is the answer not in the manual?

Page 1 Specifications and other information shown were current as of publication and are subject to change without notice. 579-337 Simplex and the Simplex logo are trademarks of Tyco International Ltd. and its affiliates and are used under license. Rev. B firealarmresources.com...
Page 2 DO NOT INSTALL ANY SIMPLEX® PRODUCT THAT APPEARS DAMAGED - Upon unpacking your Simplex product, inspect the contents of the carton for shipping damage. If damage is apparent, immediately file a claim with the carrier and notify an authorized Simplex product supplier.
Page 3 Mounting to the TPS Procedure The 4100-5124 Class A Adapter Card mounts to the TPS using four hex standoffs. The standoffs have threaded male and female ends. Follow these steps to mount the Class A Adapter Card. 1. Remove the two Torx screws shown in Figure 1. The holes in which the screws were installed are used for the Class A board standoffs.
Page 4 579-337 Rev. B firealarmresources.com...
