Press
parameters are described as follows.
No.
1
2
3
4
5
6
7
8
9
10
11
Set the power on mode to the OPP test mode:
1.
2.
3.
4.

3.10.4 Battery Discharge Test

IT8500G+ series electronic load supports the discharge test function of the
battery in CC/CW/CR mode.
Reach the set cutoff power.
The measured power supply voltage is less than the OPP voltage setting
value.
(Shift)+CW(OPP) to enter the OPP operation page, and the related
Parameter
VON LEVEL=0.000V
VON DELAY=0.1S
RANGE=5A
START =0.01W
STEP =1.00W
STEP DEL=0.1S
END =12.00W
OPP VOLT=7V
MAX TRIP =6.50W
MIN TRIP =5.60W
SAVE OPP FILE=1
Press (Shift)+
0.0000V 0.000A
POWER-ON BUZZER
Press key, select RUNMODE and confirm with
0.0000V 0.000A
RUN NORMAL
Press , select OPP_TEST , press
The VFD displays the OPP test page.
0.0000V 0.000A
STOP 0.00W
After above steps, press
test.
Trigger it again, the machine will stop the current running state and display
stop..
Note
To exit the OPP mode, you can press the [Shift]+ [8] (System) buttons
to enter the system menu and set the RUNMODE to NORMAL.
Copyright © Itech Electronic Co., Ltd.
Description
Set the Von voltage value.
Set the Von voltage delay time. After
delay certain time, the DC load starts
to draw power.
Set the working current range.
Set the initial power.
Set the step power.
Set delay time of each step.
Set the cutoff power.
Set the OPP voltage.
Upper limit of OPP value.
Lower limit of OPP value
Save OPP test file (1-10)
(System) to enter into system menu.
(Shift) (Trigger) To trigger the OPP function
+
Functions and Characteristics
.
to confirm.
