Indicates the load level by 0-24%, 25-49%, 50-74% and 75-100%.
Indicates overload.
Programmable outlets information
Indicates that programmable management outlets are working.
Mode operation information
Indicates the UPS connects to the mains.
Indicates the battery is working.
Indicates charging status
Indicates the bypass circuit is working.
Indicates the ECO mode is enabled.
Indicates the AC to DC circuit is working.
Indicates the PFC circuit is working.
Indicates the inverter circuit is working.
Indicates the UPS is working in converter mode.
Indicates the output is working.
Battery information
Indicates the battery level by 0-24%, 25-49%, 50-74%, and 75-100%.
Indicates low battery.

3.3 Audible Alarm

Battery Mode
Low Battery
Overload
Fault
Bypass Mode

3.4 LCD display wording index

Abbreviation Display content
ENA
DIS
ESC
HLS
LLS
Sounds every 5 seconds
Sounds every 2 seconds
Sounds every second
Continuously sounding
Sounds every 10 seconds
Meaning
Enable
Disable
Escape
High loss
Low loss
