4.2 LEDs..........................7 5 Installation..........................8 5.1 Precautions........................8 5.2 Mounting options......................8 6 Operation..........................9 6.1 Configure and install the optimyze sensors..............9 6.2 Set up optimyze Gateway....................9 6.3 Unpairing........................9 7 Troubleshooting......................... 10 7.1 Symptoms and remedies.....................10 8 Technical Specification...................... 11 8.1 Dimensions........................11...
Page 4
Table of Contents 11 Certifications........................17 11.1 For U.S........................17 11.2 For Canada (ISED)....................18 11.3 UK (UKCA)........................ 18 11.4 EU Regulatory......................18 ™ optimyze Gateway Instruction, Operation, and Maintenance Manual...
This includes any modification to the equipment or use of parts not provided by Xylem. If there is a question regarding the intended use of the equipment, please contact a Xylem representative before proceeding.
Only use the manufacturer’s original spare parts to replace any worn or faulty components. The use of unsuitable spare parts may cause malfunctions, damage, and injuries as well as void the warranty. ™ optimyze Gateway Instruction, Operation, and Maintenance Manual...
The product must be stored in a covered and dry location free from heat, dirt, and vibrations. NOTICE: Protect the product against humidity, heat sources, and mechanical damage. NOTICE: Do not place heavy weights on the packed product. ™ optimyze Gateway Instruction, Operation, and Maintenance Manual...
Once set up and paired, the Gateway will automatically connect to the sensors every 24 hours to collect asset health data. The data will then be securely sent to the xylem cloud over low-power LTE-M, allowing users to access the latest information about their ®...
4. Bluetooth Button 5. USB Power Connector 6. Power Switch 4.2 LEDs The LEDs are used to show different status information of the optimyze Gateway: • Bluetooth status • LTE cellular status • Xylem Cloud server connection status The LED statuses are shown below:...
For optimal performance, external antennas should be positioned vertically, tip pointing up, perpendicular to the ground regardless of mounting surface orientation. Precaution To avoid damage, be sure to use appropriate anchors and screws when mounting on vertical surfaces. ™ optimyze Gateway Instruction, Operation, and Maintenance Manual...
Power switch. 3. Turn on Gateway with the 4. The Gateway will connect to the cellular network and xylem cloud. Note that this could take a few minutes. Once it successfully connects, the red LED goes from blinking to a solid red state and green LED will also turn on.
Gateway because of lacking network coverage. optimyze sensor is in • optimyze sensor may not be in 1. Move Gateway closer to configuration mode and Gateway pairing range. sensors.
AC line power requirements • Voltage input: 90 VAC ~ 264 VAC 8.5 Wireless communication Feature Value Bluetooth Bluetooth Low Energy Secure Connections 4.2 Cellular • Multi-Band cellular operation for world-wide operation • Category LTE-M ™ optimyze Gateway Instruction, Operation, and Maintenance Manual...
Weight for Gateway boxed kit (without power 0.518 lbs (0.24 kg) supply) Weight for Power Supply 0.300 lbs (0.14 kg) 8.7 Part numbers Part Part number optimyze Gateway w/USB cable P2007065 Power supply P2007067 ™ optimyze Gateway Instruction, Operation, and Maintenance Manual...
EXEMPLARY OR SPECIAL DAMAGES, INCLUDING BUT NOT LIMITED TO LOSS OF PROFIT, LOSS OF ANTICIPATED SAVINGS OR REVENUE, LOSS OF INCOME, LOSS OF BUSINESS, LOSS OF PRODUCTION, LOSS OF OPPORTUNITY OR LOSS OF REPUTATION. ™ optimyze Gateway Instruction, Operation, and Maintenance Manual...
This section reviews security features and provides guidance to help securely operate this product. For details and updates on Xylem product https://www.xylem.com/en-us/about-xylem/cybersecurity/ cybersecurity visit 10.1 Xylem Product Cybersecurity...
Page 17
Ensure Magnet Key is removed Protections, such as the magnet NIST SP 800-53 Rev5: AC-18 after putting the optimyze sensor key, are put in place to make ISA/IEC 62443-4-2: CR 4.1, NDR in Configuration Mode so that the pairing deliberate and to require device does not re-enter physical proximity to the device.
Page 18
10 Cybersecurity https://collaborate.mitre.org/attackics/index.php/ 1. ATT&CK for ICS available online: Mitigations https://nvlpubs.nist.gov/nistpubs/ 2. NIST SP 800-53 Rev 5 available online: SpecialPublications/NIST.SP.800-53r5.pdf 3. ISA/IEC 62443 standards available for purchase from ISA, IEC, or ANSI. ™ optimyze Gateway Instruction, Operation, and Maintenance Manual...
Page 19
™ The Pinnacle 100 is fully approved for mobile and portable applications. CAUTION: Any changes or modifications not expressly approved by Xylem Inc. could void the user’s authority to operate the equipment. Federal Communication Commission Interference Statement This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules.
Page 20
• 2014/53/EU – Radio Equipment Directive (RED) • 2015/863/EU - RoHS Directive (RoHS 3) A “Declaration of Conformity” in accordance with the applicable directives, standards, and documentation/regulatory-information- regulations has been made and is on file under mg100 ™ optimyze Gateway Instruction, Operation, and Maintenance Manual...
Page 24
For more information on how Xylem can help you, go to www.xylem.com Visit our Web site for the latest version of this document and more information The original instruction is in English.
