- Page 1 Owner Manual Winton Hole Borer WHB Series IMPORTANT: Read all instructions before using this attachment...
- Page 2 Congratulations on the purchase of your new attachment! Before you get started, we have provided a helpful space to jot down a few important details: Model number: WHB Serial number: Date of purchase: Factory reference: HMD-L This manual should be considered a permanent part of this attachment and therefore should remain with it even if the attachment is subsequently sold.
-
Page 3: Safety Information
Safety Information Before installation/maintenance, ensure tractor and attachment are stationary with the hydraulic lift system in a neutral position, and the ignition key removed. Read and understand this manual before operating any machinery to avoid equipment damage. Failure to follow all safety standards can result in severe injury or death. Regularly check condition and service of your attachment. - Page 4 Safety Information (Continued) Attachment Pre-use Checks Upon receipt of your new attachment and again within the first 4 hours of use (the ‘shake in’ period), we recommend the following: Check/tighten all bolts, nuts and screws (and those securing blades). Check the tension of any belt(s), and adjust if required. Apply grease to grease points if necessary.
-
Page 5: Table Of Contents
Safety Information………………………………………………………………………..page 3-4 Specifications…………………………………………………………………………………..page 6 Installation………….………………………………………………………………………..page 7-9 Operating Instructions…………………………………………………………………..page 10 Auger Blade & Tip Replacement…………………………………………………….page 11 Gear Oil Change & Check………...…………………………………………………….page 12 Servicing & Maintenance………………………………………………………………..page 13 Parts Diagram & List………………………………………………………………….Page 14-15 Attaching & Resizing PTO Shaft………………………………………………………page 16 Winton Product Warranty……………………………………………………………...page 17... -
Page 6: Specifications
Specifications Model WHB Unit WHB06 WHB09 WHB12 Weight 138kg 148kg 158kg No. Of Blades Working Width 6 inches 9 inches 12 inches PTO Turning Speed 540 RPM Recommended Tractor HP 20-50HP Dims 177x79cm PTO Shaft Size 130-160cm Linkage Size Category 1... -
Page 7: Installation
Installation Before installation/maintenance, the tractor and attachment should be stationary with the hydraulic lift system in a neutral position and the ignition key removed. You will need to refer to Components Diagram opposite on page 8 and Installation Diagram 10 Steps on page 9. You will also require a second person to assist with installation. - Page 8 Step 7: Connect the PTO drive shaft to the gear box (C) and the other end to the tractor PTO. Check that it correctly meshes at both ends. Always cou- ple the two ends of the driveline and check they are locked in place. Com- pletely insert the sprung lock pins into the grooves in the PTO shaft on both the tractor and attachment sides.
- Page 9 Installation Diagram 10 Steps Roller adjustment Skid adjustment...
-
Page 10: Operating Instructions
Operating Instructions For compacted ground and denser soil types, operate the attachment at a slower speed to achieve the best finish and to avoid any damage to the attachment. Lower the tractor lift arms until the blades are near the ground, without touching the ground. -
Page 11: Auger Blade & Tip Replacement
Auger Blade & Tip Replacement Before installation/maintenance, the tractor and attachment should be stationary with the hydraulic lift system in a neutral position and the ignition key removed. You may wish to remove the auger from the attachment to change the blades. -
Page 12: Gear Oil Change & Check
Gear Oil Change & Check Before installation/maintenance, the tractor and attachment should be stationary with the hydraulic lift system in a neutral position and the ignition key removed. Always follow the manufacturer’s instructions for oils and lubricants. Do not mix old and new oils together, or mix different oil types. Always dispose of oils correctly and safely. -
Page 13: Servicing & Maintenance
Servicing & Maintenance Store all lubricants away from excessive heat, dust, moisture and contaminants. Before maintenance, the tractor and attachment should be stationary with the hydraulic lift system in a neutral position and the ignition key removed. Wipe grease nipples with a clean cloth before greasing to avoid injecting any dirt/grit. -
Page 14: Parts Diagram & List
Parts Diagram... - Page 15 Parts List for Diagram Diag. Part No Part Description 703820090 RB-00.102 Lower linkage pin 700080010 200.56.011 Lock/linch pin 803800002 WX-L-03-001 A frame bracket 703800010 WX-L-00-101 A frame top pin 501011099 GB/T 5783 M8x20 Bolt M8x20 506010055 GB/T 97.1 8 Plain washer 8 803820041 WX-HL-13-001 PTO protection hood...
-
Page 16: Attaching & Resizing Pto Shaft
Attaching & Resizing PTO Shaft Before installation/maintenance, the tractor and attachment should be stationary with the ignition key removed. Ensure all safety guards are in place and cover the PTO shaft when extended, ensure the sprung locking collar slides freely and is securely in the groove on the PTO. -
Page 17: Winton Product Warranty
Terms & Conditions All products purchased as new are covered under our 12 month warranty from the date of purchase. During this period Winton will repair or replace defective parts free of charge. This warranty is given on the proviso that the product has been used and maintained according to the Owners Manual. - Page 18 Notes...
- Page 19 Notes...
- Page 20 Published: August 2021...
