4 Rotate the handle on the transducer counterclockwise to the horizontal (locked)
position and push down on the handle to lock the transducer.
To disconnect the transducer from the system
1 Flip the lock handle up and rotate clockwise to the vertical (unlocked) position.
2 Pull the transducer connector away from the transducer interface.
3 Slide the connector up and out of the transducer bay.
Figure 1-11 Transducer bay with
transducer connected
