Electrical and Gas Oven
Combi TOUCH
EN
User manual *
0595402L00- 2022.02
*Original instructions

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Combi TOUCH 6 GN 1/1 and is the answer not in the manual?

Questions and answers

Related Manuals for Electrolux Professional Combi TOUCH 6 GN 1/1

Summary of Contents for Electrolux Professional Combi TOUCH 6 GN 1/1

  • Page 1 Electrical and Gas Oven Combi TOUCH User manual * 0595402L00- 2022.02 *Original instructions...
  • Page 2 Foreword Read the following instructions, including the warranty terms before installing and using the appliance. Visit our website www.electroluxprofessional.com and open the Support section to: Register your product Get hints & tips of your product, service and repair information The installation, use and maintenance manual (hereinafter Manual) provides the user with information necessary for correct and safe use of the appliance.

  • Page 3: Table Of Contents

    Contents A WARNING AND SAFETY INFORMATION....................5 General information ........................5 Personal protection equipment ......................6 General safety ..........................6 Protection devices installed on the appliance ..................7 Safety signs to be placed on the appliance or near its area ..............8 Reasonably foreseeable improper use ....................
  • Page 4 Anomaly table..........................58 FURTHER INFORMATION ........................67 Ergonomic features........................67 I.1.1 Certification ........................67 I.1.2 General recommendations ....................67 MACHINE DISPOSAL........................... 69 Procedure regarding appliance disposal ..................69...

  • Page 5: Awarning And Safety Information

    WARNING AND SAFETY INFORMATION General information To ensure safe use of the appliance and a proper understanding of the manual it is necessary to be familiar with the terms and typographical conventions used in the documentation. The following symbols are used in the manual to indicate and identify the various types of hazards: WARNING Danger for the health and safety of operators.

  • Page 6: Personal Protection Equipment

    Personal protection equipment Summary table of the Personal Protection Equipment (PPE) to be used during the various stages of the appliance's service life. Stage Protective Safety Gloves Glasses Safety garments footwear helmet ● ○ ○ — Transport — ● ○ —...

  • Page 7: Protection Devices Installed On The Appliance

    Disconnect the appliance from the power supply before carrying out any installation, assembly, cleaning or maintenance procedure. • Do not remove, tamper with or make illegible the CE marking, the safety, danger and instruction signs and labels on the appliance. •...

  • Page 8: Safety Signs To Be Placed On The Appliance Or Near Its Area

    Safety signs to be placed on the appliance or near its area Prohibition Meaning do not remove the safety devices do not use water to extinguish fires (placed on electrical parts) Keep the area around the appliance clear and free from combustible materials.

  • Page 9: Appliance Cleaning

    indicating the personal protection equipment to be used by them. In order to reduce the risks, provide for sufficient spaces while installing the unit. To preserve these conditions, the areas around the appliance must always be: • kept free of obstacles (e.g. ladders, tools, containers, boxes, etc.); •...

  • Page 10: Preventive Maintenance

    Preventive Maintenance In order to ensure the safety and performance of your equipment, it is recommended that service is undertaken by Electrolux Professional authorised engineers every 12 months, in accordance with Electrolux Professional Service Manuals. Please contact your local Electrolux Professional Service Centre for further details.

  • Page 11: Cgeneral Information

    – improper or poor: installation, repair, maintenance (including tampering, modifications and repairs carried out Check on Electrolux Professional website the list of authorized by third parties not authorized) and modification of safety customer care.

  • Page 12: Responsibility

    Protection safety measures consisting of the use of operation and invalidates the original manufacturer devices specific technical means (guards and warranty); safety devices) for protecting operators • operations carried out by non-specialised personnel; against risks. • unauthorized modifications or operations; Guard an element of a appliance used in a •...

  • Page 13: Appliance Overview

    Food loading on oven MODELS No. of grids 6 GN 1/1 6 GN 2/1 10 GN 1/1 10 GN 2/1 20 GN 1/1 20 GN 2/1 Maximum oven load Maximum pan/ tray load Appliance overview 1. Door handle (shape depending on the model) 10.

  • Page 14: Control Panel

    1. Turn the door handle clockwise or counterclockwise all the way to fully open the oven door. The cooking cycle is stopped, if in progress. 2. To close the door press it against the oven enough to lock 20 GN Model 1.

  • Page 15: Main Menu

    Models with boiler MANUAL Manual Automatic Programs MANUAL USER SkyHub Cleaning Settings °C °C 01 20 160°C 00:30 Help Agenda Plan & save °C 01:20 h:m 00 30 Touch the required icon in the main menu to access inside the different modes.

  • Page 16: Touch Screen Commands / Info And Display Messages

    Signalling information PLAN-N-SAVE/COOKING OPTIMIZER Door open warning signalling icon This function allows you to optimise consecutive cooking processes in order to reduce energy and water consump- The icon appears when the door is open or not properly tion of the transition phases (see F.12 Plan&Save/Cooking closed Optimizer mode chapter).
  • Page 17 – Upper drawer opening: Fan speed MANUAL USER • Touch this icon to set the speed of the fan from 1 to 7 levels. Manual Automatic Programs • Touch icon to close and enable the setting. • To disable this function operate on icons.

  • Page 18: Manual Mode

    MANUAL USER MANUAL USER MANUAL USER COMBI Cycle The steam generator and compartment heaters are used at the same time to keep foods tender; Food Safe Control Maximum temperature up to 300 ℃. ent Closed Low risk High risk Food Safe Control STEAM Cycle Use “Low risk”...
  • Page 19 Set the required TEMPERATURE • Touch the button illustrated in the figure to access the setting of temperature and time options; • Touch the row of the temperature value; enter the new value on the numeric keypad appearing on the display. MANUAL MANUAL USER...
  • Page 20 C. The display shows the set cooking cycle with the delayed MAN UAL USER start. Touch the button to confirm it (“C“). MANUAL Preheating °C 250°C 00:45 09 00 0 130 09:30 09:30 NOTE! If the cavity temperature is too high a message •...
  • Page 21 MAN UAL USER NOTE! To delete ECO-DELTA function touch the icon again. With ECODELTA on, the mode “Cooking Time“ Cycle done! switches automatically to the “Core Probe“ Now holding mode, that detects the inside temperature of the food (65℃). 5.7 kWh This function is particularly suitable for cooking large pieces of 00:35:00 food (at least 5 kg, e.g.
  • Page 22 Models with boiler • Touch VENT OPEN option Vent valve ADJUSTABLE for cooking with humid- MANUAL USER MANUAL USER ity adjustable from 1 to 99 %, allowing the 01 % Vent open removal of humidity when the set value is exceeded.
  • Page 23 When the set value is reached, the oven stops automatically. Make sure the tip (the sensitive part) is positioned near the centre of the product. Probe types It is important to place the core probe correctly near the centre of the product, making sure the tip does not Adjustable PROBE to measure the product core protrude and, in particular, that it does not to touch the temperature...
  • Page 24 Setting a MultiTimer option • Touch the touch time area on the right part of the row; 1. While setting a manual program, select MultiTimer option MANUAL MANUAL 00:30 and confirm; MultiTimer MultiTimer MANUAL MANUAL Preset 1 ---- --:-- --:--h:m 1 2 3 ---- --:--h:m...
  • Page 25 MultiTimer PreA 10:30m:s ---- --:-- h:m ---- --:-- h:m • Additional actions on the program can be done through the Food can be cooked with different modes during its cycle and ---- --:-- h:m lower drawer. Open the lower drawer to: therefore in different phases.

  • Page 26: Automatic Mode

    MANUAL MANUAL Duplicate phase Multiphase Multiphase If there is only one phase, it is not possible to move or delete a phase but only Duplicate. °C 00:30 Chill Chill °C 00:30 °C 00:30 IMPORTANT °C 00:30 °C 00:30 To keep the changes above described always save °C °C °C 00:30...
  • Page 27 How to set an automatic cycle Other presets allow to change a few parameters: 1. Open the upper drawer and select Automatic mode • Browning Level • Cooking Control (time/probe). T M T C MANUAL • Food status Meat balls Manual Automatic Programs...

  • Page 28: Cycles+ / Special Cycles

    Sensing/Temperature recovery functions start. Reference standard used (if enabled) These functions analyse the cavity conditions to optimise The check shows if the standard guide is successful. the cycle according to the type and load of food. USER AUTOMATIC Electric consumption in kWh Roasted, beaf / veal Parameter 1...
  • Page 29 Cycle displaying • Then set the core probe temperature; The display shows the set humidity value (A), for the cavity • The cycle displaying can be customised as standard or temperature the delta value set (B) and for the probe the steps view.
  • Page 30 This cycle simulates static cooking using a more gentle air It is possible to save and store the performed presets; see how distribution. The oven performs the cycle in manual mode to manage them at Presets management paragraph of this without the fan adjusting.
  • Page 31 At the end of the cycle the display shows the consumptions (if It is possible to save and store the performed presets; see how available) as a recap message. to manage them at Presets management paragraph of this chapter. It is possible to save and store the performed presets; see how to manage them at Presets management paragraph of this chapter.

  • Page 32: Programs Mode

    Programs mode AUTOMATIC USER PRESET 1 USER Cycles+ The “Programs Mode“ allows to recall program recipes already stored or downloaded from cloud and/or create and store new ones. Low temper. Eco Delta Regeneration 1. Select Programs mode. The display shows all stored cooking cooking Vent open...
  • Page 33 • Edit the program name on the appearing keypad and • Touch the image icon to change the default image; confirm. Choose the required image and confirm it. NEW PROGRAM’S NAME MANUAL USER PROGRAMS USER PICTURE All programs Default picture 1 2 3 4 5 6 7 8 9 0 Program 1 Program 2...
  • Page 34 • Touch the recycle bin icon to delete a program; • select “Local“, “Cloud“, or “All“ to display the programs by their source or to display all programs; Confirm to delete. PROGRAMS USER PROGRAMS PROGRAMS USER PROGRAMS All programs All programs All programs Cloud Program Program number 1 with...
  • Page 35 • Select the programs to be deleted or open the drawer again • Select MultiTimer presets to see all the presets saved and and select: present in all MultiTimer programs. PROGRAMS PROGRAMS if you want to be selected all the programs; Manage MT Presets Manage MT Pesets PROGRAMS...

  • Page 36: Skyhub Favorites Mode (Homepage)

    • Add more presets (see Setting a MultiTimer option – you are requested to give immediately a folder title and to paragraph); choose a pictures form the proposed ones. It is possible to rename, associate another picture or delete • Touch icon to close the EDIT window;...

  • Page 37: Help Mode

    3. Touch the required time; – To delete a new page touch the corresponding icon AGENDA USER • To delete all links, folders and pages touch icon. AGENDA USER December 2018 Reminder 11th December 2018 - 08:00 Help mode Type This function provides QR codes in order to display the user Automatic Program...
  • Page 38 AGENDA M i l i • Select the required food family and the preset. 11 D r 201 15:00 AGENDA The display shows the automatic program details. April 2019 AGENDA AGENDA Food families Meat 09:00 D il 10:00 Meat balls 11:00 Meat 12:00...

  • Page 39: Usb Mode

    1. Select USB from the upper drawer. AGENDA USER AGENDA USER December 2018 MANUAL USER December 2018 Manual Automatic Programs 08:00 Chill 09:00 09:00 10:00 10:00 °C Cleaning Settings Skyhub Download Upload 11:00 11:00 12:00 12:00 01:30 0°C Soft / Hard 13:00 13:00 14:00...
  • Page 40 • Select one of the existing backups. Then select the required Show selected items associated with the selected backup. Touch Programs and/or MultiTimer programs. When the USER USER wordings become green all the associated programs are Backup 20190607 Upload all shown on the display.

  • Page 41: Plan&Save/Cooking Optimizer Mode

    • If selecting “add“ and a file name is already existing, a • Expand the items associated to find the required preset(s); popup window asks how to proceed: PLAN & SAVE PLAN & SAVE – Rename Automatic presets Bread – Replace –...

  • Page 42: Skyduo/Match Mode (Depending On Your Model - Optional)

    • Touch to move the item; Select all A pop up message informs that this change cannot be saved. New list Show selected PLAN & SAVE PLAN & SAVE Preset / Program 1 00:00 h:m New list 3. Once you have selected a series of cooking processes: Preset / Program 2 00:00 h:m Preset / Program 3...
  • Page 43 USER MANUAL USER AUTOMATIC MANUAL USER MAN UAL USER Meat Accessories Manual Automatic Prog rams Manual Automatic Prog rams Base SkyDuo Chill SkyDuo Hood Chill Parameter 1 Do you want to start the SkyDuo Select one of the cycles available process now? SkyDuo °C...

  • Page 44: Hood Management

    • It is possible to check how much time is left until the hood Red meat maintenance: SkyDuo Select one of the cycles available in the blast chiller: °C Red meat Red meat - chill 160°C Red meat - freeze 00:30 01:30 h:m Confirm the synchronization on the blast chiller display;...
  • Page 45 reen S irit So t 00:25 h:m Setting delayed start Touch the button to start the cycle; Medium 00: 3 5 h:m • Before touching button open the lower drawer and select Strong 01:05 h:m the delay start icon. Extra strong 02:50 h:m Rinse 00: 4 5 h:m...
  • Page 46 TION KIT FOR DETERGENT/RINSE AID is the detergents, rinse aid and descale agents required (on demand); the oven will automati- approved by Electrolux Professional, which cally use the right amount of chemicals already comply with fluid category 3, as per current regulations and legislation.
  • Page 47 WARNING Detergent loading Both chemical substances and hot steam can escape from cavity with risk of burns and scalding. Use Gloves. Always refer to the safety cards and labels on the products used. WARNING Do not start any cooking cycle if the cleaning cycle has not been completed and/or after cleaning cycle completion if there are still...

  • Page 48: Boiler Maintenance

    CLEANING USER • Cycle stop Detergent consumption in tablets Green Spirit Keep hold button to stop the cycle; The Stop button will be available only when the program is Soft 00:25 h:m Rinse-aid consumption in tablets running. After the selection the display will show the Medium 00:30 h:m remaining time for rinsing the cavity and the boiler.
  • Page 49 1. Open the upper drawer and select Settings; SETTINGS SERVICE Language MANUAL 简体中文 Manual Automatic Programs ‫ةيبرعلا‬ Deutsch English UK SkyHub Cleaning Settings °C °C Español Français 01 20 160°C 00:30 Italiano Help Agenda Plan & save P усский Suomi 01:20 h:m Svenska 2.
  • Page 50 SETTINGS USER Measurement units Temperature °C °F Touch the screen as close as possible to the center of the red cross. Repeat until the cross turns green. Touch and hold to exit. Sound This setting allows to set: • the volume level from “0“ to “5“; •...
  • Page 51 Utilities Manual • Cooking info in option drawer. The activation allows riduzione figura in scala information showing up in the drawer. del 20,5 % • Delayed start. The activation allows to postpone a cycle at a This setting allows to enable / disable ( ) the Manual more convenient time.
  • Page 52 • enable/disable temperature recovery inside the cavity. Programs SETTINGS MultiTimer This setting allows to enable / disable ( ) the Programs mode and the related functions. Enable MultiTimer Enable MultiTimer programs The functions are divided into General, Local Programs and Enable temperature recovery Cloud Programs: Multitimer presets...

  • Page 53: Goven Care

    Green Spirit/Economizer Identity Card This setting allows to enable / disable ( ) the “Saving • It shows the latest uploaded software version. options“: SETTINGS User Password Green Spirit Enable saving options • This setting allows to set a password to access into specific environments, features and options to prevent setting Cleaning Skip rinse aid and...

  • Page 54: Cooking Chamber

    Air filter of the parts to be cleaned and how often they should be cleaned. It is a polyurethane sponge, housed in a support equipped with slits for the inlet of the cooling air of the oven components Cooking chamber (see figure for “table-top“...

  • Page 55: Inner, Outer And Cooking Chamber Glass

    3. Insert the new gasket along the entire seat. 2. With the door open, press the two top and bottom retaining clips as shown in the figure to reach the interspace between the inner and external glass; Clean the outer side of the internal glass door using a glass product;...

  • Page 56: Efficiency Control Of The Discharge System

    After cooking cycle the oven door, its internal glass, the 2. Remove the metal cover (“B“) and use the same system to gasket and the area around the door perimeter may become clean the single check valve (“C“); easily dirty due to greasy vapours coming out from the oven. These operations must be done with the door glass cold, without using abrasive detergents or rags.

  • Page 57: G.14 Periods Of Non-Use

    G.14 Periods of non-use G.15 Replacing wear and tear components If the appliance is not going to be used for some time, take the There are parts, whose damage happens because of the following precautions: ordinary use during a period, which are not covered by the manufacturer warranty.

  • Page 58: Maintenance Contacts (Only For Australia)

    G.18 Maintenance contacts (only for Australia) For service and spare parts, please contact: • Electrolux Professional – Electrolux Professional Australia Pty Ltd – 5–7 Keith Campbell Court – Scoresby, 3179 – call 03-9765- 8444 • Zanussi - Electrolux Professional Australia Pty Ltd – 5–7 Keith Campbell Court — Scoresby, 3179 – call 03-9765-8444 •...
  • Page 59 Anom- Type of Description Possible causes Actions anomaly ASCH Warning Component compart- • Filter is dirty; • Check room temperature considering the ment temperature oven needs fresh air to cool electronic • Too high room warning compartment. temperature. • Clean the filter; •...
  • Page 60 Anom- Type of Description Possible causes Actions anomaly BSOt Stops Boiler SSR NTC over- The oven can continue to work in recovery • Inlet air filter dirty; cooking temperature (NTC4) mode: cooking cycles will not use the boiler. • Cooling fan failure; cycle •...
  • Page 61 Anom- Type of Description Possible causes Actions anomaly CSOt Stops Cavity SSR NTC The oven can continue to work in recovery • Inlet air filter dirty; cooking overtemperature mode: cooking cycles will not use the boiler. • Cooling fan failure; cycle (NTC3) •...
  • Page 62 Anom- Type of Description Possible causes Actions anomaly Eotd Warning High temperature on Possible lack of water in • Check that the oven has water supply; water drain the drain system. • Pour some fresh water on the bottom cavity filter;...
  • Page 63 Anom- Type of Description Possible causes Actions anomaly EtUb Stops Boiler • Missing water in the • Wait for the boiler temperature to cool down boiler overtemperature boiler (electric heated (alarm ETUB will disappear) cycles appliances only); • Run a cleaning program including the rinse •...
  • Page 64 Anom- Type of Description Possible causes Actions anomaly FSnr Warning Cooling fan issue • Inlet air filter dirty • Clean inlet air filter; • Cooling fan failure • Check with a thin strip of paper whether a consistent air flow can be detected at the •...
  • Page 65 Anom- Type of Description Possible causes Actions anomaly Stops Drain temperature Possible lack of water in • Check that the oven has water supply; oven above safety limit the drain system. • Pour some fresh water on the bottom cavity filter;...
  • Page 66 Anom- Type of Description Possible causes Actions anomaly rtc1 Warning The communication Communication impossible with internal clock. between the RTC and HACCP • Call service the microcontroller is will not blocked function SbbU Stops Boiler gas fan speed Burner fan does not reach the desired speed. •...

  • Page 67: Further Information

    Anom- Type of Description Possible causes Actions anomaly UPrb Stops USB Food Probe The USB food probe is not Ensure the USB food probe is correctly oven missing or removed correctly plugged plugged. during cooking Call service. Urt2 Stops The RTC stopped flag Internal clock permanently locked.
  • Page 68 Suggested movement of trays according to their weights Try to place the trays into the cavities considering their weighs as suggested by the pictures below. 187cm 148 cm 5 Kg Shoulder hig 3 Kg hight 10 Kg Elbow hight 7 Kg hight 15 Kg Knuckle high...

  • Page 69: Machine Disposal

    5 Kg 5 Kg 10 Kg 10 Kg <15 Kg <10 Kg 15 Kg 15 Kg <5 Kg <3 Kg 10 Kg 10 Kg 5 Kg 5 Kg 3 Kg 3 Kg Blast Chiller 100Kg Oven 20G 3 Kg 5 Kg 5 Kg 10 Kg 10 Kg...
  • Page 70 NOTE! The symbol on the product indicates that this When dismantling the appliance, any marking, this product should not be treated as domestic manual and other documents concerning the appli- waste, but must be correctly disposed of in ance must be destroyed. order to prevent any negative consequences for the environment and human health.
  • Page 72 Electrolux Professional SPA Viale Treviso 15 33170 Pordenone www.electroluxprofessional.com...
