Summary of Contents for Electrolux Professional 6 GN 1/1
- Page 1 Electrical and Gas COMBI oven Touch and Digital Installation manual * 595402N00- 2019.11 *Original instructions...
- Page 2 Installation diagram 061 GN Electrical model – with boiler and boilerless – Touch and Digital (code 597402100)
- Page 3 Installation diagram 061 GN Gas model – with boiler – Touch and Digital (code 597402000)
- Page 4 Installation diagram 061 GN Gas model – boilerless – Touch and Digital (code 597401Z00)
- Page 5 Installation diagram 062 GN Electric model – with boiler and boilerless – Touch and Digital (code 597402700)
- Page 6 Installation diagram 062 GN Gas model – with boiler – Touch and Digital (code 597402600)
- Page 7 Installation diagram 062 GN Gas model – Boilerless – Touch and Digital (code 597402500)
- Page 8 Installation diagram 101 GN Electric model – with boiler and boilerless – Touch and Digital (code 597402400)
- Page 9 Installation diagram 101 GN Gas model – with boiler – Touch and Digital (code 597402300)
- Page 10 Installation diagram 101 GN Gas model – Boilerless – Touch and Digital (code 597402200)
- Page 11 Installation diagram 102 GN Electric model – with boiler and boilerless – Touch and Digital (code 597402A00)
- Page 12 Installation diagram 102 GN Gas model – with boiler – Touch and Digital (code 597402900)
- Page 13 Installation diagram 102 GN Gas model – boilerless – Touch and Digital (code 597402800)
- Page 14 Installation diagram 201 GN Electrical Model – Boilerless– Touch and Digital (code 597402P00)
- Page 15 Installation diagram 201 GN Gas Model – with boiler – Touch and Digital (code 597402Q00)
- Page 16 Installation diagram 201 GN Gas Model – Boilerless – Touch and Digital (code 597402R00)
- Page 17 Installation diagram 202 GN Electrical Model - with boiler and boilerless - Touch and Digital (code 597402V00)
- Page 18 Installation diagram 202 GN Gas Model – with boiler – Touch and Digital (code 597402W00)
- Page 19 Installation diagram 202 GN Gas Model – boilerless – Touch and Digital (code 597402X00)
- Page 20 EI = Electricity inlet G = Gas connection ⌀1″M (20 GN 1/1 – 2/1 and 10 GN 2/1) CW1 = Cold water inlet G 3/4″ G = Gas connection ⌀1/2″M (6 GN 1/1 – 2/1 and 10 GN 1/1 )
- Page 21 Foreword The installation, use and maintenance manual (hereinafter Manual) provides the user with information necessary for correct and safe use of the machine (or “appliance“). The following must not be considered a long and exacting list of warnings, but rather a set of instructions suitable for improving machine performance in every respect and, above all, preventing injury to persons and animals and damage to property due to im- proper operating procedures.
-
Page 22: Table Of Contents
Contents A WARNING AND SAFETY INFORMATION....................23 General information ........................23 Personal protection equipment ...................... 24 General safety ........................... 24 Transport, handling and storage ....................25 Installation and assembly ......................25 Positioning ..........................26 Machine disposal........................26 B APPLIANCE AND MANUFACTURER’S IDENTIFICATION DATA ..............27 Dataplate position........................ -
Page 23: Awarning And Safety Information
WARNING AND SAFETY INFORMATION General information To ensure safe use of the machine and a proper understanding of the manual it is necessary to be familiar with the terms and typographical conventions used in the documentation. The following symbols are used in the manual to indicate and identify the various types of hazards: WARNING Danger for the health and safety of operators. -
Page 24: Personal Protection Equipment
Personal protection equipment Summary table of the Personal Protection Equipment (PPE) to be used during the various stages of the machine's service life. Stage Protective Safety Gloves Glasses Safety garments footwear helmet — ● ○ — ○ Transport — ● ○... -
Page 25: Transport, Handling And Storage
• The A-weighted emission sound pressure level does not exceed 70 dB(A). • Turn the appliance off in case of fault or poor operation. • Do not use products (even if diluted) containing chlorine (sodium hypochlorite, hydrochloric or muriatic acid, etc.) to clean the appliance or the floor under it. •... -
Page 26: Positioning
• Connection to the power supply must be carried out in compliance with the regulations and provisions in force in the country of use and means for disconnection from the supply mains must be incorporated in the fixed wiring in accordance with the wiring rules. •... -
Page 27: Bappliance And Manufacturer's Identification Data
• Make the appliance unusable by removing the power cable and any compartment closing devices, to prevent the possibility of someone becoming trapped inside. APPLIANCE AND MANUFACTURER’S IDENTIFICATION DATA Dataplate position This instruction manual contains information relevant to various appliances. See the dataplate located on the left side to identify the appliance (see the picture below). -
Page 28: Cgeneral Information
Pmbar gas power Σ Qn G3–Lb1–... G120 consumption of various gas types Type-Bauart-type construction type (fume exhaust system) Electrolux Professional SpA Viale Treviso 15 33170 Porde- manufacturer none Italy Made in EU place of manufacture 99-9999 month/year of manufacture GENERAL INFORMATION... -
Page 29: Dtransport, Handling And Storage
The Manufacturer declines any liability for inaccuracies con- an integral part of the manual and therefore must be kept tained in the manual, if due to printing or translation errors. together with it. Any supplements to the installation, use and maintenance manual the Customer receives from the Manufacturer will form TRANSPORT, HANDLING AND STORAGE Introduction... -
Page 30: Etechnical Data
TECHNICAL DATA ELECTRICAL models data MODELS No. of grids 6 GN 1/1 6 GN 2/1 10 GN 1/1 10 GN 2/1 20 GN 2/1 20 GN 2/1 Power supply voltage 380– 220– 380– 220– 380– 220– 380– 220– 380– 220–... -
Page 31: Appliance Dimensions
Gas models data for Australia (cont'd.) Models No. of grids 6 GN 1/1 6 GN 2/1 10 GN 1/1 10 GN 2/1 20 GN 1/1 20 GN 2/1 Boiler max 51.8 51.1 64.1 62.6 83.9 82.4 100.1 97.9 100.0 97.9 240.1... -
Page 32: Conversion Tables
Depth Height Width Models inches inches inches 20 grids 1/1 35″ 55/64 36″ 27/64 1855 73″ 1/32 20 grids 2/1 1162 45″ 3/4 1125 44″ 27/64 1855 73″ 1/32 Conversion tables gr/gal (USA) mval/kg °dH °f °e mmol/l 1 °dH 1,79 1,25 17,9... -
Page 33: Transport Of The Appliance
3. Lift the appliance with a lift truck, remove the pallet and • All appliance sides must remain at 50 mm from any surface. position the appliance in the place of use; 50mm/2" 50mm/2" 50mm/2" If it’s necessary to carry out maintenance works on the appliance, slide it forwards. -
Page 34: Tabletop Models
• If steam from the ventilation pipe cannot be directed into an Mounting onto a cupboard (sizes GN 1/1 – 2/1) exhaust hood or a ventilating ceiling, there must be at least 1. Disassemble the rear panel “B“ and control panel “A“ (if 500 mm clearance space above the device. -
Page 35: Fixing Oven Systems
OVENS 6 GN 1/1 – 6 GN 2/1 Wall fixing – Wall brackets • Fix the stacked ovens to the wall by means of the 2 brackets. Posi- Appliance / base type See the figure below. tion Maximum Maximum OVEN 6 GN... -
Page 36: Water Connection
Water connection LEGEND NOTE! A. Single check valve assembly 3/4 ″ M – 3/4 ″ F (not to be Water connection must be carried out in compli- used for UK and Australian/NZ installations) ance with the regulations and provisions in force with the country. -
Page 37: Water Characteristics For Inlet "Cwi2
F.7.1 Water characteristics for inlet “CWI2“ In CWI2 inlet the appliance must be supplied with suitable drinking water (in particular Ph 6,5 ÷ 8,5 and conductivity > 50 µS/ cm). To guarantee correct appliance operation, some water treatment systems may therefore have to be installed. For that purpose, follow the indications given in the following charts according to your models: Models with boiler –... -
Page 38: Check Supply Pressure
MODELS WITHOUT BOILER – WTS GRAPH B (in case of treatment, check the treated water parameters falling into the green area; in no cases the values have to fall into the grey area) osmotization nanofiltration 1000 2000 3000 4000 5000 6000 7000 8000... -
Page 39: Electrical Connection
• horizontal sections where water can collect and stagnate For UK: (minimum slope 5%) are avoided. The appliance must discharge via a backflow protection device which gives fluid category 5 protection. Electrical connection For Australia: IMPORTANT The appliance shall be drained to a certified waste trap The connection to the electrical power supply must positioned at the drainage system connection point. -
Page 40: Safety Device
5. Connect the wires to the terminal block as shown in the following figure. 6. After connection secure the cable screwing the cable gland ring. CAUTION 20 grids models If the supply cord is damaged, it must be replaced by the manufacturer, its service Unsheathe all wires from the cable;... -
Page 41: Nominal Heat Output
• Before installing, consult the gas company to check the Exhaust gas and ventilation rates compatibility between the supply capacity and foreseen consumption. Appliance size • The combustion aeration capacity cannot be modified. NOTE! Min. room ventilation The connection of the inlet gas pipe is painted rate [m³/h] yellow. -
Page 42: Instructions For The Exhausting System
CAUTION Indications Make sure the ventilation system is able to • The extension pipe and the adapter ring are not included. discharge the quantity of exhaust gases They are available on the market. made by the appliance. The pipes must withstand 350 ℃. •... -
Page 43: Digital Models
G.1.2 Digital models 2. Select the “Date“ and “Time“ (set also the time and date format); When the oven is installed it is necessary to verify its correct functionality by carrying out a series of cycles with the following sequence: Time Date Set format... - Page 44 NOTE! The symbol on the product indicates that this When scrapping the machine, any marking, this product should not be treated as domestic manual and other documents concerning the appli- waste, but must be correctly disposed of in ance must be destroyed. order to prevent any negative consequences for the environment and human health.
