- Page 1 Electrical and Gas COMBI oven Touch and Digital Installation manual * 595402N00- . *Original instructions...
- Page 2 Installation diagram 061 GN Electrical model – with boiler and boil- erless – Touch and Digital (code 597402100)
- Page 3 Installation diagram 061 GN Gas model – with boiler – Touch and Digital (code 597402000)
- Page 4 Installation diagram 061 GN Gas model – boilerless – Touch and Digital (code 597401Z00)
- Page 5 Installation diagram 062 GN Electric model – with boiler and boiler- less – Touch and Digital (code 597402700)
- Page 6 Installation diagram 062 GN Gas model – with boiler – Touch and Digital (code 597402600)
- Page 7 Installation diagram 062 GN Gas model – Boilerless – Touch and Digital (code 597402500)
- Page 8 Installation diagram 101 GN Electric model – with boiler and boiler- less – Touch and Digital (code 597402400)
- Page 9 Installation diagram 101 GN Gas model – with boiler – Touch and Digital (code 597402300)
- Page 10 Installation diagram 101 GN Gas model – Boilerless – Touch and Digital (code 597402200)
- Page 11 Installation diagram 102 GN Electric model – with boiler and boiler- less – Touch and Digital (code 597402A00)
- Page 12 Installation diagram 102 GN Gas model – with boiler – Touch and Digital (code 597402900)
- Page 13 Installation diagram 102 GN Gas model – boilerless – Touch and Digital (code 597402800)
- Page 14 Installation diagram 201 GN Electrical Model – Boilerless– Touch and Digital (code 597402P00)
- Page 15 Installation diagram 201 GN Gas Model – with boiler – Touch and Digital (code 597402Q00)
- Page 16 Installation diagram 201 GN Gas Model – Boilerless – Touch and Digital (code 597402R00)
- Page 17 Installation diagram 202 GN Electrical Model - with boiler and boil- erless - Touch and Digital (code 597402V00)
- Page 18 Installation diagram 202 GN Gas Model – with boiler – Touch and Digital (code 597402W00)
- Page 19 Installation diagram 202 GN Gas Model – boilerless – Touch and Digital (code 597402X00)
- Page 20 D = Drain outlet ⌀50 mm M CW2 = Cold water inlet G 3/4″ for treated water ISO 228/1 EI = Electricity inlet G = Gas connection ⌀1″M (20 GN 1/1 – 2/1 and 10 GN 2/1) CW1 = Cold water inlet G 3/4″ G = Gas connection ⌀1/2″M (6 GN 1/1 –...
- Page 21 Foreword Read the following instructions, including the warranty terms before installing and using the appliance. Visit our website www.electroluxprofessional.com and open the Support section to: Register your product Get hints & tips of your product, service and repair information The installation, use and maintenance manual (hereinafter Manual) provides the user with information necessary for correct and safe use of the appliance.
-
Page 22: Table Of Contents
Contents A WARNING AND SAFETY INFORMATION....................23 General information ........................23 Personal protection equipment ...................... 24 General safety ........................... 24 Safety signs to be placed on the appliance or near its area ..............25 Residual risks ..........................26 Transport, handling and storage ....................27 Installation and assembly ...................... -
Page 23: Awarning And Safety Information
WARNING AND SAFETY INFORMATION General information To ensure safe use of the appliance and a proper understanding of the manual it is necessary to be familiar with the terms and typographical conventions used in the documentation. The following symbols are used in the manual to indicate and identify the various types of hazards: WARNING Danger for the health and safety of operators. -
Page 24: Personal Protection Equipment
Personal protection equipment Summary table of the Personal Protection Equipment (PPE) to be used during the various stages of the appliance's service life. Stage Protective Safety Gloves Glasses Safety garments footwear helmet ● ○ ○ — Transport — ● ○ —... -
Page 25: Safety Signs To Be Placed On The Appliance Or Near Its Area
Disconnect the appliance from the power supply before carrying out any installation, assembly, cleaning or maintenance procedure. • Do not remove, tamper with or make illegible the CE marking, the safety, danger and instruction signs and labels on the appliance. •... -
Page 26: Residual Risks
Danger Meaning caution hot surface danger of electrocution (shown on electrical parts with indication of voltage) Residual risks The appliance has several risks that were not completely eliminated from a design standpoint or with the installation of adequate protection devices. Nevertheless, through this manual the Manufacturer has taken steps to inform operators of such risks, carefully indicating the personal protection equipment to be used by them. -
Page 27: Transport, Handling And Storage
Transport, handling and storage • Transport (i. e. transfer of the appliance from one place to another) and handling (i. e. transfer inside workplaces) must occur with the use of special and adequate means. • Please refer to indications on packaging for stackability during transport, handling and storage. -
Page 28: Water Connection
Water connection • Water connection must be carried out in compliance with the regulations and provisions in force with the country. • The pressure measured upstream of the oven (and downstream of any WATER FILTRATION SYSTEMS installed) must be between 100 – 600 kPa (1,0 – 6,0 bar / 14,5 –... -
Page 29: Appliance And Manufacturer's Identification Data
Control Number: Conforms to: 3050436 NSF/ANSI 4 IMPORTANT When installing the appliance, make sure the electrical connection is carried out in compliance with that specified on the dataplate. Appliance and manufacturer's identification data The data plate gives the product identification and technical data. An example of the marking or data plate on the appliance is given below: Control Number: 3050436... -
Page 30: Cgeneral Information
Manufacturer Electrolux Professional SpA or any other The numerical values given on the appliance installation service centre authorised by Electrolux diagrams refer to measurements in millimeters and/or inches. -
Page 31: Customer Packaging Checks
Customer packaging checks • repairs not carried out in a workmanlike fashion, and replacements with parts different from those specified in • The forwarder is responsible for the goods during transport the spare parts catalogue (the fitting and use of non-original and delivery. -
Page 32: Gas Models Data
MODELS No. of grids 6 Grids 1/1 6 Grids 2/1 10 Grids 1/1 10 Grids 2/1 20 Grids 1/1 20 Grids 2/1 Weight GAS Models 140,5 163,5 157,5 Water pressure 100 – 600 100 – 600 100 – 600 100 – 600 100 –... -
Page 33: Appliance Dimensions
Category Gas: II2H3P – PRESSURE (ALL MODELS) Models 6 GN 1/1 6 GN 2/1 10 GN 1/1 10 GN 2/1 20 GN 1/1 20 GN 2/1 Type of gas Unit BOILER BOILER BOILER BOILER BOILER BOILER and BOIL- and BOIL- and BOIL- and BOIL- and BOIL-... -
Page 34: Conversion Tables
Depth Height Width Models inches inches inches 20 grids 1/1 35″ 55/64 36″ 27/64 1855 73″ 1/32 20 grids 2/1 1162 45″ 3/4 1125 44″ 27/64 1855 73″ 1/32 Conversion tables gr/gal (USA) mval/kg °dH °f °e mmol/l 1 °dH 1,79 1,25 17,9... -
Page 35: Installation
Installation E.4.1.1 Transport of the appliance • Keep the device’s barycenter in mind to prevent it from E.4.1 Unpacking tipping over. 1. Remove the copper staples and the cardboard from the appliance; • If you use the lift truck, keep also in mind the required spaces and the entrance dimensions. - Page 36 • If steam from the ventilation pipe cannot be directed into an exhaust hood or a ventilating ceiling, there must be at least 500 mm clearance space above the device. 50mm/2" 50mm/2" 50mm/2" min. 500 mm If it’s necessary to carry out maintenance works on the appliance, slide it forwards.
-
Page 37: Tabletop Models
E.4.4 Tabletop models E.4.5 Stacking installations For safety reasons, tabletop models should only be placed on The following tables indicate the possible appliance combina- top a manufacturer-original oven stand or cupboard structure. tions for stacking installations. Choose the appropriate structure in the accessories catalogue OVENS 6 GN 1/1 –... -
Page 38: Hygienic Requirements
IMPORTANT 20 GN models : Floor fixing The same safety provision shall be applied to floor For safety reasons the floor standing models MUST be fixed to standing ovens, to ship and offshore oil plant the floor by the two rear feet. installations and to all installations where the •... -
Page 39: Water Connection
Water connection LEGEND A. Single check valve assembly 3/4 ″ M – 3/4 ″ F (not to be E.5.1 General information on water connection used for UK and Australian/NZ installations) NOTE! Water connection must be carried out in compli- ance with the regulations and provisions in force For UK: with the country. -
Page 40: Water Characteristics For Inlet "Cwi2
E.5.2 Water characteristics for inlet “CWI2“ In CWI2 inlet the appliance must be supplied with suitable drinking water (in particular Ph 6,5 ÷ 8,5 and conductivity > 50 µS/ cm). To guarantee correct appliance operation, some water treatment systems may therefore have to be installed. For that purpose, follow the indications given in the following charts according to your models: Models with boiler –... -
Page 41: Check Supply Pressure
MODELS WITHOUT BOILER – WTS GRAPH B (in case of treatment, check the treated water parameters falling into the green area; in no cases the values have to fall into the grey area) osmotization nanofiltration 1000 2000 3000 4000 5000 6000 7000 8000... -
Page 42: Electrical Connection
• or to let the drain pipe discharge into a floor grate. • back side: AIR BREAK 20 grids models NOTE! An air-break to drain conforms to EN61770 shall be installed before the discharge to the drainage system. For UK: AIR BREAK The appliance must discharge via a backflow protection device which gives fluid category 5 protection. -
Page 43: Power Cable Installation In Electric Models
• Include also the appliance into an equipotential system. The equipotential wire must have a section of at least 10 mm This connection is made with the setscrew marked located externally near the power cable entry. IMPORTANT For Electrical models only: This appliance can be connected only to a supply with maximum system impedance no more than: 6 GN 1/1 and 10 GN 1/1 = 0.18 Ω... -
Page 44: Safety Device
2. Loose the ring to let the power cable run through the cable 6. After connection secure the cable screwing the cable clamp (see the figures) gland ring. 6–10 GN models E.6.4 Safety device The appliance is equipped with the following safety devices: •... -
Page 45: Nominal Heat Output
Before installing the discharge system: In relation to the combustion technology used, steam con- vection gas ovens are classified according to their “Construction type“. The regulations provide discharge system for each burnt gas. • identify the "“Construction type“" of the model in D TECHNICAL DATA paragraph or on the dataplate;... -
Page 46: Instructions For The Exhausting System
Indications • The extension pipe and the adapter ring are not included. They are available on the market. The pipes must withstand 350 ℃. • When installing the manifold “G“, always keep the distance “2D“ between the top of the extension pipe and the lowest point of the hood filters. -
Page 47: Wizard (Only For Touch Models)
NOTE! 3. Select the appliance configuration; For detailed information about the above proce- dures consult the corresponding Service Manual. Configuration WIZARD (only for touch models) When the appliance is switched for the first time a procedure Standard configuration verifies the installation and tests the appliance performances. Bakery/pastry This procedure must be completed to guarantee the oven Customer configuration... - Page 50 Electrolux Professional SPA Viale Treviso 15 33170 Pordenone www.electroluxprofessional.com...
