Monitor Desk Mount Instruction Manual
Website:
www.huanuoav.com
Model: HNCM19
Thank you for choosing this HUANUO product! At HUANUO we
strive to provide you with the best quality products and services
in the industry. Please share your experience of our product
with others on www.huanuoav.com/reviews if you are satisfied.
Should you have any issues, please don't hesitate to contact us.
Telephone: 1-800-556-0533 Mon-Fri 10am - 5pm (PST) (USA) (CAN)
Email: support@huanuoav.com (US/CA)
V1.0
Advertisement
Table of Contents
Related Manuals for HUANUO HNCM19
Summary of Contents for HUANUO HNCM19
- Page 1 Monitor Desk Mount Instruction Manual V1.0 Model: HNCM19 Thank you for choosing this HUANUO product! At HUANUO we strive to provide you with the best quality products and services in the industry. Please share your experience of our product with others on www.huanuoav.com/reviews if you are satisfied.
- Page 2 IMPORTANT SAFETY INSTRUCTIONS • Please carefully read all instructions before attempting installation. If you do not understand the instructions or have any concerns or questions, please contact our Technical Support line at 1-800-556-0533 or customer service at support@huanuoav.com. CAUTION: Avoid potential personal injuries and property damage! •...
- Page 3 Supplied Parts and Hardware Warning: This product contains small items that could be a choking hazard if swallowed. Before starting assembly, verify all parts are included and undamaged. Do not use damaged or defective parts. lf you require replacement parts, contact our Product Support line at 1-800-556-0533 or customer service at support@huanuoav.com.
- Page 4 Step 1 Assemble the Base Place foot pads [02] to the tempered glass base [04] in the corners Step 1-1 Note: Kindly note that the tempered glass base is designed to show the shiny glass side facing up Connect the pole [01] to tempered glass base [04] Step 1-2 Secure the pole [01] to tempered glass base [04] using bolts [A], steel washer [B], plastic washer [C] and Allen key [05a].
- Page 5 Step 2 Secure the Swivel Arm Assembly to the Pole Large Allen Key...
- Page 6 Large Large Allen Key Allen Key Step 3 Secure the Moitors to Swivel Arms Phillips Secure 2 pcs bolts into the Screwdriver top VESA holes on the back [Not Included] (If needed) (If needed) of the monitor manually. 3 in. (75mm)x3 in. (75mm) 4 in.(100mm)x4 in.(100mm) TV1/TV2 Alternate...
- Page 7 HEAVY! You may need assistance with this step. (If needed) (If needed) TV1/TV2 TV3/TV4 Step 4 Adjust the Monitor Position Slightly Adjust the Height of the Monitor Large Large Allen Key Allen Key Turn the preassembled bolt [S] clokwise or counter-clockwise to adjust the monitor up or down...
- Page 8 Horizontally Shift the Monitor Along the Swivel Arm Tilt the bottom of the monitor forward and move the monitor along the swivel arm. Step 5 Cable Management and Angle Adjustment 360° 360°...
