FILteR mAIntenAnCe (ContInued)
2. To Clean and Replace the Filters (continued)
19. To clean the Magnet Grate (5), un-screw and remove the 6off end caps with a flat
headed screw driver and remove each magnet bar contained within using a pair of
grips on the end of the magnet bar screw.
20. As each magnet bar is removed from the grate, dirt and debris will start to fall off the
grate.
21. Once all of the magnet bars have been removed, carefully clean the bars with a dry
cloth and store in a safe place. Do not allow the magnet bars to get too close to each
other, pinching hazard!
22. When the Magnet Grate (5) has had all of the magnet bars removed, rinse the Magnet
Grate under a tap or swill around in a bucket of water to remove any remaining dirt
and debris.
23. Clean and dry the Magnet Grate (5) with a dry cloth, carefully replace all of the
magnet bars with the crew facing outwards and then screw the caps back on with a
flat screw driver.
24. Replace the now cleaned Magnet Grate (5) back into the Vessel Body (4) on top of
the Baffle Plate (6).
25. Now repeat the operations of 11 to 13, in reverse by following the Bolt tightening
sequence on page 26.
26. Ensure the nuts on the lid have been tightened to a torque of 40Nm.
27. Manually close the ½" Manual Vent Isolating Valve (19) and replace the ½" plug to
prevent accidental opening of the Manual Vent Valve (19).
28. Manually close the 1" Isolating Valve (12). This will close the BOSS™ X-POT6+ Vessel
(4) to drain.
29. Slowly manually open the 1" Isolating Valves (1 & 3) on the Dirty Flow into the BOSS™
X-POT6+. This will now let system water into the BOSS™ X-POT6+ Vessel.
30. At the start of the filling procedure, air will escape through the Automatic Air Vent.
This will be signalled by a 'hissing'. When the air is fully omitted from the vessel...
31. Slowly manually open the 1" Isolating Valves (8 & 11) on the Clean Return from the
BOSS™ X-POT6+.
32. Replace the top cover of the Insulation Jacket and tie.
33. Turn the power on to the BOSS™ X-POT6+ unit by turning the Mains ON/OFF Power
Switch (22) through 90
34. Check to see if the power is on. The power to the VEXO
activate it. The screen should now scroll 'Filter Pump Run' and the pump will be
operational.
The BOSS™ X-POT6+'s filters have been cleaned and changed. The BOSS™ X-POT6+ is
now active and is running in automatic mode and in-line with the controls philosophy.
