RDL M-101 User Manual page 8

TIMER MODE
3.4 Disconnection
3.4.1 No Remaining Credit
When the prepaid credit expires the timer main contactor will be open, thus disconnecting the
power. To restore power and restart the timed cycle, coins must be inserted.
3.4.2 Reverse Energy Detection
If reverse power is detected above a pre-determined level the display will indicate "RED" (Reverse
Energy Detection). Reverse detection can only be reset via the private mode switch buttons.
3.5 Prepayment Coins
3.5.1 Valid Coins
When a valid coin is inserted, time is credited to the timer and its acceptance is indicated by the
message 'XXXX Minutes' being displayed momentarily. The maximum credit is limited to 1440
minutes at which point the display will change to Maximum Reached. An example is shown below:
Example 1:
DISPLAY
Timer Countdown 00:00:00
XXXX Minutes Credited
3.5.2 Maximum Reached
The message "Maximum Reached" is displayed if a coin is inserted that would cause the pre-paid
credit to become greater than Maximum Time hh:mm set.
Visit: www.rdlmeters.com
14
ACTION
Insert value Coin
Set time credited to timer
4. PRIVATE MODE PROGRAMMING
4.1 Programming Method
After REMOVING THE CASH BOX and pressing either of the exposed recessed black private mode
switch buttons, the following 7 parameters can be sequentially viewed/ modified using the RED and
GREEN buttons of the timer.
STEP PROGRAMMING
1 DD/MM/YYYY HH:MM
2 Zero Timer No Yes
3 Token hh:mm
4 Max Time hh:mm
Tournament Mode
5
No Yes
6 Operational Mode Meter Timer
7 Factory Defaults No Yes
To display/modify a particular parameter first press either private mode switch buttons upon the
message "Programming" will be displayed. Next press the RED button until the Date and Time are
displayed.
Each press of the GREEN button will increment the value above the cursor.
Each press of the RED button for less than 3 seconds will move the cursor one place through
the programmable setting displayed parameter. To store the new value press the RED button for
greater than 3 seconds, then on releasing the RED button the next parameter for programming will
be displayed. If no buttons are pressed within 10 seconds the display revert to its normal operation
mode without saving the new value.
Example: (shown overleaf)
To change the amount of time credited for each coin inserted the sequence of events will be as
follows:
TIMER MODE
SETTINGS
Current Date and Time
Manually Zero Timer - No or Yes
Time credited for each token coin inserted
Maximum time which can be credited
Select Tournament Mode - No or Yes
Select Meter or Timer mode
Reset to Factory Defaults excluding kWh
cumulative totals
