RDL M-101 User Manual page 5

METER MODE
Example 3:
DISPLAY
Debt £2.99
£5.00 Credited
Rate - Debt £2.01
3.7.2 Excess Credit
The message "Excess Credit" is displayed if a coin is inserted that would cause the pre-paid
credit to become greater then £999.99.
3.7.3 Emergency Credit Repayment
When the pre-set emergency credit has expired, coins must be inserted that are of sufficient
value to give a pre-paid credit of at least £1.00 above the emergency credit debt.
4. PRIVATE MODE PROGRAMMING
4.1 Programming Method
After REMOVING THE CASH BOX and pressing either of the exposed recessed black private
mode switch buttons, the following 10 parameters can be sequentially viewed/ modified using
the RED and GREEN buttons on the meter.
STEP PROGRAMMING
1 DD/MM/YYYY - HH:MM
2 Zero Credit No Yes
3 Set Credit £XXX.XX
4 Emergency Credit £XX.XX
5 Emergency Credit Avail £XX.XX
6 Rate 1 Unit Cost £XX.XX
7 Rate 2 Unit Cost £XX.XX
8 Standing Charge £XX.XX
9 Operational Mode Meter Timer
10 Factory Defaults No Yes
To display/modify a particular parameter first press either private mode switch button upon the
message 'PROGRAMMING' will be displayed. Next press the RED button until the Date and
Time are displayed.
Visit: www.rdlmeters.com
8
ACTION
Insert £5 value of Coins
SETTINGS
Current Date and Time
Manually Zero Credit - No or Yes
Manually Set Credit
Emergency Credit Value
Emergency Credit Available point
Rate 1 - Cost per kWh Unit
Rate 2 - Cost per kWh Unit
Standing Charge per 24 hours
Select Meter or Timer operating mode
Reset to Factory Defaults excluding kWh
cumulative totals
Each press of the GREEN button will increment the value above the cursor. Each press of the
RED button for less than 3 seconds will move the cursor one place through the programmable
setting of the displayed parameter. To store the new value press the RED button for greater
than 3 seconds, then on releasing the RED button the next parameter for programming will
be displayed. If no buttons are pressed within 10 seconds the display will revert to its normal
operation mode without saving the new value.
Example: To change the value on Rate 1 Unit Cost the sequence of events will be as follows:
STEP ACTION
1 Press either private mode switch button
Press and release the RED button for less
2
than 3 seconds
Press and hold the RED button for greater
3
than 3 seconds to store the value
Press and hold the RED button for greater
4
than 3 seconds to store the value
Press and hold the RED button for greater
5
than 3 seconds to store the value
Press and hold the RED button for greater
6
than 3 seconds to store the value
Press and hold the RED button for greater
7
than 3 seconds to store the value
Press and release the GREEN button
8
until the correct value is shown
Press and release the RED button for less than 3
9 seconds to move the cursor one place through the
programmable setting of the displayed parameter
Press and hold the RED button for greater
10
than 3 seconds to store the settings
Press and hold the RED button for greater
11
than 3 seconds to store the settings
Press and hold the RED button for greater
12
than 3 seconds to store the settings
Press and hold the RED button for greater
13
than 3 seconds to store the settings
Press and hold the RED button for greater
14
than 3 seconds to store the settings
15
METER MODE
DISPLAY
PROGRAMMING
Date and Time
DD/MM/YY HH:MM
Date and Time
DD/MM/YY HH:MM
Zero credit
No Yes
Set Credit
£XXX.XX
Emergency Credit
£XXX.XX
Emergency Credit Avail
£XXX.XX
Rate 1 Unit Cost
£XXX.XX
Rate 1 Unit Cost
£XXX.XX
Rate 1 Unit Cost
£XXX.XX
Rate 2 Unit Cost
£XXX.XX
Standing Charge
£XXX.XX
Operational Mode
Meter Timer
Factory Defaults
No Yes
Exiting Programming
