2.1 Functions
◇ Automatic cleaning: the default mode is automatic, however, this can be overridden using the
Remote Control. When the Remote Control is not being used, the iCleaner-120 will return to
automatic mode.
◇ Overall cleaning: the iCleaner-120 not only cleans the floor of your pool, it also cleans the
wall, at the same time, the iCleaner-120 will filter water, and the dirt will be collected into
Filter Bag.
◇ Timing cleaning: you can select one of three cleaning time with Remote Control (0.5h, 1h or
2 h). The iCleaner-120 will shut down automatically when the selected cycle time is over.
The power box must be turned of manually.
◇ Manual cleaning: the Remote Control can be used to clean specific areas immediately.
◇ Self protection (out of water): Impeller decelerates to a stop in twenty five seconds if the
iCleaner-120 senses it is no longer in water, to prevent personal injury and to protect the
water pump.
◇ Stop protection: the iCleaner-120 will stop if foreign matter retards the Impeller.
2.2 Product Parameters
Model
Input Voltage
Rated Power
Cycle Time
Floating Cable Standard Length
Filter Bag
Water Pump Capacity
Moving speed
Grade of Waterproof
Optimum Storage Temperature
Optimum Working Temperature
Dimension（L*W*H）
Packing Measurement(L*W*H)
Gross Weight
All manuals and user guides at all-guides.com

2 Product Overview

iCleaner-120/SPC-1
100-240VAC, 50-60Hz
200W
0.5Hr/1Hr/2Hrs
15m
Standard:70um
18m /h
15m/min
Host: IP68
0~40℃
10~32℃
450*490*260mm
574*574*413mm
19.2kg
