2.1 Functions
◇ Automatic cleaning: the default mode is automatic, however, this can be overridden using the
Remote Control. When the Remote Control is not being used, the iCleaner-200D will return
to automatic mode.
◇ Overall cleaning: the iCleaner-200D not only cleans the floor of your pool, it also cleans the
wall, at the same time, the iCleaner-200D will filter water, and the dirt will be collected into
Filter Bag.
◇ Timing cleaning: you can select one of three cleaning time with Remote Control (4h, 6h or 8
h). The iCleaner-200D will shut down automatically when the selected cycle time is over.
The power box must be turned of manually.
◇ Manual cleaning: the Remote Control can be used to clean specific areas immediately.
◇ Self protection (out of water): Impeller decelerates to a stop in twenty five seconds if the
iCleaner-200D senses it is no longer in water, to prevent personal injury and to protect the
water pump.
◇ Stop protection: the iCleaner-200D will stop if foreign matter retards the Impeller.
2.2 Product Parameters
Model
Input Voltage
Rated Power
Cycle Time
Floating Cable Standard Length
Filter Bag
Water Pump Capacity
Moving speed
Grade of Waterproof
Storage Temperature
Optimum Working Temperature
Dimension（L*W*H）
Packing Measurement(L*W*H)
Gross Weight

2 Product Overview

- 2 -
iCleaner-200
D
100~240VAC, 50-60Hz
350W
4Hrs/6Hr /8Hr s s
40m
Standard: 70um
3
40m /h
15m/min
Host: IP68
0~40℃
10~32℃
845.8*264*452.5mm
931*574*433mm
37.5kg
