VI. ZONES
The EU-M-8n is a master room regulator – it enables the user to edit parameters of other zones regardless of the room
regulator or room sensor used there.
In order to edit a given zone parameters, tap on the area of the screen with the zone status information. The display shows a
basic zone editing screen:
1
11
1. Return to the main screen
2. Operation mode icon
3. Schedule icon
4. Heating active
5. External temperature
6. Current time and date
7. Enter Zones menu
8. Parameter icons
9. Pre-set zone temperature
10. Name of the current schedule
11. Current zone temperature
3
2
5
4
Sensor, regulator
icon
Actuator icon
Window sensor
icon
Floor sensor icon
Level humidity*
* with a registered sensor offering humidity measurement function
12
6
7
8
Level of battery
WiFi signal
strenght
Level of actuator
opening
