Kit Contents: K1
A
K1
C1
New
Ref.
Description
K1
A
Rotary Ignitor
NI
B
Burner Grate
NI
C/C1
Top Cover / Screws
NI
D
Spark Electrode Wire
NI
E
Knob
NI
F
Knob Base
NI
G
Ignitor Bracket
NI
Not Included: Reference Only
Tools Needed:
■ #2 Phillips Screwdriver
■ Installation / Owner's Manual
This procedure is to be performed by authorized service
WARNING
!
personnel only. Improper installation, adjustment, altera-
ATTENTION
tion, service or maintenance can cause injury or property
damage.
Replace Part
Be sure the appliance has been isolated from the pro-
WARNING
!
pane gas supply before starting!
ATTENTION
B
1. Remove
; set aside.
C1
2. Remove
(3x); set aside.
C
3. Remove
.
D
4. Pull
(2x-cooktop, 3x-oven) from
E
A
5. Pull
off of
; set aside.
F
6. Remove
(2x); set aside.
A
G
7. Remove
and
assembly.
G
A
8. Remove
(2x) from
; set aside.
Using new part, reverse steps 8 through 1 to replace and reinstall.
Printed in U.S.A./Imprimé aux É.-U./Impreso en EE. UU.
Thetford Corporation
7101 Jackson Road
Ann Arbor, MI 48103
1-800-543-1219
XR17200 and XC200
Rotary Ignitor
B
C
A
terminals.
www.thetford.com
A
K1
D
D
Fig. 1
Service Kit
Ensemble de réparation
Juego de servicio
SPARK
BURNERS
E
G
Part No. /N° de pièce/Pieza n.º 639472A (05.22.2017)
639473
F
A
K1
