Dual FXS Voice Relay Cable

Dual FXS Voice Relay Cable
Specification
The voice relay cable shipped with the Dual FXS Voice Relay Daughtercard has the
following specification:
Connector Pinout
The RJ45 FXS port have the following pinout:
Warning!
The FXS Interface should only be connected to an analog telephone handset and/or
fax machine.
B-4
All manuals and user guides at all-guides.com
• Connectors: RJ45 to RJ45 Cable
• Color: Gray
Pin
No.
1
2
3
4
5
6
FXS
Name Function
N/A
N/A
Loop B
Loop A
N/A
N/A
PathBuilder S21x Switch Cabling
