Installing or Removing the Lithium Battery
Removing/
Figure 2-6 shows how to install and replace the battery.
Installing the
Battery
To remove the battery:
Using your fingers, push the retaining
tabs aside and pry the battery out of the
holder.
To install the battery:
Place the battery in the holder, with the
positive (+) side up, and press down until
the retaining tabs click into place.
Figure 2-6. Replacing the Battery
2-14
All manuals and user guides at all-guides.com
Retaining Tabs
Installing the PathBuilder S21x Switch Hardware
Battery
Battery Holder
