Summary of Contents for NetPing 4/PWR-220 v4/SMS
- Page 1 [ENG] NetPing 4/PWR-220 v4/SMS, User guide ...
-
Page 2: Table Of Contents
[ENG] NetPing 4/PWR-220 v4/SMS, User guide - Содержание [ENG] About What and for Whom This Document Is ..........4 [ENG] Appearance and Specifications of a Device ............ 5 [ENG] Connecting External Sensors ................8 [ENG] Connecting Load..................... 10 [ENG] Disclaimer and Copyright................12 [ENG] Plugging, Installing and Initial Configuring of a Device........ - Page 3 [ENG] NetPing 4/PWR-220 v4/SMS, User guide - – ...
-
Page 4: [Eng] About What And For Whom This Document Is
[ENG] NetPing 4/PWR-220 v4/SMS, User guide -[ENG] About What and for Whom This Document Is [ENG] About What and for Whom This Document Is Preparing a device for operation as well as external electric interfaces and operating peculiarities are described in the document. -
Page 5: [Eng] Appearance And Specifications Of A Device
[ENG] NetPing 4/PWR-220 v4/SMS, User guide -[ENG] Appearance and Specifications of a Device [ENG] Appearance and Specifications of a Device Picture 1 Front appearance of a device with a plugged 1-Wire temperature sensor Picture 2 Front panel of a device Sockets, LEDs and controls at the front panel: Sockets for connecting sensors of the 1-Wire standard (temperature, humidity sensors);... - Page 6 [ENG] NetPing 4/PWR-220 v4/SMS, User guide -[ENG] Appearance and Specifications of a Device Picture 3 Back appearance of a device Picture 4 Back panel of a device Sockets at the back panel: Input socket for a power supply cable; Output sockets for power supply channels.
- Page 7 [ENG] NetPing 4/PWR-220 v4/SMS, User guide -[ENG] Appearance and Specifications of a Device Product Specifications Value Length of a removable power cord Device dimensions 220 x 175 x 42 Package dimensions 240 x 180 x 101 Weight 1270 g [ENG] Appearance and Specifications of a Device...
-
Page 8: [Eng] Connecting External Sensors
[ENG] NetPing 4/PWR-220 v4/SMS, User guide -[ENG] Connecting External Sensors [ENG] Connecting External Sensors It is prohibited to plug sensors and external modules into NetPing devices when a power supply is on! Plug external sensors of the 1-Wire standard into the connectors at the front panel of a device: It is possible to plug up to 8 temperature sensors and 1 humidity sensor into 4 1-Wire connectors of the device. - Page 9 [ENG] NetPing 4/PWR-220 v4/SMS, User guide -[ENG] Connecting External Sensors Maximum cable length 1-Wire network is limited to 50 meters. For example, the next picture shows 3 temperature sensors plugged into one port: For configuration and receiving notifications from sensors through the Ethernet/Internet network as well as SMS notifications see the document "Firmware Description"...
-
Page 10: [Eng] Connecting Load
[ENG] NetPing 4/PWR-220 v4/SMS, User guide -[ENG] Connecting Load [ENG] Connecting Load Connect equipment which power needs to be controlled to output sockets at the back panel of a device. To make connecting more convenient, use the cords «monitor - the system unit» or an adapter for connecting PWR-220, for example:... - Page 11 [ENG] NetPing 4/PWR-220 v4/SMS, User guide -[ENG] Connecting Load When connecting a load to output power supply channels, take into account that the maximum allowable summary voltage of all connected external devices must not exceed 3500 W. A maximum load for one socket must not exceed 1,5 kW.
-
Page 12: [Eng] Disclaimer And Copyright
User Guide, as well as firmware and software of devices and this User Guide belong to NetPing global Ltd. Сopying, replication and translation of this user guide to other languages are not allowed without a prior written permission are not allowed without a of a rightholder. -
Page 13: [Eng] Plugging, Installing And Initial Configuring Of A Device
[ENG] NetPing 4/PWR-220 v4/SMS, User guide -[ENG] Plugging, Installing and Initial Configuring of a Device [ENG] Plugging, Installing and Initial Configuring of a Device To prepare a device for operation, do the following: 1. Take a device out of a package and install at a horizontal surface or fix it in the 10" or 19" 1U rack. - Page 14 LINK LED lighting near a corresponding Ethernet port at the front panel of a device will mean that a connection was established successfully. The second Ethernet port may be used for connecting any Ethernet devices in the chain, including other NetPing devices.
- Page 15 [ENG] NetPing 4/PWR-220 v4/SMS, User guide -[ENG] Plugging, Installing and Initial Configuring of a Device Now a device is connected and ready for operation. A device that has been just purchased or a device, which has been reset to default values (see «Resetting Parameters to Default Values»), needs the initial configuration of network addresses and load control...
-
Page 16: [Eng] Resetting Parameters To Default Values
[ENG] NetPing 4/PWR-220 v4/SMS, User guide -[ENG] Resetting Parameters to Default Values [ENG] Resetting Parameters to Default Values Resetting parameters of a device to default values is necessary in the next cases: • Login and/or password for accessing a device web interface is lost;... -
Page 17: [Eng] Safety Precautions
[ENG] NetPing 4/PWR-220 v4/SMS, User guide -[ENG] Safety Precautions [ENG] Safety Precautions The next information will allow users to avoid both injuries and damaging a device as well as connected equipment. • A device must be plugged to a power supply socket with a ground or a hole, where a contact is inserted. A contact must be located at a plug and be connected to a ground wire. -
Page 18: [Eng] Shipping Kit
[ENG] NetPing 4/PWR-220 v4/SMS, User guide -[ENG] Shipping Kit [ENG] Shipping Kit Shipping kit includes: The device «NetPing 4/PWR-220 v3/SMS» - 1 pc.; Power cord - 1 pc.; GSM antenna - 1 pc.; Mounting brackets - 2 pcs.; Shipping box - 1 pc. -
Page 19: [Eng] Terms Of Use, Storage, Transportation And Recycling Information
[ENG] NetPing 4/PWR-220 v4/SMS, User guide -[ENG] Terms of Use, Storage, Transportation and Recycling Information [ENG] Terms of Use, Storage, Transportation and Recycling Information It is allowed to use a device only in excellent technical condition and only for intended purpose according to a user guide. -
Page 20: [Eng] Updating Firmware
[ENG] NetPing 4/PWR-220 v4/SMS, User guide -[ENG] Updating Firmware [ENG] Updating Firmware A device supports updating firmware through a device web interface – see the document "Firmware Description" for more details (Where to Get a Document Describing Firmware). [ENG] Updating Firmware... -
Page 21: [Eng] Warranty
[ENG] NetPing 4/PWR-220 v4/SMS, User guide -[ENG] Warranty [ENG] Warranty The manufacturer guarantees normal operation of the product within 24 months from the date specified on the warranty sticker if a buyer follows operating and storage conditions. Manufacturer warranty applies only to failure of a device which occurred because of defects in manufacturing process of products and components used. -
Page 22: [Eng] What If There Are Still Questions
[ENG] NetPing 4/PWR-220 v4/SMS, User guide -[ENG] What if There Are Still Questions [ENG] What if There Are Still Questions Technical support for Netping devices Manufacturer's website: http://www.netpingdevice.com/ Kindly see our blog for articles with examples of using the devices and news on issuing new firmware versions. -
Page 23: [Eng] Where To Get A Document Describing The Firmware
[ENG] NetPing 4/PWR-220 v4/SMS, User guide -[ENG] Where to Get a Document Describing the Firmware [ENG] Where to Get a Document Describing the Firmware The settings and operating procedures with device management interfaces are given in the document "Firmware description". The documentation is updated in accordance with current amendments to the firmware. ...
