Summary of Contents for NetPing NP-SM4
- Page 1 [ENG] NetPing NP-SM4, User guide ...
-
Page 2: Table Of Contents
Appearance ............................5 Sockets and LEDs ..........................5 Power Supply Unit ..........................5 [SM4] Shipping Kit....................... 7 [SM4] Installation and Connection................8 [SM4] PoE Technology in NP-SM4 Switches .............. 9 [SM4] QoS Technology in NP-SM4 Switches ............12 [SM4] Warranty......................13... - Page 3 [ENG] NetPing NP-SM4, User guide - – ...
-
Page 4: [Sm4] Introduction
This User Guide helps to know the peculiarities of a device operation as well as to get an idea about its functionality and technical specifications, and prepare a device for operation. A User Guide describes a model NP-SM4 of switches (hereinafter a switch or a device). -
Page 5: [Sm4] Np-Sm4 Switch Overview
In this section a using area of a device is described as well as its appearance, sockets and indication elements. A Purpose of a Device NP-SM4 – is an uncontrollable switch with 4 ports. A peculiarity of this switch is its power supply feeding from PoE (IEEE 802.3.at... - Page 6 [ENG] NetPing NP-SM4, User guide -[SM4] NP-SM4 Switch Overview To plug an external power supply unit, a socket DJK-02A with a 2.1 mm dowel is used. It is recommended to use Power Supply Unit 48V 1.5A as an external power supply unit of a switch.
-
Page 7: [Sm4] Shipping Kit
[ENG] NetPing NP-SM4, User guide -[SM4] Shipping Kit [SM4] Shipping Kit A shipping kit includes: • a NP-SM4 switch; • 6 mini jumpers for PoE switching; • a ZIP pack. A power supply unit is not included into a shipping kit! [SM4] Shipping Kit ... -
Page 8: [Sm4] Installation And Connection
A switch operation with an opened lid is not allowed. • Install jumpers to transmit a power supply (Look at the Section “PoE Technology in NP-SM4 Switches”)); • Put a switch in a place of planned installation;... -
Page 9: [Sm4] Poe Technology In Np-Sm4 Switches
By default, NP-SM4 switch does not feed the ports P0, P1, P2. There is a need to install jumpers on a board of a switch to feed one or several ports. Two jumpers are responsible for each port. A location of jumpers is shown at the picture 7. - Page 10 Installing of a jumper J6 disables a function of auto determination, which is used by PSE devices to determine a presence of PoE consumers (PD devices). Thus PSE devices will feed NP-SM4, which has a jumper J6 installed. J6 jumper is not included into a shipping kit.
- Page 11 802.3at standard. Consumers can be connected to different ports of NP-SM4 switch or to one port, there is no limit to a total power. A maximum power consumption of NP-SM4 switch itself is 2.5 watts, which gives an oppurtunity to join up to 10 NP-SM4 switches in a circuit, using short patch cords.
-
Page 12: [Sm4] Qos Technology In Np-Sm4 Switches
[ENG] NetPing NP-SM4, User guide -[SM4] QoS Technology in NP-SM4 Switches [SM4] QoS Technology in NP-SM4 Switches QoS technology in NP-SM4 switches is programmed to provide a good result for the most scenarios with default settings. Amount of queues in the interface:4 Queues servicing mechanism:WRR (Weighted Round Robin) Traffic classification: by six high-order IP TOS and IPv6 TC bits ... -
Page 13: [Sm4] Warranty
[ENG] NetPing NP-SM4, User guide -[SM4] Warranty [SM4] Warranty The manufacturer guarantees normal operation of the product within 24 months from the date specified on the warranty sticker if a buyer follows operating and storage conditions. Manufacturer warranty applies only to failure of a device which occurred because of defects in manufacturing process of products and components used.
