Hoops Pro Dunk Gold PD-G-G Owner's Manual

Basketball system

Advertisement

Quick Links

OWNER'S
MANUAL
Warning
! Do not slide, climb, or
play on pole.
! Keep organic
material away from
pole base. Grass,
litter, etc. could cause
corrosion and /or
deterioration.
! Check pole system
twice a year for signs
of corrosion (rust,
pitting, and chipping).
Remove rust and/or
loose paint completely
and repaint with
exterior enamel paint.
If rust has penetrated
through the steel
anywhere, replace
pole immediately.
! Check unit before
each use for loose
hardware, excessive
wear, and signs of
corrosion and repair
before using.
! During play, use
extreme caution to
keep players face
away from the
backboard, rim, and
net.
! Wear a mouth guard
when playing to avoid
dental injuries.
! When adjusting
height, keep hands
and fingers away from
moving parts.
! During play, do not
wear jewelry (rings,
watches, necklaces,
etc.). Objects may
entangle in net.
Pro Dunk
Basketball System
MODEL NUMBER
PD-G-G or PD-G-A
WELCOME TO THE FAMILY OF PRO
DUNK
Thank you for purchasing our basketball system. We try hard to
ensure that our products are of high quality and free of
manufacturing defects and of missing parts. However, if you have
any problems with your basketball pole, such as a manufacturing
defect or a missing part please contact us at the following:
Toll Free: 1.800.294.4667
Web: www.hoopsincorporated.com
FAX: (281) 357-4822
Please provide model number, serial number, and/or part number
of the product and/or part when you call, write or email. These
numbers can be found on the product, packaging, or in this owner's
manual.
Read this manual all the way through before starting to put up
your pole. Then read each step completely before beginning
that step.
Gold
®
OWNERS
®
Hoops Incorporated
22047 Lutheran Church Rd.
Tomball, TX 77377
1

Advertisement

loading
Need help?

Need help?

Do you have a question about the Pro Dunk Gold PD-G-G and is the answer not in the manual?

Questions and answers

Summary of Contents for Hoops Pro Dunk Gold PD-G-G

  • Page 1 • ! Check unit before Toll Free: 1.800.294.4667 Hoops Incorporated each use for loose Web: www.hoopsincorporated.com 22047 Lutheran Church Rd. hardware, excessive FAX: (281) 357-4822...
  • Page 2: Bill Of Materials

    Bill of Materials Ref. Qty. Description Vertical Post Main Extension Arm Parallel Linkages H-Frame Backboard Mount Spring-Assist Cartridge Crank Adjustment Cylinder 14mm X 13cm Hex Bolt 14mm Lock Nuts 16mm X 31cm Hex Bolts 16mm X 28cm Hex Bolts 16mm Lock Nuts 16mm Anchor J-Bolts 16mm J-Bolt Hex Nuts Anchor Footing Template...
  • Page 3: Installation Instructions

    1. Prior to goal assembly, call utility services for location of underground utility lines before you dig. 2. NOTE: Immediately unpack all components and cross check against bill of materials. Report any shortages to Hoops Inc. customer service at 1.800.294.4667. 3. Assembly is a two part process.
  • Page 4 ANCHOR SYSTEM INSTALLATION INSTRUCTIONS (Day 1) 1. Choose the proper location to dig for the concrete footing. Use the distance chart in figure C to help you make your decision. When choosing the exact position to dig, make sure to maximize the amount of playing surface while minimizing possible driveway obstruction.
  • Page 5 NOTE: It is better to mix it slightly wet than too dry. 6. Insert the broomstick in 3 or 4 different places and vibrate up and down to settle the concrete. Submerge the four Anchor Footing Rebar (O) pieces into the center of the hole spaced evenly. Next set the anchor system into the wet concrete, vibrate it as it goes in to make sure the concrete fills in around the 16mm Anchor J-Bolts (L) hooks.
  • Page 6 PRO DUNK® ASSEMBLY INSTRUCTIONS (~Day 5) 7. Loosen the top four 16mm J-Bolt Hex Nuts (M) from the 16mm Anchor J- Bolts (L). Leave Anchor Footing Template (N) in place. 8. Put the 16mm Anchor J-bolt Washers (W) on each Anchor J-Bolt (L). 9.
  • Page 7 When you are satisfied with alignment, attach backboard to H-Frame Backboard Mount (D) at all points along the top and bottom of the board using the 8mm X 2.5cm Machine Screws (P), 8mm Flatwashers (Q), 8mm Lockwashers (R) and 8mm Hex Nuts (S) as shown in figure D. Tighten all 8mm hardware.
  • Page 8 22. If you’d like to restrict height adjustment from 10’ to 7’ you can optionally insert the Black Safety Rod And Pin (X) into the tube on the back of the Vertical Post (A). NOTE: It is advisable to do so to avoid injury...
  • Page 9 Installation Figures...
  • Page 11 Pro Dunk® Care Information BACKBOARD Items needed to clean backboard: • 100% cotton soft cloth, (only) • Mild dish washing liquid for soap • Luke warm water Cleaning Directions Rinse backboard with lukewarm water. Wash gently with a 100% Cotton soft cloth, lukewarm water and mild soap.
  • Page 12 (if not installed by our company. Hoops, Inc.), or use of this product. Nor does this warranty cover rusting or fading due to weather conditions, climate conditions, or exposure to corrosives such as salts, pesticides, etc.
