Bill of Materials
A (1) Vertical Post
B (1) 45 Degree Extension Arm
C (1) Mounting Plate
D (6) 5/8"x 7" Hex Bolt
E (6) 5/8" Hex Nut
F (6) 5/8" Flat washer
NOTE: Immediately unpack all components and cross check against bill of materials. Report any shortages to
Hoops customer service at 1-866-944-6677.
www.HoopsDallas.com 866-944-6677
Hoops Pro Dunk® Competitor
Assembly Instructions
G (6) 5/8" Lock washer
H (2) Backboard Frame Support
I (8) 3/8"x 1 ¼" Hex Bolt
J (8) 3/8" Flat washer
K (8) 3/8" Lock washer
L (8) 3/8" Hex Nut
Page 1
