AVProEdge AC-AUDEX-DIGI Quick Start Manual

150M Digital Audio Extender w/ Dolby® Digital & DTS®
Quick Start Guide
The AC-AUDEX-DIGI Digital Audio Extender is useful for sending the digital audio
signal up to 150m away at high quality. The units can switch between Coaxial
and Optical digital signals and can be powered by either USB or power adapter
allowing users flexibility of choice between power sources. With its elegant and
compact design, user friendly operation and easy installation, the Digital Audio
Extender is ideal tool for extending digital audio from one location to another.
This quick start guide will be going through:
•

Installation

• Product breakdown
• Troubleshooting
Installation
1. PLug in the 5 V power supply included with
the AC-AUDEX-DIGI to either the receiver or
transmitter. Or power the device on through USB.
2. Connect the audio source (Dvd player, cable box, gaming console) to the
transmitter via Optical in or Coax in.
3. Plug Cat6 Cable from the transmitter to the receiver.
4. Connect an amplifier or active speakers to the receiver via Optical out or
Coax out.
AC-AUDEX-DIGI
