Page 6: Chapter 2 Introduction
UNl-1': Chapter 2 Introduction This series of devices are economical, high-performance, multi-functional arbitrary waveform generators that use direct digital synthesis (DDS) technology to produce accurate and stable waveforms. UTG900 can generate accurate, stable, pure and low distortion output signals. UTG900's convenient interface, superior technical indexes and user-friendly graphical display style can help users to complete study and test tasks quickly and improves work efficiency. -
Page 7: Front Panel
UNl-1': 2.3 Panels and Buttons Introduction 2.3.1 Front Panel The product provides users with a simple, intuitive, and easy-to-use front panel, as shown below: 1 . Display screen 4.3 inches TFT color LCD screen distinguishes the output status, function menu and other key information of CH1 and CH2 by various colors. -
Page 9: Function Interface
UNl-1': 2.3.3 Function Interface As shown below: © 1. CH1 information, the selected channel will be highlighted. HighZ indicates the matched impedance of output terminal (10 to 9990 adjustable or high resistance; defaults to HighZ) riii1l!!: sine wave currently (Different modes have different menu) 2. - Page 12 UNl-1': 3.3.2 Frequency Counter This instrument can measure the duty ratio and frequency of TTL-compatible level signal, with frequency range of 1OOmHz-100MHz. When we use the frequency counter function, the TTL-compatible level signal inputs through an external digital modulation or frequency counter interface (INPUT/CNT connector) I , I Press Utility!➔...
- Page 15 UNl-1': • Set Carrier Wave Frequency Default frequency is 1 kHz. Different carrier waveform has different settable frequency range. Frequency Carrier UTG932E UTG962E waveform Maximum Minimum Maximum Minimum 1µHz 1µHz Sine wave 30MHz 60MHz Square wave 1µHz 1µHz 15MHz 20MHz 1µHz 1µHz Ramp wave...
- Page 17 UNl-1': 3) Set Waveform and Parameter of Carrier Wave Signal Press I Wavel➔ I square I to select the square wave as carrier waveform (default to sine wave). Press� to set the frequency, enter 10 by numeric keypad, and select the parameter unit � Press to set the amplitude, enter 200 by numeric keypad, and select the parameter unit lmVpp l .
- Page 35 UNl-1': 4.3.2 Select Arbitrary Wave UTG900 allows users to select build-in arbitrary waveform. In arbitrary wave function, users can select the arbitrary wave by multi-functional knob and direction keys or by pressing lwaveFile Ito select arbitrary waveforms as needed. List of built-in arbitrary wave: AbsSine AmpALT AttALT...
-
Page 37: Appendix A: Factory Reset State
UNl-1': Appendix A: Factory Reset State Parameter Factory default Channel parameters Current carrier wave Sine wave Output load High Sync output Channel output Channel output reverse phase Amplitude limit Upper amplitude limit +10V Lower amplitude limit -10V Fundamental wave Frequency 1kHz Amplitude 100mVpp... - Page 42 UNl-1': Frequency sweep Sine wave, square wave, ramp wave, arbitrary wave Carrier wave Type Linear or logarithmic Frequency sweep time 1 ms~500s ± 0.1 % Sync signal Output level TTL compatible Output frequency 1 µHz~2 MHz Output frequency 500, typical value Coupled mode Trigger input Input level...
