690 459/89475/26MM8682-B453
690 460/89482/26MM8682-t402
690 462/89468/26MM8682-M318
USE AND CARE GUIDE
WEStClIff
Questions, problems, missing parts? Before returning to the store,
call Home Decorators Collection Customer Service
8 a.m. - 7 p.m., EST, Monday - Friday, 9 a.m. - 6 p.m., EST, Saturday
1-800-986-3460
HomeDepot.Com/HomeDeCoRAtoRS
THANK YOU
We appreciate the trust and confidence you have placed in Home Decorators through the purchase of this electric fireplace. We strive to
continually create quality products designed to enhance your home. Visit us online to see our full line of products available for your home
imporvement needs. Thank you for choosing Home Decorators!

Advertisement

Table of Contents
loading

Related Manuals for Home Decorators Collection Westcliff

Summary of Contents for Home Decorators Collection Westcliff

  • Page 1 690 462/89468/26MM8682-M318 USE AND CARE GUIDE WEStClIff Questions, problems, missing parts? Before returning to the store, call Home Decorators Collection Customer Service 8 a.m. - 7 p.m., EST, Monday - Friday, 9 a.m. - 6 p.m., EST, Saturday 1-800-986-3460 HomeDepot.Com/HomeDeCoRAtoRS THANK YOU We appreciate the trust and confidence you have placed in Home Decorators through the purchase of this electric fireplace.

  • Page 2: Table Of Contents

    table of Contents Maximum load Warning ........... 2 Package Contents .............. 7 Safety Information ............. 3 Assembly ..............8 Warranty ..............5 Operation ..............16 Pre-Assembly ............. 6 fCC/IC Information ............18 Hardware Included ........... 6 Care & Cleaning ............18 Product Specifications ............

  • Page 3: Safety Information

    Safety Information Please read and understand this entire manual before attempting to assemble, operate or install the product. If you have any question regarding the product, please call customer service at service at 1-800-986-3460, 8 a.m.-7 p.m., EST, WARNING: Under no circumstances should this fireplace be Monday-Friday, 9 a.m.
  • Page 4 Safety Information (continued) NOtE: Use care in assembling your new fireplace. Take your time and use the hardware provided and a quality Phillips head screwdriver. Never overtighten bolts. • Do not sit on any part of the mantel. NOtE: To avoid injury from unexpected starting or electrical shock, do not plug the power cord into a source of power during unpacking and assembly.

  • Page 5: Warranty

    Warranty 1 Year Limited Warranty: The manufacturer warrants that your new Electric Fireplace is free from manufacturing and material defects for a period of one year from date of puchase, subject to the following conditions and limitations. Install and operate this appliance in accordance with the installation and operating instructions furnished with the product at all times.

  • Page 6: Pre-Assembly

    Pre-Assembly HARDWARE INCLUDED Part Description Part Number Quantity Shelf Pin PH-SPNPCSPLB2 Euro Hinge PH-HNGPC35AS95 Small Flathead Screw Camlock Bolt PH-KDBZNC002 Camlock PH-KDCZNC002 Metal Plate (Pre-attached) PH-PLBLK001 Screw PH-SCRBLK001 Wood Dowel PH-DWLNTL001 Leveler (Pre-attached) PH-LVRBLK001 Door Bumper PH-BMPCLR001 Knob (With screw) Cover Touch-up Pen NOtE:...

  • Page 7: Package Contents

    Pre-Assembly (continued) PACKAGE CONTENTS NOtE: All panels are labeled left and right as viewed from the front of unit. Part Description Quantity Base Assembly Left Front Panel Right Front Panel Left Center Panel Right Center Panel Top Front Panel Top Assembly Left Side Panel Right Side Panel Back Panel...

  • Page 8: Assembly

    Assembly Attaching the front panel Preparing the front panel Insert the Wood Dowels (HH) into the pre-drilled holes in Put the Left Front Panel (B) down on a flat surface. the Left Center Panel (D). Insert the Camlock Bolts (DD) into the pre-drilled holes, Align the Left Front Panel (B) and the using the Phillips Screwdriver.
  • Page 9 Assembly (continued) Preparing the base assembly Preparing the base assembly Insert the Wood Dowels (HH) into the pre-drilled holes in Insert the Camlock Bolts (DD) into the pre-drilled holes the Base Assembly (A). in the Base Assembly (A). Use the Phillips Screwdriver to tighten. Attaching the center panels Align the Left Center Panel (D) and the Left Front Panel (B) with the Base Assembly (A).
  • Page 10 Assembly (continued) Securing the panels To secure the Middle Front Panel (F) to the Left Front Panel (B), insert the Screws (GG) through the Metal Plate (FF) and turn clockwise to tighten. Repeat steps to secure the Middle Front Panel (F) to the Right Front Panel (C).
  • Page 11 Assembly (continued) Preparing the top assembly Preparing the top assembly Insert the Camlock Bolts (DD) through the pre-drilled Insert the Wood Dowels (HH) into the pre-drilled holes in holes in the Top Assembly (G). the Panels (D) (E) (F) (H) (I). Use the Phillips Screwdriver to tighten the Camlock Bolts (DD).
  • Page 12 Assembly (continued) Attaching the cover Attaching the back panels Peel the back off the Covers (LL) and place over the Insert the Screws (GG) through the pre-drilled holes in Camlocks (EE) screwed into the Panels (D) (E) (H) (I). the Back Panel (J). Preparing the doors Put the Left Door (K) on a flat surface.
  • Page 13 Assembly (continued) Attaching the knobs Insert the screws through the pre-drilled holes in the Right Door (L), to attach the Knobs (KK). Repeat for the Left Door (K). Attaching the doors Align the Right Door (L) with the Right Side Panel (I). Insert the Small Flathead Screws (CC) through the Euro Hinge (BB).
  • Page 14 Assembly (continued) Attaching the adjustable shelves Installing the fireplace insert into the mantel assembly Insert the Shelf Pins (AA) into the pre-drilled holes on Lift the Fireplace Insert (P) carefully into the back of the the inside of the Panels (D) (E) (H) (I). unit and center in the fireplace insert opening.
  • Page 15 Assembly (continued) Attaching the securing block Place the Securing Block (N) onto the Camlock Bolts (DD) and the Wood Dowels (HH). Insert the Camlocks (EE) into the pre-drilled holes. Turn clockwise with the Phillips Screwdriver to secure. Leveling the unit On the bottom side of each foot, are the Levelers (II).

  • Page 16: Operation

    Operation Operation NOtE: The control panel can be accessed at the upper-right corner of the insert. Fig . 1 Powering the fireplace Adjusting the flame Push the Power button to supply power to all There are 6 brightness levels that can be selected: functions of the fireplace and put the insert in a standby mode.
  • Page 17 Operation (continued) Replacing the remote control battery Disposing of used batteries The battery may contain hazardous substances that When the remote control stops operating or its range could endanger the enviroment and human health. seems reduced, it is time to replace the battery with new ones.

  • Page 18: Fcc/Ic Information

    fCC/IC Information WARNING: Changes or modifications to this unit not expressly approved by the party responsible for compliance could void user’s authority to operate the equipment. NOtE: This equipment has been tested and found to comply with the limits for Class B digital device, pursuant to part 15 of the FCC Rules.

  • Page 19: Troubleshooting

    troubleshooting PROBLEM ROOT CAUSE CORRECTIVE ACTION Unplug the fireplace, remove the back panel of the fireplace and check that the thermo- The thermostat sensor is stat is plugged into the main circuit board. Display shows " " broken or disconnected. If this does not solve the problem contact customer service for a replacement thermo- stat sensor.
  • Page 20 troubleshooting (continued) PROBLEM ROOT CAUSE CORRECTIVE ACTION Flame effect works but heater func- With the power on press and hold the POWER tion does not and the emberbed flashes button on the control panel for 10 seconds. The heater is disabled. when the Heater button is pressed.

  • Page 21: Replacement Parts

    Replacement Parts For replacement parts, call our customer service department at 1-800-986-3460, 8 a.m.-7 p.m., EST, Monday-Friday, 9 a.m. - 6 p.m., EST, Saturday. Part Description Qty. Flame Generator Drive Motor Thermostat Sensor Main Circuit Board Thermostat Heater/Blower Assembly Control Panel Circuit Board Control Panel Emberbed with Log Emberbed Circuit Board...
  • Page 22 Questions, problems, missing parts? Before returning to the store call Home Decorators Customer Service 8 a.m. - 7 p.m., EST, Monday - Friday, 9 a.m. - 6 p.m., EST, Saturday 1-800-986-3460 HOMEDEPOT.COM/HOMEDECORATORS RETAIN THIS MANUAL FOR FUTURE USE.
