Home Decorators Collection Elmhurst WSFP60ECHD-20 Assembly Instructions Manual
Home Decorators Collection Elmhurst WSFP60ECHD-20 Assembly Instructions Manual

Home Decorators Collection Elmhurst WSFP60ECHD-20 Assembly Instructions Manual

60 in. media console with infrared electric fireplace in brown twilight grey finish

Advertisement

Quick Links

OMSID # 207000465
Model # WSFP60ECHD-20
ASSEMBLY INSTRUCTIONS
Elmhurst 60 in. Media Console with Infrared Electric Fireplace
in Brown Twilight Grey Finish
Questions, problems, missing parts? Before returning to the store,
call Home Decorators Collection Customer Service
8 a.m. - 7 p.m., EST, Monday-Friday
9 a.m. - 6 p.m., EST, Saturday
1-800-986-3460
HOMEDEPOT.COM/HOMEDECORATORS
THANK YOU
We appreciate the trust and confidence you have placed in Home Decorators Collection through the purchase of this fireplace console.
We strive to continually create quality products designed to enhance your home. Visit us online to see our full line of products available
for your home improvement needs. Thank you for choosing Home Decorators Collection!

Advertisement

loading

Summary of Contents for Home Decorators Collection Elmhurst WSFP60ECHD-20

  • Page 1 THANK YOU We appreciate the trust and confidence you have placed in Home Decorators Collection through the purchase of this fireplace console. We strive to continually create quality products designed to enhance your home. Visit us online to see our full line of products available...
  • Page 2 Table of Contents Table of Contents ..............2 Hardware Included ............3 Safety Information ..............2 Package Contents ............4 Warranty ................2 Assembly................5 Pre-Assembly ............... 2 Care and Maintenance ............18 Planning Assembly ............2 Tools required ..............2 Safety Information Fits up to most 177.8 cm / 70 in.
  • Page 3 Pre-Assembly (continued) HARDWARE INCLUDED NOTE: Hardware not shown to actual size. Part Description Quantity Part Description Quantity Cam lock 35 + 1 extra Straight metal plate Cam bolt 35 + 1 extra L-shaped metal brace Long wood dowel 34 + 1 extra Door stopper Short wood dowel 4 + 1 extra...
  • Page 4 Pre-Assembly (continued) PACKAGE CONTENTS Part Description Quantity Part Description Quantity Top panel Right lower partition panel Center shelf Upper partition panel Bottom panel Fireplace insert cover Upper back panel Center crossbar Top crossbar Adjustable shelf Bottom back stretcher Lower back panel Bottom front stretcher Side door Bottom front molding...
  • Page 5 Assembly Attaching the top crossbar NOTE: Do not fully tighten all bolts until you finish assembling all parts. Once assembled, go back and fully tighten all bolts. This will make the assembly easier. Unpack the unit and confirm that you have all the hardware and required parts. Assemble the unit on a carpeted floor or □...
  • Page 6 Assembly (continued) Attaching the cam bolts and door stoppers Securely screw the cam bolts (BB) into the designated small holes on the center shelf (B) on both sides. Tighten with a □ Phillips screwdriver. Using the pilot holes as a guide, fasten two door stoppers (NN) to the center shelf (B) with four short wood screws (GG). □...
  • Page 7 Assembly (continued) Attaching the middle stiles Fasten one middle stile (S) to the left lower partition panel (K) with two long wood dowels (CC) and two cam locks (AA). □ Repeat the same procedure to combine the other middle stile (S) and right lower partition panel (L) together. □...
  • Page 8 Assembly (continued) Attaching the bottom stretchers Glue two long wood dowels (CC) into the inner holes of the bottom front stretcher (G) and attach it to the bottom panel □ (C) with three cam locks (AA). Repeat the same procedure to attach the bottom back stretcher (F) at the opposite end. □...
  • Page 9 Assembly (continued) Installing the side panels Glue ten long wood dowels (CC) into the inner holes of the center shelf (B) and the bottom panel assembly at both ends. □ Align the large holes on both side panels (I and J) with the inserted wood dowels (CC) and press them together. Attach □...
  • Page 10 Assembly (continued) Attaching the bottom front molding Align and attach the bottom front molding (H) to the bottom front stretcher (G) with four short wood dowels (DD) and □ eight medium wood screws (FF). Installing the triangle metal plates Using the pilot holes as a guide, fasten two triangle metal plates (QQ) at the bottom joints between the bottom front □...
  • Page 11 Assembly (continued) Screwing the floor levelers Screw two floor levelers (RR) into the installed triangle metal plates (QQ). □ Attaching the upper partition panel Insert one long wood dowel (CC) into the middle hole of the upper partition panel (M) and attach it to the center shelf (B) □...
  • Page 12 Assembly (continued) Attaching the top panel Insert five long wood dowels (CC) into the top inner holes on upper side panels (I and J) and partition panel (M). Position □ the top panel (A) onto the inserted wood dowels (CC) and fasten it in place with six cam locks (AA). Installing the metal plate Flip the assembled unit around at its front edges.
  • Page 13 Assembly (continued) Attaching the back panels Pick up the upper back panel (D) and align the drilled holes against the upper long edge with the pilot holes on the back □ stretcher of the top panel (A). Attach the back panel (D) in place using the provided washer head screws (HH). Align and attach two lower back panels (Q) to the lower side panels and partition panels (I, J, K and L) with the provided □...
  • Page 14 Assembly (continued) Installing the doors Stand the assembled unit upright. □ Pick up one door (R) and attach the extended hinge arms to the hinge bases installed on the left side panel (I). Loosen □ the bolt on the back of the hinge base for an easy fit. Align and insert the “U” slot on the hinge arm under the bolt head on the back of the hinge base.
  • Page 15 Assembly (continued) Installing the fireplace insert Lift the fireplace insert carefully into the back of the assembled mantel and center it in the opening. DO NOT drag the □ insert across the bottom panel (C) as it may scratch the unit. Attaching the L-shaped metal braces Using the pilot holes as a guide, align and attach two L-shaped metal braces (MM) to the bottom panel (C) by screwing □...
  • Page 16 Assembly (continued) Attaching the acrylic stopper Remove the paper backing of the acrylic stopper (SS). Then properly align the acrylic stopper into the cut-out on the □ acrylic stopper template on the front of the top panel (A). Press down on the acrylic stopper to help adhesion. At the back of the top panel (A), carefully pull out the thumb tacks to remove the acrylic stopper template.
  • Page 17 Assembly (continued) Installing the tipping restraint hardware WARNING: Young children can be seriously injured by tipping furniture. You must install the tipping restraint hardware with the unit to prevent the unit from tipping, causing any accidents or damage. The tipping restraints are intended only as a deterrent, they are not a substitute for proper adult supervision.
  • Page 18 Care and Maintenance A Touch-up Pen has been provided to repair any small nicks or scratches that may occur during assembly or shipping. To clean and care for your furniture: Use a soft, clean cloth that will not scratch the surface when dusting. □...
  • Page 19 Questions, problems, missing parts? Before returning to the store, call Home Decorators Collection Customer Service 8 a.m. - 7 p.m., EST, Monday-Friday 9 a.m. - 6 p.m., EST, Saturday 1-800-986-3460 HOMEDEPOT.COM/HOMEDECORATORS Retain this manual for future use.
