OMSID # 207000441
Model # WSFP60ECHD-19
ASSEMBLY INSTRUCTIONS
Montauk Shore 60 in. Media Console with Infrared Electric Fireplace
in Antique White & Medium Cherry Finish
Questions, problems, missing parts? Before returning to the store,
call Home Decorators Collection Customer Service
8 a.m. - 7 p.m., EST, Monday-Friday
9 a.m. - 6 p.m., EST, Saturday
1-800-986-3460
HOMEDEPOT.COM/HOMEDECORATORS
THANK YOU
We appreciate the trust and confidence you have placed in Home Decorators Collection through the purchase of this fireplace console.
We strive to continually create quality products designed to enhance your home. Visit us online to see our full line of products available
for your home improvement needs. Thank you for choosing Home Decorators Collection!

Advertisement

Table of Contents
loading

Summary of Contents for Home Decorators Collection WSFP60ECHD-19

  • Page 1 THANK YOU We appreciate the trust and confidence you have placed in Home Decorators Collection through the purchase of this fireplace console. We strive to continually create quality products designed to enhance your home. Visit us online to see our full line of products available...
  • Page 2: Table Of Contents

    Table of Contents Table of Contents ............... 2 Hardware Included ..............3 Safety Information .............. 2 Package Contents ..............4 Warranty ................2 Assembly ................5 Pre-Assembly ..............2 Care and Maintenance ............16 Planning Assembly ..............2 Tools required ................2 Safety Information Fits up to most 177.8 cm / 70 in. flat panel TVs Please read and understand these instructions before assembling Maximum load 61.2 kg / 135 lb and using this console.
  • Page 3: Hardware Included

    Pre-Assembly (continued) HARDWARE INCLUDED NOTE: Hardware not shown to actual size. Part Description Quantity Part Description Quantity Wood dowel 44 + 2 extra Medium wood screw 4 + 1 extra Cam lock 41 + 2 extra Cam lock cover 8 + 1 extra Cam bolt 41 + 2 extra Shelf pin...
  • Page 4: Package Contents

    Pre-Assembly (continued) PACKAGE CONTENTS Part Description Quantity Part Description Quantity Top panel Right upper side panel Center shelf Left upper partition panel Bottom panel Right upper partition panel Bottom back stretcher Adjustable shelf Bottom front molding Upper back panel Left lower side panel Middle crossbar Right lower side panel Middle stile...
  • Page 5: Assembly

    Assembly Screwing the cam bolts NOTE: Do not fully tighten all bolts until you finish assembling all parts. Once assembled, go back and fully tighten all bolts. This will make the assembly easier. Unpack the unit and confirm that you have all the hardware and required parts. Assemble the unit on a carpeted floor or the empty □...
  • Page 6 Assembly (continued) Assembling the cam bolts and magnetic catches Securely screw the cam bolts (CC) into the designated plastic bushings on the center shelf (B) on both sides. □ Align two magnetic catches (EE) to the pilot holes on the center shelf (B) with the magnetic plates facing the finished edge. Then attach □...
  • Page 7 Assembly (continued) Installing the bottom back stretcher Align and attach the bottom back stretcher (D) to the bottom panel (C) by using four wood dowels (AA) and four cam locks (BB). □ Attaching the lower partition panels Glue four wood dowels (AA) into the inner holes of the lower partition panels (H and I) and attach them to the bottom panel (C) by using □...
  • Page 8 Assembly (continued) Installing the lower side panels Glue six wood dowels (AA) into the inner holes of the bottom panel assembly at both ends. □ Align the large holes on both side panels (F and G) with the inserted wood dowels (AA) and press them together. Attach the side panels □...
  • Page 9 Assembly (continued) Installing the center shelf Glue eight wood dowels (AA) into the top inner holes of the previous assembly. □ Ask for assistance to position the center shelf (B) onto the inserted wood dowels (AA). Attach the center shelf (B) in place by □...
  • Page 10 Assembly (continued) Attaching the top panel Glue eight wood dowels (AA) into the top inner holes on the upper side panels (M and N) and partition panels (O and P). Position the top □ panel (A) onto the inserted wood dowels (AA) and fasten it in place with eight cam locks (BB). Attaching the bottom front molding Align and attach the bottom front molding (E) to the lower side panels (F and G) with four medium wood screws (KK).
  • Page 11 Assembly (continued) Installing the metal plate Flip the assembled unit around at its front edges. Fasten the middle crossbar (S) to the middle stiles (T) by attaching two metal plates □ (PP) at the joints, using two screws (HH) in each, as shown. Attaching the back panel Pick up the upper back panel (R) and align the pre-drilled holes against the upper long edge with the pilot holes on the back stretcher of □...
  • Page 12 Assembly (continued) Installing the adjustable shelves and cam lock covers Stand the unit upright. □ Insert four shelf pins (MM) into the holes at your desired height inside each side compartment. Tilt and rest the adjustable shelves (Q) □ onto the shelf pins (MM) and secure in place with the short wood screws (HH). Plug the cam lock covers (LL) onto the visible cam locks to conceal the cams.
  • Page 13 Assembly (continued) Installing the drawers To insert the drawers (U) into the frame, extend the ball bearing slide tracks on the upper side panels (M and N) and partition panels (O □ and P) all the way forward (including ball bearing cart). Align the slide runners on the drawers (U) with the slide tracks, and then push the drawer carefully inside until it stops.
  • Page 14 Assembly (continued) Attaching the L-shaped metal braces Using the pilot holes as a guide, align and attach two L-shaped metal braces (FF) to the bottom panel (C) by screwing one washer head □ screw (II) in each.
  • Page 15 Assembly (continued) Installing the acrylic stopper Remove the tape from the acrylic stopper (QQ) and place it in the cut-out of the acrylic stopper template on the top panel (A). Make sure □ that it is properly aligned before applying pressure. At the back of the top panel (A), carefully pull out the thumb tacks to remove the acrylic stopper template.
  • Page 16: Care And Maintenance

    Citrus oil based products can be obtained at supermarkets or hardware stores. Questions, problems, missing parts? Before returning to the store, call Home Decorators Collection Customer Service 8 a.m. - 7 p.m., EST, Monday-Friday 9 a.m. - 6 p.m., EST, Saturday 1-800-986-3460 HOMEDEPOT.COM/HOMEDECORATORS...
