SKU # 1001803998
Model # WSFP59HD-14
ASSEMBLY INSTRUCTIONS
Bellevue Park 59 in. Media Console with Infrared Electric Fireplace
in Dark Brown Cherry Finish
Questions, problems, missing parts? Before returning to the store,
call Home Decorators Collection Customer Service
8 a.m. - 7 p.m., EST, Monday-Friday
9 a.m. - 6 p.m., EST, Saturday
1-800-986-3460
HOMEDEPOT.COM/HOMEDECORATORS
THANK YOU
We appreciate the trust and confidence you have placed in Home Decorators Collection through the purchase of this fireplace console.
We strive to continually create quality products designed to enhance your home. Visit us online to see our full line of products
available for your home improvement needs. Thank you for choosing Home Decorators Collection!
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for Home Decorators Collection 1001803998
Summary of Contents for Home Decorators Collection 1001803998
- Page 1 THANK YOU We appreciate the trust and confidence you have placed in Home Decorators Collection through the purchase of this fireplace console. We strive to continually create quality products designed to enhance your home. Visit us online to see our full line of products...
- Page 2 Table of Contents Table of Contents ..............2 Hardware Included ............3 Safety Information ..............2 Package Contents ............. 4 Warranty ................2 Assembly ................5 Pre-Assembly ................ 2 Care and Maintenance ............16 Planning Assembly............2 Tools required ..............2 Safety Information Fits up to most 177.8 cm / 70 in.
- Page 3 Pre-Assembly (continued) HARDWARE INCLUDED NOTE: Hardware not shown to actual size. Part Description Quantity Part Description Quantity Wood dowel 44 + 2 extra Medium wood screw 4 + 1 extra Cam lock 43 + 2 extra Cam lock cover 8 + 1 extra Cam bolt 43 + 2 extra Shelf pin...
- Page 4 Pre-Assembly (continued) PACKAGE CONTENTS Part Description Quantity Part Description Quantity Top panel Right upper side panel Center shelf Left upper partition panel Bottom panel Right upper partition panel Bottom back stretcher Adjustable shelf Bottom front molding Upper back panel Left lower side panel Middle crossbar Right lower side panel Middle stile...
- Page 5 Assembly Screwing the cam bolts NOTE: Do not fully tighten all bolts until you finish assembling all parts. Once assembled, go back and fully tighten all bolts. This will make the assembly easier. □ Unpack the unit and confirm that you have all the hardware and required parts. Assemble the unit on a carpeted floor or the empty carton to avoid any scratches.
- Page 6 Assembly (continued) Assembling the cam bolts and magnetic catches □ Securely screw the cam bolts (CC) into the designated plastic bushings on the center shelf (B) on both sides. □ Align two magnetic catches (EE) to the pilot holes on the center shelf (B) with the magnetic plates facing the finished edge.
- Page 7 Assembly (continued) Installing the bottom back stretcher □ Align and attach the bottom back stretcher (D) to the bottom panel (C) with four wood dowels (AA) and four cam locks (BB). Attaching the middle crossbar □ Attach the middle crossbar (S) between the lower partition panels (H and I) by engaging two cam locks (BB), as shown.
- Page 8 Assembly (continued) Attaching the bottom panel assembly □ Glue four wood dowels (AA) into the inner holes of the lower partition panels (H and I) and attach them to the bottom panel (C) with four long wood screws (JJ). Installing the lower side panels □...
- Page 9 Assembly (continued) Installing the center shelf □ Glue ten wood dowels (AA) into the top inner holes of the previous assembly. □ Ask for assistance to position the center shelf (B) onto the inserted wood dowels (AA). Attach the center shelf (B) in place by engaging eleven cam locks (BB).
- Page 10 Assembly (continued) Attaching the top panel □ Glue eight wood dowels (AA) into the top inner holes on the upper side panels (M and N) and partition panels (O and P). Position the top panel (A) onto the inserted wood dowels (AA) and fasten it in place with eight cam locks (BB). Attaching the bottom front molding □...
- Page 11 Assembly (continued) Installing the metal plates □ Flip the assembled unit around at its front edges. Fasten the middle crossbar (S) to the middle stiles (T) by attaching two metal plates (PP) at the joints, using two short wood screws (HH) in each, as shown. Attaching the back panels □...
- Page 12 Assembly (continued) Attaching the adjustable shelves and cam lock covers □ Stand the unit upright. □ Insert four shelf pins (MM) into the desired holes inside each side compartment. Tilt and rest the adjustable shelves (Q) onto the shelf pins (MM) and secure in place with the short wood screws (HH). □...
- Page 13 Assembly (continued) Installing the drawers □ To insert the drawers (U) into the frame, extend the ball bearing slide tracks on the upper side panels (M and N) and partition panels (O and P) all the way forward (including ball bearing cart). Align the slide runners on the drawers (U) with the slide tracks, and then push the drawer carefully inside until it stops.
- Page 14 Assembly (continued) Attaching the L-shaped metal braces □ Using the pilot holes as a guide, align and attach two L-shaped metal braces (FF) to the bottom panel (C) by screwing one washer head screw (II) in each. Installing the acrylic stopper □...
- Page 15 Assembly (continued) Installing the tipping restraint hardware WARNING: Young children can be seriously injured by tipping furniture. You must install the tipping restraint hardware with the unit to prevent the unit from tipping, causing any accidents or damage. The tipping restraints are intended only as a deterrent, they are not a substitute for proper adult supervision.
- Page 16 Citrus oil based products can be obtained at supermarkets or hardware stores. Questions, problems, missing parts? Before returning to the store, call Home Decorators Collection Customer Service 8 a.m. - 7 p.m., EST, Monday-Friday 9 a.m. - 6 p.m., EST, Saturday 1-800-986-3460 HOMEDEPOT.COM/HOMEDECORATORS...
