- Page 1 Home Decorators Collection BF-22418 OXFORD COLLECTION ONE DRAWER END TABLE ASSEMBLY INSTRUCTIONS Made In China...
-
Page 2: Important Note
Thank you purchasing this quality produst.Be sure to check all packing material carefully for small parts,which may have came loose inside the carton during shipment. Count all parts and material hardware,Compare with parts list to be sure all part are present.If any parts are missing or damaged,phone,fax,or mail to our Customer Service Department.For efficient and speedy service please indicate the model number and code letter of part(s)need... - Page 3 CAM-BOLTS-10PCS SCREWS-14PCS DOWELS-6PCS SCREWS-1PC CAM-TOOL-1PC SCREWS-1PC KNOB-1PC SHELF SUPPORT-4PCS LOW PANEL-1PC REAR PANEL GUIDE-1PC SCREWS-10PCS...
- Page 4 NOTE: UPON OPENING THOROUGHLY CLEAN ALL WOODS SURFACES TO REMOVE DUST AND DIRT THAT MAY HAVE SETTLED ONTO FINISH DURING SHIPMENT.IN ORDER TO PREVENT DAMAGE DURING ASSEMBLY,PLEASE ASSEMBLE THIS ITEM WITH AT LEAST TWO PEOPLE. NOTE: TURN THE CAM-BOLT SCREWS UNTIL THEY ARE TIGHT, THE SHOULDER SHOULD BE AGAINST THE SURFACE OF THE PART.
- Page 5 2).ASSEMBLE THE SIDE PANEL(B/C). ATTACH LOW PANEL(V)TO BOTTOM PANEL(D)USING SCREW(R). INSERT THE 6 DOWELS(P)INTO HOLES IN ACROSS PANEL(F)AND LOW PANEL(V). ROTATE THE CAM-BOLTS(N)INTO HOLES IN SIDE PANEL(B/C). PLACE CAM-BOLTS(N)INTO HOLES IN PANEL(F/D)AND ATTACH USING 10 CAM-LOCKS(M).
- Page 6 3).ASSEMBLE THE TOP PANEL(A). ROTATE THE CAM-BOLTS(N)INTO HOLES IN TOP PANEL(A). PLACE CAM-BOLTS(N)INTO HOLES IN SIDE PANEL(B/C)AND ATTACH USING CAM-LOCKS(M). INSER THE SHELF SUPPORTS(T)INTO HOLES IN SIDE PANEL(B/C).
