Spirent GSS7000 Quick Start Manual

PDF copies of all Spirent user documents are installed in the default documentation folder
1
Check contents of all boxes
Check the contents of each box against Spirent's packing list.
Remove all packing and inspect equipment for damage.
If any item is missing or damaged, please advise Spirent.
For contact details refer to Spirent Support Services
Positioning Quick Guide (66-000314).
4
Connect keyboard and mouse
For keyboard and mouse connection, Spirent
recommends using the USB 2.0 ports (black inserts).
71-008079 Rev. A1
June 2017
GSS7000 QUICK START GUIDE
D:\posapp\software\<version>\gui\Docs
REMOTE Ethernet port
Use for general network and internet connections.
Connect remote control PC to this port.
Can have a Static or DHCP IP address.
2
Connect to AC Power
100 to 240 V
50 to 60 Hz
Switch on at step
3
Connect monitor to DisplayPort
Now see 5 to 7
over
5
© 2017 Spirent Communications
Document status: Approved
