1. Snap the locking bracket onto the power cable.
2. Insert the power cable into the PCIe Adapter's power port.
3. Confirm that the power cable is well connected.
4. Slide the locking bracket forward and clip it on the beveled rim on PCIe Adapter.
Step 4 - Connect cables
Connect the cables to PCIe Adapter:
Ethernet*: Device configuration
SFF-8644: Data
Lyve Mo bile Mo unt and PCIe Adapter - Fro nt Lo ader
3/21/22
13
