Remove The Motor
REPAIR MANUAL
1
Advertisement
Table of Contents
Related Manuals for SWELLPRO SPLASHDRONE 3
Summary of Contents for SWELLPRO SPLASHDRONE 3
- Page 1 Step 1: the casing after removing the motor..............2 Step 2: remove the screws of the gland ................3 Step 3: remove the silicon pieces ................... 4 Step 4: remove the screws which used for fixed motor ..........5 Swellpro Technology Co., Ltd.
-
Page 2: Step 1: The Casing After Removing The Motor
REPAIR MANUAL Step 1: the casing after removing the motor. Swellpro Technology Co., Ltd. -
Page 3: Step 2: Remove The Screws Of The Gland
REPAIR MANUAL Step 2: remove the screws of the gland Tool: cross screwdriver #1 Please remove the 4 screws of the gland Swellpro Technology Co., Ltd. -
Page 4: Step 3: Remove The Silicon Pieces
REPAIR MANUAL Step 3: remove the silicon pieces Pull a little bit hardly to remove the silicon pieces Swellpro Technology Co., Ltd. -
Page 5: Step 4: Remove The Screws Which Used For Fixed Motor
Step 4: remove the screws which used for fixed motor Tool: hexagonal screwdriver 2.0 Use the hexagonal screwdriver to remove the screws, there is some glass cement on the screws, can be moved by the screwdriver Swellpro Technology Co., Ltd.
