SECTION A - GENERAL INFORMATION
1. PRINCIPAL CHARACTERISTICS
1.1 APPLIANCE CLASSIFICATION
The F-FR-FC-FCR fan heaters are defined as
"air treatment terminals for winter and summer
air conditioning".
1.2 EC CONFORMITY - CERTIFICATION
The EC symbol guarantees that the appliance
conforms to EEC machinery directive EEC/98/
37, low tension directive EEC/73/23,
electromagnetic directive EEC/89/336 and any
subsequent amendments. The appliances have
the Eurovent certificates and the symbol
guarantees conformity to the data declared.
1.3 FUNCTIONAL DESCRIPTION
The fan heaters consist essentially of a system
of heat exchange between the liquid circulating
inside the exchanger (hot or cold water) and the
air flow controlled by a fan system. The outside
air is taken in by the fans and sent out to the heat
exchanger which heats the air in winter or cools
it in summer.
During the summer cycle,
depending on the heat-hygrometric conditions of
the outside air, water condensation is formed
and collected in the appropriate container so that
it can be disposed of.
The treated air is emitted through the appliance
grille or through the outlet units built in to the plant.
The appliances come as standard with fittings
for 2 pipes. For 4-pipe plants with two independent
circuits, there is an optional supplementary heat
exchange system. The fan heater has a remote
control (supplied separately). A choice can be
made from various available versions.
1.4 ASSEMBLY CHARACTERISTICS
1.4.1 Available versions
The fan heaters are available in 6 different sizes
and in the following versions:
FR
- Vertical with casing
For wall installation, under windows or in
any other free space or position which offers
technical or functional advantages.
FC - Horizontal with casing
For direct ceiling installation in all situations
where there is not enough free wall space.
FCO - Vertical built in
Supplied without any casing for invisible
installation in custom made panels and
connection to intake and output grilles and
outlets.
FCR - Horizontal built in
As above, supplied without casing for
invisible installation in panelling or dropped
ceiling.
For the F and FR versions, there is also a G
variation with frontal air intake grille complete
with filter.
1.4.2 Component characteristics
The support frame is made in zinc plate of an
appropriate thickness and comes with fixings
already in place for attaching the appliance to a
wall or ceiling with hooks and brackets as well as
mountings for the various components and
accessories. Internal surfaces are insulated
with closed-cell fireproof material.
The heat exchange system is for a 2-pipe plant
and consists of 3 rows of copper pipes with
continuous aluminium fins. The aluminium fin
pack is welded to the pipe surface by mechanical
expansion of the pipes themselves. The frame
is in stainless steel and the collectors in brass
alloy come with female attaching flanges of G 1/
2" and manual air bleed valves of G1/8". The
fan coil unit come as standard with plumbing
attachments on the left side.
The fan system consists of one (sizes 100 and
200) or two centrifugal double-aspiration fans.
They have a high air capacity and low noise level
with blades and screws in plastic. The system
is electronically balanced before and after being
mounted in the unit.
pag. 3
