Chamberlain LM3800W Manual

Wall mount residential wi-fi garage door opener
Hide thumbs Also See for LM3800W:
Table of Contents

Advertisement

Quick Links

Download this manual
en
Wall Mount Residential Wi-Fi
de
Wi-Fi
Wand-Garagentorantrieb für en Privatgebrauch
®
fr
Système d'ouverture Wi-Fi
nl
Wi-Fi
®
-garagedeuraandrijving voor uw garage
da
Wall Mount Residential Wi-Fi
no
Veggmontert for boliger Wi-Fi
sv
Väggmonterad Wi-Fi
®
pl
®
cs
sl
it
es
Abridor de puerta de garaje residencial Wi-Fi
hu
Seinälle asennettava asuintalojen Wi-Fi
sk
®
rus
hr
ro
is
Veggfestur Wi-Fi
®
Garage Door Opener
®
®
pour portes de garage, montage mural, pour particuliers
Garageportåbner
®
®
Garasjeportåpner
-garageportöppnare för hemmabruk
®
de montaje en pared
®
®
-autotallinoven avaaja
®
®
®
con montaggio a muro
®
"
®
LM3800W

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the LM3800W and is the answer not in the manual?

Questions and answers

Related Manuals for Chamberlain LM3800W

Summary of Contents for Chamberlain LM3800W

  • Page 1 LM3800W Wall Mount Residential Wi-Fi Garage Door Opener ® Wi-Fi Wand-Garagentorantrieb für en Privatgebrauch ® Système d’ouverture Wi-Fi ® pour portes de garage, montage mural, pour particuliers Wi-Fi ® -garagedeuraandrijving voor uw garage Wall Mount Residential Wi-Fi Garageportåbner ® Veggmontert for boliger Wi-Fi ®...

  • Page 2: Table Of Contents

    Note: The original installation and operating instructions were compiled in English. Any other available language is a translation of the original English version. General Safety Guidelines....................................3 Intended Use ........................................4 Planning Door Operation....................................4 Planning for MyQ Operation....................................4 Preparing Your Garage Door.....................................5 Tools Needed........................................5 Carton Inventory........................................5 Required Accessories......................................5...

  • Page 3: General Safety Guidelines

    WARNING! START BY READING THESE IMPORTANT SAFETY INSTRUCTIONS! General Safety Guidelines Before you begin the installation: Please read the operating instructions and especially the precautions. Keep the manual for future reference and pass it on to a possible subsequent owner. The following symbols are placed in front of instructions to avoid personal injury or property damage. Read these instructions carefully. CAUTION CAUTION Personal injury or property damage...

  • Page 4: Intended Use

    • technician. • Operation of the emergency release can lead to uncontrolled movements of the door, if springs are weak or broken or if the door is unbalanced. • Mount the release handle of the emergency release at a height less than 1.80 m. •...

  • Page 5: Preparing Your Garage Door

    Drill Bits Pencil Carton Inventory If anything is missing, carefully check the packing material. GARAGE DOOR OPENER HARDWARE BAG Garage Door Opener, LM3800W Screw 15 mm Automatic Garage Door Lock, 841EU Screw 54.8 mm Mounting Bracket Handle Collar with Set Screws...

  • Page 6: Attach The Collar To The Garage Door Opener

    Attach the Collar to the Garage Door Opener The garage door opener can be installed on either side of the door (see Planning section). The illustrations shown are for installation on the Illustations Sheet. 1. Loosen the set screws. 2. Attach collar to the garage door opener motor shaft. The side of the collar with the larger hole should be placed on the motor shaft. 3.

  • Page 7: Install The Automatic Door Lock

    Install the Automatic Door Lock The automatic door lock (model 841EU) is used to prevent the door from being manually opened once the door is fully closed. NOTE: Older model 24 V door locks are incompatible. 1. The lock must be mounted within 3.05 m of door opener. If possible, mount on same side as door opener. 2.

  • Page 8: Install Myq Remote Led Light (Designed For Dry Areas Only)

    Install MyQ Remote LED Light (designed for dry areas only) The MyQ Remote LED Light is designed to plug directly into a standard 230V outlet. Select an appropriate location on the ceiling or wall to mount the light within 1.83 m of an electrical outlet so that the cord and light are away from moving parts. MyQ Remote LED Light installation is required to enable MyQ and Timer-to-Close (TTC) operation.

  • Page 9: Connect Power

    Connect Power There is only one option for connecting power: TYPICAL WIRING Plug in the garage door opener into a grounded outlet. Install the Battery Backup (Optional accessory) To reduce the risk of FIRE or INJURY to persons. Disconnect ALL electric and battery power BEFORE performing ANY may explode.

  • Page 10: Program The Travel

    Program the Travel Incorrect adjustment of garage door travel limits will interfere with proper operation of safety reversal system. After ANY adjustments are made, the safety reversal system MUST be tested. Door MUST reverse on contact with 40 mm object on Travel limits regulate the points at which the door will stop when moving up or down.Unplug the garage door opener.

  • Page 11: To Open The Door Manually

    To Open the Door Manually If possible, use emergency release handle to disengage door ONLY when garage door is CLOSED. Weak or broken springs or unbalanced door could result in an open door falling rapidly and/or unexpectedly. NEVER use emergency release handle unless garage doorway is clear of persons and obstructions.
  • Page 12 MyQ allows you to control your garage door opener from your mobile device or computer from anywhere. MyQ technology uses a radio signal to provide two way communication between the garage door opener and MyQ enabled accessories. The garage door opener has an internal gateway that allows the garage door opener to communicate directly with a home Wi-Fi network and access your MyQ account.

  • Page 13: Connect With Your Smartphone

    Connect With Your Smartphone The Wi-Fi Garage Door Opener is compatible with up to 16 MyQ enabled accessories. Up to 10 devices can be paired to the Wi-Fi garage door ® opener’s internal gateway. These devices can be controlled with the MyQ app. These devices include any combination of MyQ garage door openers, Wi-Fi garage door openers, MyQ light, MyQ gate operators.

  • Page 14: Program Your Opener And Remote / The Wireless Push Button/ / Wireless Keypad (Optional)

    Program Your Opener And Remote / The Wireless Push Button/ / Wireless Keypad (Optional) Activate the opener only when door is in full view, free of obstruction and properly adjusted. No one should enter or leave garage while door is in motion. Do not allow children to operate push button(s) or remote(s). Do not allow children to play near the door. Your garage door opener receiver and one of the buttons remote control are pre-programmed.

  • Page 15: To Erase The Memory

    To Erase the Memory ERASE ALL REMOTE CONTROLS AND KEYLESS ENTRIES Press and hold the LEARN button (L) on garage door opener until the learn LED goes out (approximately 6 seconds). All remote control and keyless entry codes are now erased. Reprogram any accessory you wish to use. ERASE ALL DEVICES (INCLUDING MYQ ENABLED ACCESSORIES) 2.

  • Page 16: Disposal

    Disposal The packaging must be disposed of in the local recyclable containers. According to the European Directive 2002/96/EC on waste electrical equipment, this device must be properly disposed of, after usage in order to ensure a recycling of the materials used. Old accumulators and batteries may not be disposed of in the household waste, since they contain pollutants and must be properly regulations must be adhered to.

  • Page 17: Troubleshooting

    DIAGNOSTIC CODE SYMPTOM SOLUTION Up Arrow Down Arrow Flash(es) Flash(es) Door is moving stops and or Manually open and close the door. Check for binding or obstructions, such reverses. as a broken spring or door lock, correct as needed. If the door is binding or sticking contact a trained door systems technician.
  • Page 18 The door reverses for no apparent reason and garage door opener lights don’t blink: • Check that cable tension monitor is correctly installed. If one of the cable tension monitors is removed, unplug both monitors from the opener. Then plug in the monitor you wish to use and unplug and plug in the opener three times to relearn the monitor to the opener. The 1k resistor provided is for trouble shooting the CTM set up only.

  • Page 19: Optional Accessories

    Optional Accessories Always use LiftMaster accessories. External products can cause malfunctions. TX4UNIF 4-channel universal remote control TX4EVS 4-channel remote control TX4UNI/S 4-channel universal remote control 128EV Wireless Wall Control 2-Channel 747EV Keypad 78EV Wired multi-functional wall control FLA-1LED Flashing light 772E Photocells 100034...

  • Page 20: Automatic Garage Door Opener Safety & Maintenance Guide

    Automatic Garage Door Opener Safety & Maintenance Guide GARAGE DOOR OPENER SAFETY – AN AUTOMATIC DECISION A garage door is the largest moving object in the home. An improperly adjusted garage door and opener can exert deadly force when the door closes –...

  • Page 21: Routine Maintenance Can Prevent Tragedies

    Routine Maintenance Can Prevent Tragedies Make monthly inspection and testing of your garage door and opener system a part of your regular routine. Review your owner’s manual for both the opener model number on the back of the power unit. WARNING –...
