Step 3 - PLC Setup
(For TCP/IP Passthrough, see below.)
TCP/IP Passthrough
For more information, please access the InView context-sensitive online help by
clicking on the blue button in the upper right corner of the user interface.
Please visit our website for links to the InView user manual, data sheets, install
guides, software guides, and add-on instructions.
www.spectrumcontrols.com/InView.html
1705 132nd Ave NE, Bellevue, WA 98005
Telephone : +1 (425) 746-9481 Email: spectrum@spectrumcontrols.com
Specifications subject to change without notice. Printed in USA
Copyright ©2015 Spectrum Controls, Inc., all rights reserved. Part No. 0100249-04 Rev 9/2015
Open PLC
Select your PLC and enter its
IP address.
Enter your PLC server tag
values.
Check the enable polling box.
Note: Both message and
variable tags must exist on
the PLC controller.
Open PLC
For TCP/IP passthrough,
select "Passthrough" for the
Msg Server Type.
Set the TCP Port
