COLOR GPS/PLOTTER/SOUNDER
System Configuration ............................................. i
Equipment Lists ..................................................... ii
1.1 Installation of Display Unit .............................................. 1-1
1.3 Installation of Transducers ............................................... 1-4
1.4 Installation of Sensors .................................................... 1-14
2. Wiring ...............................................................2-1
3. Initial Settings ..................................................3-1
3.1 NMEA Setting .................................................................. 3-1
3.2 Output Data Sentences ..................................................... 3-3
3.3 Antenna Height ................................................................. 3-4
3.4 Baud Rate Setting (GP-1650DF only).............................. 3-5
3.6 Depth Adjustment ............................................................. 3-7
3.7 External Equipment Setup (Option) ................................. 3-8
(for GP-1650F) .................................................4-1
PACKING LIST .................................................... A-1
OUTLINE DRAWINGS ......................................... D-1
INTERCONNECTION DIAGRAM ........................ S-1
SCHEMATIC DIAGRAM ...................................... S-2
INSTALLATION MANUAL
GP-1650F/1650DF

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the GP-1650F and is the answer not in the manual?

Questions and answers

Related Manuals for Furuno GP-1650F

Summary of Contents for Furuno GP-1650F

  • Page 1: Table Of Contents

    3.5 Beacon frequency Setting (GP-1650DF only) ....3-6 3.6 Depth Adjustment ............. 3-7 3.7 External Equipment Setup (Option) ......... 3-8 4. Installation of DGPS Beacon Receiver (for GP-1650F) ..........4-1 APPENDIX TRIDUCER 525ST-PWC/PWD ..AP-1 PACKING LIST ............ A-1 OUTLINE DRAWINGS ......... D-1 INTERCONNECTION DIAGRAM ......
  • Page 2 *00080856801* *00080856801* *00080856801* *00080856801* ( ( TATA TATA ) ) GP-1650F/1650DF GP-1650F/1650DF * 0 0 0 8 0 8 5 6 8 0 1 * * 0 0 0 8 0 8 5 6 8 0 1 * *IME43942N00* *IME43942N00*...
  • Page 3 Do not remove the label. If the label is missing or illegible, contact When handling the transducer cable, a FURUNO agent or dealer. keep in mind the following points. • Keep the cable away from oil and Name: Warning Label (1)

  • Page 4: System Configuration

    System Configuration The GP-1650F/1650DF mainly consists of a display unit, a GPS an- tenna and a dual frequency transducer. A DGPS beacon receiver is provided inside the display unit for GP-1650DF type. The chart card drive in the display unit loads electronic charts. External equipment which can be connected include water temperature and speed sen- sors, autopilot, and DGPS beacon receiver.

  • Page 5: Equipment Lists

    Equipment Lists Standard supply s t r l l a i t a 4 1 0 - 0 1 , r e . t n Optional equipment GR-7000A, Whip ant. R-7000A -7000A . t n -7000A -7000A -7000A MJ-A7SPF0003-050 l i a...
  • Page 6 Optional equipment (con't) 525ST-MSD 000-015-263 000-015-261 525ST-PWD r te f i t r e i 00RAM02MC-004 RAM Card 004-371-790 DGPS Beacon for GP-1650F GR-80 Receiver...

  • Page 7: Installation Of Standard Equipment

    1. Installation of Standard Equipment 1.1 Installation of Display Unit Mounting considerations The display unit can be installed on a tabletop, on the overhead or flush mounted in a console or panel. Hard Cover Tabletop Overhead Figure 1-1 Tabletop, overhead mounting methods When selecting a mounting location for the display unit keep the fol- lowing in mind: •...
  • Page 8 Mounting procedure Follow the procedure below to mount the display unit on a tabletop or the overhead. Tabletop, overhead mounting 1. Fix the hanger by four pan head screws M5 X 16. 2. Screw knob bolts in display unit, set it to hanger, and tighten knob bolts.

  • Page 9: Installation Of Antenna Unit (Gp-1650Df Only)

    216±1 6-R2.25 164±0.5 Pan head screws Flush mount Figure 1-3 Flush mounting of display unit 1.2 Installation of Antenna Unit (GP-1650DF only) Mounting considerations Install the antenna unit referring to the installation diagram on page D-3 or D-4. When selecting a mounting location for the antenna unit, keep in mind the following points: •...

  • Page 10: Installation Of Transducers

    1.3 Installation of Transducers Installing the inside-hull mount transducer Necessary tools You will need the following tools: • Sandpaper (#100) • Silicone sealant • Silicone grease Remarks on installation • Do the installation with the boat hauled out of the water. •...
  • Page 11 Attaching the transducer 1. Clean the transducer face to remove any foreign material. Lightly roughen the transducer face with #100 sandpaper. Also, roughen the inside of the hull where the transducer is to be mounted. 2. Warm the silicone sealant to 40°C before usage to soften it. Coat the transducer face and mounting location with silicone sealant.
  • Page 12 Observing the picture 1. Press the [POWER] key to turn on the display unit. 2. Press the [SNDR] key to select the sounder display. 3. Press the soft key labeled "MODE/FREQ" to display the follow- ing message. MODE/FREQ AUTO (CRUSING) AUTO (FISHING) MANUAL Figure 1-8 MODE FREQ selection screen...
  • Page 13 SOUNDER °C RANGE GAIN SHIFT MODE/ FREQ 32.8 SNDR DGPS 3D FUNC Figure 1-10 Video sounder picture If the bottom is displayed in red and the light-blue color appears the mounting location is suitable. You can leave the transducer in position.
  • Page 14 Installing the thru-hull mount transducer Transducer mounting location This type of mounting provides the best performance of all, since the transducer protrudes from the hull and the effect of air bubbles and turbulence neat the hull skin is reduced. When the boat has a keel, the transducer should be at least 30 cm away from it.
  • Page 15 Acceptable transducer mounting locations Deep-V hull • Position 1/2 to 1/3 length of the hull from stern • 15 to 30 cm off center line (inside first lifting strakes). Figure 1-12 Transducer mounting location on deep-V hull High speed V-planing hull •...
  • Page 16 Procedure for installing the thru-hull mount transducer 1. With the boat hauled out of the water, mark the location selected for mounting the transducer on the bottom of the hull. 2. If the hull is not level within 15° in any direction, fairing blocks made out of teak should be used between the transducer and hull, both inside and outside, to keep the transducer face parallel with the water line.
  • Page 17 Installing the transom mount transducer This type of mounting is very commonly employed, usually on rela- tively small I/O or outboard boats. Do not use this method on an inboard motor boat because turbulence is created by the propeller ahead of the transducer. There are two methods of installation: flush with hull (for flat hulls) and projecting from hull (for deep V-hulls).
  • Page 18 M5 x 20 M5 x 20 5° Tape No. 1 M5 x 14 Figure 1-17 Transom mount transducer, mounting flush with hull Installing the transom mount transducer projecting from hull (for deep-V hulls) This method is employed on deep-V hulls and provides good perfor- mance because the effects of air bubbles are minimal.
  • Page 19 Triducer 524ST-MSD, 525ST-MSD The triducer is designed for thru-hull mounting. Mounting considerations When selecting a mounting location keep the following points in mind: • Air bubbles and turbulence caused by movement of the boat seri- ously degrade the sounding capability of the transducer. The trans- ducer should, therefore, be located in a position where water flow is the smoothest.

  • Page 20: Installation Of Sensors

    1.4 Installation of Sensors Transom mount water temperature sensor T-02MTB • Fix the cable at a convenient location with cable clamp. • When the cable is led in through the transom board, make a hole of approx. 17 mm diameter to pass the connector. After passing the cable, fill the hole with a sealing compound.
  • Page 21 Thru-hull mount water temperature sensor T-02MSB, T-03MSB • Select a mid-boat flat position. The sensor does not have to be installed perfectly perpendicular. The sensor must not be damaged in dry-docking operation. • Select a place apart from equipment generating heat. •...
  • Page 22 Through-hull mount water temperature/speed sensor ST-02MSB, ST-02PSB Select a suitable mounting location considering the following: • Select a mid-boat flat position. The sensor does not have to be installed perfectly perpendicular. The sensor must not be damaged in dry-docking operation. •...

  • Page 23: Wiring

    12-24 DGPS NMEA ANTENNA UNIT External equipment DGPS beacon receiver White Black (option for GP-1650F, Shieled GPA-019 RS-232C only) (GP-1650DF) TRANSDUCER Figure 2-1 Display unit, rear view Power cable Connect the power cable to the power connector. Connect the leads to the battery (12 or 24 VDC);...
  • Page 24 Antenna unit Connect the antenna unit cable to the ANT connector. Transducer Connect the transducer cable to the XDR connector. Connect the water temperature sensor (option) or water temperature/speed sensor (op- tion) to the XDR connector with the converter connector (Type : 02S4147, Code No.
  • Page 25 To connector at rear of display unit MJ-A10SPF Type : 02S4147 Code No. : 000-141-082 MJ-A6SRMD MJ-A10SRMD Water temp., water temp/speed Transducer connector sensor connector Figure 2-5 Connection of transducer, water temperature sensor, water temperature/speed sensor Ground The display unit CAUTION contains several CPUs.
  • Page 26 Extending antenna cable length The standard cable is 10m long. For extension, in case of the GPA- 016, GPA-018S or GPA-019S, an antenna cable set of 30m or 50m is available. Extension cable line-up Fabricate the end of the antenna cable and attach the coaxial con- nector.
  • Page 27 How to attach the N-P-8DFB connector Dimensions in millimeters. Outer Sheath Armor Inner Sheath Shield Remove outer sheath and armor by the dimensions shown left. Expose inner sheath and shield by the dimensions shown left. Cover with heat-shrink tubing and heat. Cut off insulator and core by 10mm.

  • Page 28: Initial Settings

    3. Initial Settings 3.1 NMEA Setting NMEA port 1. Press the [MENU] key. 2. Press the software key labeled "CONFIGURATION". 3. Press the software key labeled "SETUP NMEA PORT1". 4. Select "FORMAT" by the arrow key. 5. Press the software key labeled "EDIT" to display the following message.
  • Page 29 DGPS port 1. Press the [MENU] key. 2. Press the software key labeled "CONFIGURATION". 3. Press the software key labeled "SETUP NMEA/DGPS PORT2". 4. Select "FORMAT" by the arrow key. 5. Press the software key labeled "EDIT" to display the following message.

  • Page 30: Output Data Sentences

    3.2 Output Data Sentences Select output data sentences for external equipment as follows. 1. Press the [MENU] key. 2. Press the software key labeled "CONFIGURATION". 3. Press the software key labeled "SETUP NMEA PORT1". 4. Press the software key labeled "SELECT SNTNC." to display the following list.

  • Page 31: Antenna Height

    3.3 Antenna Height 1. Press the [MENU] key. 2. Press the software key labeled "GPS/DGPS/TD OPTIONS". 3. Press the software key labeled "GPS SETUP OPTIONS". 4. Select "ANT. HEIGHT" by the arrow key. 5. Press the software key labeled "EDIT" to display the following message.

  • Page 32: Baud Rate Setting (Gp-1650Df Only)

    3.4 Baud Rate Setting (GP-1650DF only) 1. Press the [MENU] key. 2. Press the software key labeled "GPS/DGPS/TD OPTIONS". 3. Press the software key labeled "DGPS SETUP OPTIONS" to dis- play the following message. DGPS s FORMAT NMEA 0183 OPTION DGPS MODE VER 1.5 BEACON FREQUENCY...

  • Page 33: Beacon Frequency Setting (Gp-1650Df Only)

    3.5 Beacon frequency Setting (GP-1650DF only) 1. Press the [MENU] key. 2. Press the software key labeled "GPS/DGPS/TD OPTIONS". 3. Press the software key labeled "DGPS SETUP OPTIONS" to dis- play the following message. DGPS s FORMAT NMEA 0183 OPTION DGPS MODE VER 1.5 BEACON FREQUENCY...

  • Page 34: Depth Adjustment

    3.6 Depth Adjustment 1. Press the [MENU] key. 2. Press the software key labeled "DISPLAY OPTION". 3. Press the software key labeled "NEXT PAGE". 4. Select "DEPTH ADJ." by the arrow key. 5. Press the software key labeled "EDIT" to display the following message.

  • Page 35: External Equipment Setup (Option)

    3.7 External Equipment Setup (Option) This section shows you how to set up the GP-1650F/1650DF when external equipment is connected. If a water temperature/speed sensor is installed, you should complete this section with the boat in the water and running, to confirm speed/water temperature readout.
  • Page 36 Speed Adjustment Adjust speed when you select own speed source "OWN PDDWHL". 1. Press the [MENU] key. 2. Press the software key labeled "DISPLAY OPTIONS". 3. Press the software key labeled "NEXT PAGE" to display the Fol- lowing display. DISPLAY s SPEED SOURCE SETUP2 TEMP SOURCE...
  • Page 37 8. Press the [PLOT] key to finish. Temperature Adjustment 1. Press the [MENU] key. 2. Press the software key labeled "DISPLAY OPTIONS". 3. Press the software key labeled "NEXT PAGE" to display the fol- lowing display. DISPLAY s SPEED SOURCE SETUP2 TEMP SOURCE OWN XDCR...

  • Page 38: Installation Of Dgps Beacon Receiver (For Gp-1650F)

    4. Installation of DGPS Beacon Receiver (for GP-1650F) The DGPS beacon receiver GR-7000A can be incorporated in the GP-1650F to provide it with DGPS capability. Six installation kits are available as shown. GR-802-1650-10A-018 GR-802-1650-15A-018S GR-802-1650-10N-018 (No whip ant.) GR-802-1650-15N-018S (No whip ant.) GR-802-1650-10N-019 (No whip ant.)
  • Page 39 Disassembly Procedure 1. Turn off the power. Wait at least one minute before opening the cover, to allow capacitors to discharge. 2. Remove nuts attached to DGPS, NMEA and power supply connectors at the rear of the display unit. Nut, Washer COVER ASSEMBLY Screws X 6 B Screws X 6 A...
  • Page 40 Installation of DGPS receiver Procedure 1. Disconnect 8P connector as shown in the figure below. CHASSIS ASSEMBLY CONNECTOR A View PH8P J106 PANEL ASSEMBLY Figure 4-2 Dismounting chassis assembly 2. Dismount chassis assembly from panel assembly by disconnect- ing connector shown in the figure above. 3.
  • Page 41 Screws X 4 ANLG Board GN-7707 Mini pin coax. cable Heat sink Figure 4-4 Chassis assembly 5. Take off the mini pin coaxial cable from J2 on the GN-7707. 6. Open the lid of GR-7000A. 7. Connect the mini pin coaxial cable to J1 of GN-7000A. Mini pin coax.
  • Page 42 Pan-head Screw B M3X10, 4 pcs. Connect to J107 on MAIN Board Connect to Cable Assy. J8 on ANLG PH6P-W-L240 Board. Cover of GR-7000A S.FL2-2LPO.7-D-WHT (121) Notch Connect to J2 on GN-7707. Beacon Receiver Board GR-7000A Connect to J106 on MAIN Board.
  • Page 43 14. Mount the ANLG board on the heat sink. 15. Mount chassis assembly on the panel assembly. Connect 8P con- nector and 6P connector to Main board as shown in the figure below. CHASSIS ASSEMBLY CONNECTOR A View PH8P J106 PH6P J107 PANEL ASSEMBLY...
  • Page 44 Note: When reattaching the cover, confirm the following parts are attached. . Shield gasket, cover gasket (See figure 4-11.) . Connector gasket (See figure 4-1.) Cover gasket Shield gasket(1) Shield gasket (2) Figure 4-11 Gaskets...
  • Page 45 Checking the DGPS installation 1. Press the [MENU] key. 2. Press the software key labeled "CONFIGURATION". 3. Press the software key labeled "SYSTEM MENU". 4. Press the software key labeled "SELF TEST". 5. Press the software key labeled "MEMORY•I/O TEST" to display the following message.
  • Page 46 Connecting DGPS beacon receiver A DGPS beacon receiver whose output format is RS-232C can be connected to the GP-1650F. Below is the example of interconnection between the GP-1650F and FURUNO beacon receiver GR-80. GR-80 DATA GP-1650F DGPS (setting RS-232C) YELLOW...

  • Page 47: Appendix Triducer 525St-Pwc/Pwd

    APPENDIX TRIDUCER 525ST-PWC/PWD This appendix provides a copy of the installation instructions for AIRMAR triducer. If you loose the original supplied with the triducer, use this appendix. INSTALLATION INSTRUCTIONS ® Transom Mount Transducer or TRIDUCER Multisensor with Integral Release Bracket Model P66 U.S.
  • Page 48 APPENDIX TRIDUCER 525ST-PWC/PWD Caution: Never Use Solvents! Cleaners, gasoline, paint, sealants, and other products may contain P66 Installation template strong solvents such as acetone which can attack many plastics dramatically reducing their strength. for starboard side of boat Installation Drill at locations labeled "B" Bracket Cut out the installation template shown on the left.
  • Page 49 APPENDIX TRIDUCER 525ST-PWC/PWD Cable Routing Route the sensor cable over the transom, through a drain hole, or 2°-10° transom angle 11° transom angle 19°-22° transom angle NO SHIM thorough a new hole drilled in the transom above the waterline. shim with shim with taper down taper up...
