COLOR GPS/PLOTTER/SOUNDER
SAFETY INSTRUCTIONS....................................................................................................................I
SYSTEM CONFIGURATION ...............................................................................................................II
EQUIPMENT LISTS ...........................................................................................................................III
1. INSTALLATION..............................................................................................................................1
1.1 Installation of Display Unit........................................................................................................1
1.2 Installation of Antenna Unit ......................................................................................................4
1.3 Installation of Transducer.........................................................................................................5
1.4 Optional Speed/Water Temperature Sensor...........................................................................19
2. WIRING .......................................................................................................................................20
3. ADJUSTMENTS ..........................................................................................................................27
3.1 Display Settings .....................................................................................................................27
3.2 Navigator Settings .................................................................................................................31
3.3 I/O Port Settings ....................................................................................................................33
3.4 Sub Track Settings.................................................................................................................36
3.5 Echo Sounder Settings ..........................................................................................................38
3.6 Setting Transducer Model, Output Power ..............................................................................40
3.7 Connection of External Monitor..............................................................................................42
APPENDIX 1 INSTALLATION OF TEMPERATURE SENSORS ...................................................AP-1
PACKING LIST ................................................................................................................................ A-1
OUTLINE DRAWINGS .................................................................................................................... D-1
INTERCONNECTION DIAGRAM .................................................................................................... S-1
All brand and product names are trademarks, registered trademarks or service marks of their respective holders.
Installation Manual
Model
www.furuno.com
GP-3500F

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the GP-3500F and is the answer not in the manual?

Questions and answers

Related Manuals for Furuno GP-3500F

Summary of Contents for Furuno GP-3500F

  • Page 1: Table Of Contents

    Installation Manual COLOR GPS/PLOTTER/SOUNDER GP-3500F Model SAFETY INSTRUCTIONS........................I SYSTEM CONFIGURATION .......................II EQUIPMENT LISTS ...........................III 1. INSTALLATION..........................1 1.1 Installation of Display Unit......................1 1.2 Installation of Antenna Unit ......................4 1.3 Installation of Transducer......................5 1.4 Optional Speed/Water Temperature Sensor................19 2. WIRING ............................20 3. ADJUSTMENTS ..........................27 3.1 Display Settings ........................27...
  • Page 2 ・FURUNO Authorized Distributor/Dealer 9-52 Ashihara-cho, Nishinomiya, 662-8580, JAPAN A : JUL 2003 Printed in Japan All rights reserved. H : MAR . 17, 2017 Pub. No. IME-44212-H ( TEHI ) GP-3500F 0 0 0 1 4 6 7 8 3 1 7...

  • Page 3: Safety Instructions

    SAFETY INSTRUCTIONS WARNING CAUTION ELECTRICAL SHOCK HAZARD Observe the following compass safe Do not open the equipment distances to prevent interference to a unless totally familiar with magnetic compass: electrical circuits and service manual. Standard Steering compass compass Only qualified personnel Display 0.75 m 0.50 m...

  • Page 4: System Configuration

    Standard: GPA-019S Standard: GPA-017S Option: GPA-021S Option: GPA-019S*/GPA-020S/GPA-021S* *: DGPS position-fixing requires installation of the optional DGPS beacon For GP-3500F For GP-3500F-D receiver kit and the antenna unit GPA-019S or GPA-021S. Receives signal from GPS Receives signal from satellite and beacon reference station.

  • Page 5: Equipment Lists

    EQUIPMENT LISTS Standard supply Name Type Code No. Remarks GP-3500F — Display Unit w/DGPS beacon receiver GP-3500F-D — GPA-017S — For GP-3500F Antenna Unit GPA-019S — For GP-3500F-D 520-5PWD 000-015-126 Transducer 520-5MSD 000-015-212 520-5PSD 000-015-204 Choose one (600 W) Triducer (transducer...
  • Page 6 Option Name Type Code No. Antenna Cable CP20-01700 004-372-110 30 m, antenna cable extension CP20-01710 004-372-120 50 m, antenna cable extension Right Angle No.13-QA330 000-803-239 Antenna Base L-angle Antenna No.13-QA310 000-803-240 Base For mounting antenna unit Antenna Base for No.13-RC5160 000-806-114 Rail Mounting Mast Mounting Kit...
  • Page 7 GPA-020S — For GP-3500F Antenna Unit GPA-021S — *: Use of the extension cable may cause the following problems: Reduced detection ability Wrong ACCU-FISH™ information (fish length smaller than actual length, fewer fish detections, error in individual fish detection). Wrong speed data...

  • Page 8: Installation

    1. INSTALLATION NOTICE Do not apply paint, anti-corrosive sealant or contact spray to coating or plastic parts of the equipment. Those items contain organic solvents that can damage coating and plastic parts, especially plastic connectors. 1.1 Installation of Display Unit The display unit may be mounted on a desktop, overhead or flush mounted in a console.
  • Page 9 Mounting Desktop, overhead mounting 1. Fix the hanger to the mounting location with four tapping screws (5X20). See the outline drawing on page D-1 for mounting dimensions. 2. Loosely screw knob bolts into the display unit. 3. Set the display unit to the hanger and tighten the knob bolts. 4- 7 229 0.5 75 0.5...
  • Page 10 Flush mounting If the thickness of the console is 11-14 mm, use the washer head screws (M4X20) supplied with the installation materials. If it is thicker than those dimensions, the length of the screws should be the thickness of the console plus 7.3 mm ±1.5 mm. The length of the threaded portion to be inserted to the display unit should not exceed 7 mm (B 7).

  • Page 11: Installation Of Antenna Unit

    1.2 Installation of Antenna Unit Refer to the antenna unit outline drawing at the back of this manual for mounting instructions. When selecting a mounting location consider the following points: Select a location out of the radar and Inmarsat beams. Those beams will obstruct or prevent reception of the GPS satellite signal.

  • Page 12: Installation Of Transducer

    1.3 Installation of Transducer Inside-hull mounting The thru-hull mount transducer (520-5PSD, 520-5MSD) may also be installed inside the hull, following the procedure below. Necessary tools You will need the following tools: Sandpaper (#100) Marine sealant Remarks on installation Turn off the engine and anchor the boat while installing the equipment. Install the transducer in the engine room.
  • Page 13 Attaching the transducer 1. Clean the transducer face to remove any foreign material. Lightly roughen the transducer face with #100 sandpaper. Also, roughen the inside of the hull where the transducer is to be mounted. 2. Warm the marine sealant to 40°C before usage to soften it. Coat the transducer face and mounting location with marine sealant.
  • Page 14 9. Press the [GAIN] key. GAIN 50 kHz HIGH TURN KNOB TO ADJUST GAIN. Gain setting window 10. Confirm that the gain setting is 5.0. 11. Push the knob. 12. Press the [RANGE] key. 13. Rotate the knob to set the range to 10 m. 14.
  • Page 15 Case 2 If the bottom is not displayed in reddish-brown, the transducer position is not suitable. Change the location of the transducer. Further, refer to the operator’s manual to apply echo offset in order to display the depth readout. To change location of transducer: 1.
  • Page 16 Unit: mm 520-5PSD 520-5MSD Thru-hull mount transducer mounting dimensions (millimeters) Acceptable transducer mounting locations DEEP-V HULL Position 1/2 to 1/3 of the hull from stern. 15 to 30 cm off center line (inside first lifting strakes.) HIGH SPEED-V HULL Within the wetted bottom area Deadrise angle within 15°...
  • Page 17 Procedure for installing the thru-hull mount transducer 1. With the boat hauled out of the water, mark the location chosen for mounting the transducer on the bottom of the hull. 2. If the hull is not level within 15° in any direction, fairing blocks made out of teak should be used between the transducer and hull, both inside and outside, to keep the transducer face parallel with the water line.

  • Page 18: Transom Mount Transducer

    Transom mount transducer The transom mount transducer (520-5PWD) is very commonly employed, usually on relatively small inboard/outboard or outboard boats. Do not use this method on an inboard motor boat because turbulence is created by the propeller ahead of the transducer. There are two methods of installation: flush with hull (for flat hulls) and projecting from hull (for deep V-hulls).
  • Page 19 Installing the transom mount transducer on a deep-V hull This method is employed on deep-V hulls and provides good performance because the effects of air bubbles are minimal. Install the transducer parallel with water surface; not flush with hull. If the boat is placed on a trailer care must be taken not to damage the transducer when the boat is hauled out of the water and put on the trailer.
  • Page 20 Triducer 525STID-MSD The optional triducer 525STID-MSD is designed for thru-hull mounting. For how to install this transducer see paragraph 4.2. φ79 mm 133 mm 2.00"-12 UN threads 7 mm φ51 mm 27 mm 140 mm Triducer 525STID-MSD 525STID-PWD ® The Transom Mount Transducer or TRIDUCER Multisensor with Integral Release Bracket 525STID-PWD is manufactured by AIRMAR Co.
  • Page 21 Drill bit for: Bracket holes: 4mm, #23, or 9/64” Fiberglass hull: chamfer bit (preferred), 6mm, or 1/4” Transom hole: 19mm or 3/4” (optional) Cable clamp holes: 3mm or 1/8” Screwdrivers Straight edge Marine sealant Pencil Zip-ties Water-based antifouling paint (mandatory in salt water). Mounting location To ensure the best performance, the sensor must be submerged in aeration-free and turbulence-free water.
  • Page 22 Installation of bracket 1. Cut out the installation template shown below. 2. At the selected location, position the template, so the arrow at the bottom is aligned with the bottom edge of the transom. Being sure the template is parallel to the waterline, tape it in place.
  • Page 23 5. Using the two #10 x 1-1/4” self-tapping screws, temporarily screw the bracket to the hull. DO NOT tighten the screws completely at this time. Follow the step 1-4 in “Attaching the Sensor to the Bracket”, before proceeding with “Adjusting”. Adjusting 1.
  • Page 24 5. Using the vertical adjustment space on the bracket slots, slide the sensor up or down to provide a projection of 3 mm (1/8”). Tighten the screws. Cable cover Cable clamp 50 mm (2") Hull projection 3 mm (1/8") Vertical adjustment and cable routing Attaching the sensor to the bracket 1.
  • Page 25 2. Route the cable over or through the transom. 3. On the outside of the hull secure the cable against the transom using the cable clamps. Position a cable clamp 50 mm(2”) above the bracket and mark the mounting hole with a pencil.

  • Page 26: Optional Speed/Water Temperature Sensor

    1.4 Optional Speed/Water Temperature Sensor Thru-hull type speed/water temperature sensor ST-02MSB, ST-02PSB 1. Dry-dock the boat. 2. Make a hole of approx. 51 mm diameter in the mounting location. 3. Unfasten locknut and remove the sensor section. 4. Apply high-grade sealant to the flange of the sensor. 5.

  • Page 27: Wiring

    2. WIRING ANTENNA UNIT GPA-017S/GPA-019S/ GPA-020S/GPA-021S TNC-PS/PS-3D-L15M-R, 15 m Display unit, rear view Power source The power source is a 12 or 24 VDC battery. Be sure the power cable is tightly fastened to the power source and the polarity (plus and minus) is correct. Connect the white lead to the positive terminal(+) and the black lead to the negative terminal(-).
  • Page 28 Transducer Connect the transducer to XDR port on the rear of the display unit. If the optional speed/water temperature sensor is connected, connect the transducer with the optional cable 02S4147 (Code No. 000-141-082). Connect to XDR port on display unit MJ-A10SPF Connection Cable Type: 02S4147...
  • Page 29 GP-3500F (D) MJ-A6SRMD MJ-A10SPF SHIELD TEMP TEMP TEMP0V TEMP0V Water Temp. TEMP0V/SHIELD Sensor +12V MJ-A10SRMD XDR+ XDR-SHIELD XDR- Transducer XDR+ XDR SHIELD XDR- Wiring for connection of water temperature sensor with cable 02S4147 GP-3500F (D) MJ-A6SRMD MJ-A10SPF SHIELD TEMP TEMP...
  • Page 30 Ground Connect the ground wire to the boat’s grounding bus. If the unit is not grounded noise may result. If noise is a problem on an FRP vessel, fasten a ground plate of 20 cm X 30 cm to the outside of the ship’s hull and connect the ground wire there. Use a closed-type lug ( ) for the connection on the display unit.
  • Page 31 Waterproofing the connector After connecting the antenna cable, wrap the connector with self-vulcanizing tape and then vinyl tape to waterproof it. Bind ends of vinyl tape with cable ties to prevent unraveling. How to waterproof the connector How to attach N-P-8DFB connector Inner Dimensions in millimeters.
  • Page 32 Optional transducer Installing one transducer To install one transducer among 50B-6, 50B-6G, 200B-5 or 200B-5S, use cable assy. 02S4089 (optional supply). Fabricate the transducer cable as shown below and connect it to the cable assy. (1 m). Crimp-on lug FVC1.25, red, 3 pcs. Vinyl sheath Vinyl sheath Shield...
  • Page 33 Installing two transducers To install two transducer among 50 kHz transducer 50B-6/50B-6G and 200 kHz transducer 200B-5/200B-5S, use cable assy. 02S4089 (code no. 000-133-622, optional supply). Fabricate the transducer cable as shown below and connect it to the Distributor MB-1000. Vinyl Sheath Crimp-on Lug FV1.25-3, Red...

  • Page 34: Adjustments

    3. ADJUSTMENTS 3.1 Display Settings Sensor calibration 1. Press the [MENU] key to open the menu. MENU 1. WAYPOINTS LIST 2. ROUTES LIST 3. MEMORY CARD OPERATIONS & DATA TRANSFER 4. MARKS/SHIP’S TRACKS SETUP 5. MARKS/SHIP’S TRACKS EDITION 6. ALARM SETUP 7.
  • Page 35 2. Press the [0] and [1] keys to show the DISPLAY SETUP menu. This menu has two pages. 0-1. DISPLAY SETUP NEXT PAGE LANGUAGE 1. ENGLISH KEY BEEP 1. ON 2. OFF SPEED SOURCE 1. INT GPS 2. NMEA SOG 3. NMEA STW NMEA SPEED CALIB +00% (-50-+50%)
  • Page 36 4. To offset speed data, rotate the knob to choose NMEA SPEED CALIB and then roll the trackball rightward or leftward as appropriate to display appropriate offset value. For example, if the actual speed is 10.0 kt and the displayed value is 11.0 kt, enter +10(%). 5.
  • Page 37 Ship and antenna characteristics 1. Display page 1 of the DISPLAY SETUP and then rotate the knob to choose NEXT PAGE. 0-1. DISPLAY SETUP PREVIOUS PAGE WAYPOINT STATUS 1. ON 2. OFF WAYPOINT INFO 1. ON 2. OFF MARK STATUS 1.

  • Page 38: Navigator Settings

    3.2 Navigator Settings If you are receiving position data from an external navigator, set up as follows: Navigator settings 1. Press the [MENU] key to display the menu. 2. Press the [0] and [2] keys to shown the NAVIGATOR SETUP menu. 0-2 NAVIGATOR SETUP SELECT NAV SOURCE .
  • Page 39 Antenna height The default antenna height (above the waterline) is 5 m. If the height of your antenna is different enter its height as follows: 1. At the NAVIGATOR SETUP menu, rotate the knob to choose ANTENNA HEIGHT 2. Enter height with the numeric keys. 3.

  • Page 40: I/O Port Settings

    3.3 I/O Port Settings NMEA1 and NMEA2 ports NMEA 1 and NMEA 2 ports are used to connect external navigation equipment such as an autopilot and radar. Set up the ports according to equipment connected. 1. Press the [MENU] key to open the menu. 2.
  • Page 41 4. Rotate the knob to choose TLL OUTPUT and then roll the trackball rightward or leftward to choose appropriate option. Choose ON to output the latitude and longitude of mark entered when a mark key is pressed. 5. Rotate the knob to choose L/L FORMAT and then roll the trackball rightward or leftward to choose appropriate option.
  • Page 42 8. Rotate the knob to place the cursor on the sentence to process. 9. Push the knob to display ON or OFF as appropriate. 10. Repeat steps 8 and 9 to process other sentences. 11. Press the [MENU] key several times to close the menu. I/O format Port I/O format...

  • Page 43: Sub Track Settings

    3.4 Sub Track Settings Sub track is the ship’s track drawn using the NMEA signal from external equipment. To display the sub track, set talker of external equipment as follows. 1. Press the [MENU] and [4] keys to show the MARK/SHIP’S TRACK SETUP menu. 4.
  • Page 44 4. MARKS/SHIP'S TRACKS SETUP PREVIOUS PAGE DISP TARGET TRACKS 1. ON 2. OFF TARGET TRACK COLOR TARGET TRACK STYLE DISP SUB TRACKS 1. ON 2. OFF SUB TRACKS COLOR SUB TRACK STYLE SUB TRACK TALKER 1. GP 2. II 3. IN 4.

  • Page 45: Echo Sounder Settings

    3.5 Echo Sounder Settings If the optional speed or speed/water temperature sensor is connected calibrate it as shown in the procedure below. 1. Press the [MENU] key. 2. Press the [0] and 8] keys to show the ECHO SOUNDER SYSTEM SETUP menu. 0-8.
  • Page 46 3. If the speed or water temperature readout is wrong, calibrate the speed or water temperature data input from the transducer or sensor. Enter a minus(-) or plus(+) value if the actual value is lower or higher than the displayed value, respectively. Also, if you desire depth from the sea surface rather than the transducer set ship’s draft.

  • Page 47: Setting Transducer Model, Output Power

    3.6 Setting Transducer Model, Output Power The GP-3500F (D) is preset to use a transducer having 600 W output power (520-5PSD, 520-5PWD, 520-5MSD). For 1 kW transducer, set a jumper block inside the display unit as shown in the procedure below.
  • Page 48 4. Unfasten 15 binding screws (M3X10) to detach the rear panel. These are marked with the stars in the illustration on the previous page. 5. Remove the ES board protective cover from the ES Board, disengaging it from the ES Board in the order shown in the illustration below.

  • Page 49: Connection Of External Monitor

    3.7 Connection of External Monitor Use the optional external monitor connection kit to connect a VGA monitor as a remote display. External Monitor Connection Kit Type: OP03-176, Code No.: 008-526-360 Name Type Code No. Remarks Cable Assy. 15SDS/XHP10-005 000-144-511 0.5 m, Mini D-sub 15P Grommet MG-4 000-871-378...
  • Page 50 Handling the Coaxial Cable • Wear gloves when touching the connector. • Use radio pincers to disconnect, and lift vertically. • Use radio pincers to connect, and insert vertically. • The allowable load on the cable is as shown in the drawing below. Less than 2.94N(300gf) Less than 9.8N(1kgf) Less than 2.94N(300gf)

  • Page 51: Appendix 1 Installation Of Temperature Sensors

    APPENDIX 1 INSTALLATION OF TEMPERATURE SENSORS The installation instructions in this chapter are copied from the manufacturer's (AIRMAR Technology Corporation) installation guide, which is included with your sensor. The model numbers mentioned within the documentation should be read as follows: T42 =>...
