Welcome to the family. Let's get started.
Mfg. Date - Serial Number
These numbers are located on the rating label of the grill.
CGT18G1A
Portable Charcoal Grill
Manual applies to the following model number(s)
MB20040722, MB20040822,
MB20040522, MB20040622
IMPORTANT
Please record this information immediately and keep in a safe
place for future use.
Master it. Masterbuilt.
Your model number
Manual Code : 9804210034 220124-GH
Advertisement
Table of Contents
Related Manuals for Masterbuilt CGT18G1A
Summary of Contents for Masterbuilt CGT18G1A
- Page 1 Mfg. Date - Serial Number Your model number These numbers are located on the rating label of the grill. IMPORTANT Please record this information immediately and keep in a safe place for future use. Manual Code : 9804210034 220124-GH Master it. Masterbuilt.
-
Page 2: Carbon Monoxide Hazard
• Never use grill for anything other than its intended use. This grill is NOT for commercial use. • Accessory attachments not supplied by Masterbuilt Manufacturing, LLC are NOT recommended and may cause injury. • Use of alcohol, prescription, or non-prescription drugs may impair user’s ability to properly assemble or safely operate grill. -
Page 3: Warnings And Important Safeguards
• Remove all printed labels from the grill. DO NOT RETURN TO RETAILER for assembly assistance, missing or damaged parts. Please contact MASTERBUILT Customer Service at www.masterbuilt.com/pages/support. Please have STOP the model number and serial number available. These numbers are located on the silver rating... -
Page 4: Parts Diagram
Parts Diagram Parts List QTY. QTY. DESCRIPTION DESCRIPTION Temperature Gauge Lid Handle Liner Lid Handle Bezel Charcoal Grate Lid Handle Grease Tent Charcoal Hopper Lid Cooking Grate Charcoal Hopper Handles (MODELS MB20040522 and MB20040622) Manifold Right Shelf Body Liner Metal Shelf Support Rear Left Shelf Metal Shelf Support Front Mica Gaskets... - Page 5 Hardware M6x15 Phillips Screw Qty - 10 M4x10 Phillips Screw Qty - 4 Mica Plat Qty - 4 M12 Nut Qty - 2 M12 Flat Gasket Qty - 2 Wrench Qty - 1 QTY. DESCRIPTION TOOL REQUIRED M6x15 Screw M4x10 Screw Mica Plat M12 Nut M12 Flat Gasket...
- Page 6 Assembly MODELS WITH NO CART MB20040522, MB20040622...
- Page 7 Assembly Press Down Unlock Instructions for raising and lowering the cart are located on page 14.
- Page 8 Assembly...
- Page 9 Assembly Install Grease Tent First...
- Page 10 Assembly...
- Page 11 Assembly Operating Instructions ASSEMBLY IS DONE. LET’S HAVE SOME FUN! PRE-SEASONING Pre-seasoning will rid your grill of chemicals and oils left over by the manufacturing process, allowing them to burn off. PRE-SEASON GRILL PRIOR TO FIRST USE. 1. Start grill following the START-UP instructions and set the temperature to medium. 2.
- Page 12 Operating Instructions START-UP 1. Open charcoal hopper. 2. Place fire starter in fire starter slot under the charcoal grate. Replace the charcoal grate and light the firestarter. • Use a food safe fire starter block or twisted paper towel/paper. • Use caution and wear protective gloves. •...
-
Page 13: Control Panel
Operating Instructions REGULATING TEMPERATURE CONTROL PANEL IN YOUR GRILL: Your grill has a temp probe located under the cooking grate that will regulate the grill temp based on the position of the control knob. Knob positon in relation to the grill temperature will vary based on outside temperature, amount of food and charcoal type used. - Page 14 Operating Instructions CART RAISING AND LOWERING THE CART PRESS HERE TO RELEASE LATCH From the lower position: 1. Place foot on the bottom leg. 2. Release the latch 3. Using the side shelf, pull the grill up. 4. Raise the top leg in the lock position. Note: Do not remove foot from bottom leg until grill is fully locked in the raised position.
-
Page 15: Troubleshooting
Troubleshooting PROBLEM REASONS SOLUTIONS Grill is not getting up to Charcoal is not lit. Check the charcoal, re-run temperature. lighting procedure. Charcoal low. Add charcoal to keep the temperature up. Ash buildup in the charcoal hopper and Cleanout old ash from both the hopper and manifold. - Page 16 Rest assured, we’re here to help. Customer Service masterbuilt.com/contact-us masterbuilt.com/warranty masterbuilt.com/collections/parts @masterbuilt masterbuilt.com...
