Masterbuilt CGP24G1D Instruction Sheet

Gravity fed grill

Grill Body Instruction Sheet

Gravity Fed Grill CGP24G1D

CAUTION

• Always remove plug from outlet before servicing your grill.

• Make sure your grill has fully cooled to avoid burns.

• Some components may have sharp edges. Use caution to avoid injury.

Remove: grates/griddle, warming racks, manifold, charcoal from hopper, ash grate, ash can,

grease tray, slides, hopper ash door, any other accessories on the grill.

Disassembly

4 SCREWS

2 SCREWS

Remove the manifold support bracket (2 screws)

Remove front folding shelf (4 screws)

9804190243 210730-GH

Table of Contents

Do you have a question about the CGP24G1D and is the answer not in the manual?

Page 1 Grill Body Instruction Sheet Gravity Fed Grill CGP24G1D CAUTION • Always remove plug from outlet before servicing your grill. • Make sure your grill has fully cooled to avoid burns. • Some components may have sharp edges. Use caution to avoid injury.
Page 2 Disassembly 4 SCREWS Unplug wires from the controller. Remove side shelf (4 screws) SCREWS SCREWS 2 SCREWS Remove hopper lid (2 screws) Remove hopper latch (4 screws) SCREWS SCREWS 4 SCREWS SCREWS Remove shroud (7 screws) Remove shroud (7 screws)
Page 3 Disassembly SCREWS SCREWS SCREWS Remove shroud (7 screws) Unplug the wiring harness. 4 SCREWS 2 SCREWS Remove hopper (6 screws). Pull the hopper off Pull the hopper wires through the leg brace hole. the body and set to the side. SCREWS Remove 6 screws from the legs.
Page 4 10. Replace the manifold support bracket using 2 screws (2) (see step 1). 11. Replace: grates/griddle, warming racks, manifold, charcoal from hopper, ash grate, ash can, grease tray, slides, hopper ash door, any other accessories on the grill. masterbuilt.com @masterbuilt Customer Service: masterbuilt.com/contact-us • masterbuilt.com/warranty • masterbuilt.com/collections/parts...
