8. Painting/marking and Final assembly/setting
See video guide Decals
Another advantage of Polylight LW-PLA is that it can be dyed with almost anything. The
surface for self-adhesive decals is ideally treated with a clear acrylic spray varnish. Use your
imagination and send us photos of your aircraft on social networks.
See video guide Final setting
Refer to your R/C system userguide for setup information.
you will need: Your own Rx/Tx system
Velcro strip & Rubber Bands (for wing)
Install your reciever, connect battery, setup servos and etc. with your trasmitter, check servo
position, then install propeller.
Make sure the battery is positioned properly and secured with velcro or battery holder, if
battery moves during flight it can shift the center of gravity backwards and aircraft will
become uncontrollable! Never set ESC with propeller installed, this could be very dangerous!
aileron
9. Go flying
Pre-flight check center of gravity is very important
battery properly charged, ailerons and elevator deflection check, your own flying skills or RC
simulator training ...
Flight video of Piper J-3 Cub
... print your plane | www.3DLabPrint.com
elevator
+15mm
-12mm
page
rudder
+15mm
-15mm
(move it 5mm forward for the first flights),
21
L 20mm
R 20mm
