VOSS IES980RF User Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
IES980RF
USER
MANUAL
EN
User Manual
Steam oven

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the IES980RF and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for VOSS IES980RF

Summary of Contents for VOSS IES980RF

  • Page 1 IES980RF User Manual Steam oven USER MANUAL...

  • Page 2: Table Of Contents

    16. ENVIRONMENTAL CONCERNS................39 DEAR CUSTOMER Thank you for choosing this Voss-Electrolux product. We have created it to give you impeccable performance for many years, with innovative technologies that help make life simpler – features you might not find on ordinary appliances. Please spend a few minutes reading to get the very best from it.

  • Page 3: Safety Information

    ENGLISH SAFETY INFORMATION Before the installation and use of the appliance, carefully read the supplied instructions. The manufacturer is not responsible for any injuries or damage that are the result of incorrect installation or usage. Always keep the instructions in a safe and accessible location for future reference.

  • Page 4: Safety Instructions

    Disconnect the appliance from the power supply • before carrying out any maintenance. If the mains power supply cable is damaged, it must • be replaced by the manufacturer, its Authorised Service Centre or similarly qualified persons to avoid an electrical hazard.
  • Page 5 ENGLISH • The appliance is equipped with an electrical ratings of the mains power electric cooling system. It must be supply. operated with the electric power • Always use a correctly installed supply. shockproof socket. • Do not use multi-plug adapters and extension cables.
  • Page 6 – do not put ovenware or other objects in the appliance directly Total power (W) Section of the ca‐ on the bottom. ble (mm²) – do not put aluminium foil directly on the bottom of cavity of the maximum 1380 3 x 0.75...
  • Page 7 ENGLISH • Clean regularly the appliance to operation to a well ventilated prevent the deterioration of the area. surface material. • Small pets can also be highly • Clean the appliance with a moist soft sensitive to the localized temperature cloth.

  • Page 8: Installation

    2.8 Service • Disconnect the appliance from the mains supply. • To repair the appliance contact the • Cut off the mains electrical cable Authorised Service Centre. close to the appliance and dispose of • Use original spare parts only.
  • Page 9 ENGLISH (*mm) min. 550 min. 560 3.2 Securing the oven to the cabinet...

  • Page 10: Product Description

    4. PRODUCT DESCRIPTION 4.1 General overview Control panel Electronic programmer Water drawer Socket for the food sensor Heating element Lamp Shelf support, removable Draining pipe Water outlet valve Shelf positions Steam inlet 4.2 Accessories • Food sensor To measure how far the food is •...
  • Page 11 ENGLISH Sensor Function Comment field ON / OFF To turn the oven on and off. Heating Functions Press the sensor field once to choose a heating or Assisted Cook‐ function or the menu: Assisted Cooking. Press the sensor field again to switch between the menus: Heating Functions, Assisted Cooking.

  • Page 12: Before First Use

    Other indicators of the display: Symbol Function Minute Minder The function works. Time of day The display shows the current time. Duration The display shows the necessary time for cooking. End Time The display shows when the cooking time is complete.

  • Page 13: Daily Use

    ENGLISH 6.3 Initial preheating Preheat the empty oven before the first use. Step 1 Remove all accessories and removable shelf supports from the oven. Step 2 Set the maximum temperature for the function: Let the oven operate for 1 h. Step 3 Set the maximum temperature for the function: Let the oven operate for 15 min.
  • Page 14 CAUTION! The oven is hot. There is a risk of burns. Be careful when you empty the water tank. 9. After steam cooking steam can condensate on the bottom of the cavity. Always dry the bottom of the cavity when the oven is cool.
  • Page 15 ENGLISH 7.9 Residual heat Submenu for: Basic Settings Symbol / Menu Description When you turn off the oven, the display shows the residual heat. You can use the item heat to keep the food warm. Sets the current time on the clock. 7.10 The menus in overview Set Time of Day Main menu...
  • Page 16 Symbol / Menu Description Heating func‐ Application item tion Reminds you when to To bake and roast food clean the appliance. on one shelf position. Cleaning Re‐ minder Conventional Cooking Activation / deactiva‐ tion code: 2468. To make convenience DEMO mode food (e.g., french fries,...
  • Page 17 ENGLISH Heating func‐ Application Heating func‐ Application tion tion Food reheating with Use this function to steam prevents surface prepare bread and drying. Heat is distrib‐ bread rolls with profes‐ Steam Regener‐ Bread Baking uted in a gentle and sional-like result in ating even way, which allows terms of crispiness,...
  • Page 18 7.14 Assisted Cooking Dish Food Category: Fish / Seafood Rare Dish Fish Fish, baked Scandinavian beef Medium Fish fingers Well done Fish fillet, frozen Spare ribs Whole small fish, Pork knuckle, pre- grilled cooked Whole fish, grilled Pork joint...
  • Page 19 ENGLISH Dish Dish Sweet dishes Pastry strips Cream puffs Food Category: Pizza / Quiche Puff pastry Dish Eclairs Pizza, thin Macaroons Pizza, extra topping Short pastry biscuits - Pizza, frozen Christmas stollen Pizza American, fro‐ Pizza Apple strudel, fro‐ Pizza, chilled Sponge dough Pizza snacks, fro‐...

  • Page 20: Clock Functions

    Dish Dish Bread crown French fries, frozen Bread Yeast plait Croquettes Unleavened bread Wedges Hash browns Food Category: Side dishes Dish When it is necessary to change the weight or the French fries, thin core temperature of the dish,...

  • Page 21: Automatic Programmes

    ENGLISH 8.4 Time Extension 1. When the cooking time ends, a signal sounds. Press any symbol. The function: Time Extension makes the The display shows the message. heating function continue after the end of 2. Press to turn on or to cancel.
  • Page 22 2. Put the plug of the food sensor into and the operating modes. The oven the socket at the top of the cavity. calculates the end time in approximately 30 minutes. 6. To change the core temperature, press When the meat is at the set core temperature, the signal sounds.
  • Page 23 ENGLISH Wireshelf, Baking tray / Deep pan: Push the tray between the guide bars of the shelf support and the wire shelf on the guide bars above. 10.3 Using telescopic runners Make sure you push back the telescopic runners fully in the oven before you close Do not oil the telescopic runners.
  • Page 24 Glass bowl (A) Lid (B) Injector, injector tube, and a steel grill. Injector tube (C) is for steam cooking, injec‐ tor (D) is for direct steam cooking. Steel grill (E) • Do not put the hot baking dish on •...

  • Page 25: Additional Functions

    ENGLISH 10.6 Direct steam cooking Put the baking dish on the steel grill. Add some water. Do not use the lid. WARNING! The injector may be hot when oven operates. Always use oven gloves. Remove the injector from the oven when you do not use steam function. Step 1 Connect injector with injector tube.
  • Page 26 2. Press at the same time until the display shows a message . • Function Lock is on when To turn off the Child Lock function repeat the heating function step 2. works. • The menu: Basic Settings 11.3 Function Lock lets you turn the function: Set + Go on and off.

  • Page 27: Hints And Tips

    ENGLISH 11.7 Cooling fan It is on when the When the oven operates, the cooling fan oven is turned on. turns on automatically to keep the surfaces of the oven cool. If you turn off It is on for 10 sec the oven, the cooling fan can continue to when you touch any operate until the oven cools down.
  • Page 28 Ramekins Pizza pan Baking dish Flan base tin Ceramic Dark, non-reflective Dark, non-reflective Dark, non-reflective 8 cm diameter, 28 cm diameter 26 cm diameter 28 cm diameter 5 cm height 12.3 Moist Fan Baking For the best results follow suggestions listed in the table below.
  • Page 29 ENGLISH (°C) (min) Shashlik, 0.5 kg baking tray or dripping 25 - 30 Cookies, 16 baking tray or dripping 20 - 30 pieces Macaroons, 24 baking tray or dripping 25 - 35 pieces Muffins, 12 baking tray or dripping 30 - 40 pieces Savory pastry, 20 baking tray or dripping...
  • Page 30 (°C) (min) Small True Fan Baking 2 and 4 150 - 160 20 - 35 cakes, Cooking tray 20 per tray Apple Conven‐ Wire shelf 2 70 - 90 pie, 2 tional tins Ø20 Cooking Apple True Fan Wire shelf 2...

  • Page 31: Care And Cleaning

    ENGLISH (°C) (min) Beef bur‐ Grill Wire shelf max. 20 - 30 Put the wire shelf ger, 6 and drip‐ on the fourth level pieces, ping pan and the dripping 0.6 kg pan on the third level of the oven. Turn the food halfway through the cooking time.
  • Page 32 Step 1 Turn off the oven and wait un‐ til it is cold. Step 2 Pull the front of the shelf sup‐ port away from the side wall. Step 3 Pull the rear end of the shelf support away from the side wall and remove it.
  • Page 33 ENGLISH When the cleaning ends: Turn off the oven and Clean the cavity with a soft Remove the residue from the wait until it is cold. cloth. bottom of the cavity. 13.4 How to clean: Water tank Step 1 Turn off the oven. Step 2 Place a deep pan below the steam inlet.
  • Page 34 13.5 How to remove and install: Door The oven door has three glass panels. You can remove the oven door and the internal glass panels to clean them. Read the whole "Removing and installing door" instruction before you remove the glass panels.
  • Page 35 ENGLISH Step 8 Clean the glass panels with water and soap. Dry the glass panels carefully. Do not clean the glass panels in the dishwasher. Step 9 After cleaning, install the glass panels and the oven door. Make sure that you put the glass panels (A and B) back in the correct sequence.

  • Page 36: Troubleshooting

    Step 2 Clean the glass cover. Step 3 Replace the lamp with a suitable 300 °C heat-resistant lamp. Step 4 Install the glass cover. 14. TROUBLESHOOTING WARNING! Refer to Safety chapters. 14.1 What to do if... Problem Possible cause Remedy You cannot activate or oper‐...

  • Page 37: Energy Efficiency

    Do not remove the rating plate from the oven cavity. We recommend that you write the data here: Model (MOD.) ......... Product number (PNC) ......... Serial number (S.N.) ......... 15. ENERGY EFFICIENCY 15.1 Product Information and Product Information Sheet* Supplier's name Voss...
  • Page 38 Model identification IES980RF 949494719 Energy Efficiency Index 81.2 Energy efficiency class Energy consumption with a standard load, conven‐ 0.93 kWh/cycle tional mode Energy consumption with a standard load, fan-forced 0.69 kWh/cycle mode Number of cavities Heat source Electricity Volume...

  • Page 39: Environmental Concerns

    ENGLISH Cooking with the lamp off When you use this function the lamp Turn off the lamp during cooking. Turn it automatically turns off after 30 sec. You on only when you need it. may turn on the lamp again but this action will reduce the expected energy Moist Fan Baking savings.
  • Page 40 www.voss.dk...
