Digital input pins
Pin Name
40 SGND
41 DIN1 / S0IN1
42 DIN2 / S0IN2
43 DIN3 / S0IN3
44 DIN4 / S0IN4
45 DIN5 / IGN
46 DIN6
47 DIN7
48 DIN8
49 SGND
Specification for each digital input:
Logic "High"
Logic "Low"
Bandwidth
Input impedance
Description
Signal ground
S0 input 1
Digital input 1
S0 input 2
Digital input 2
S0 input 3
Digital input 3
S0 input 4
Digital input 4
Digital input 5
Digital input 6
Digital input 7
Digital input 8
Signal Ground
Min. Typ. Max.
8 12 40
-5 - 3
- -
20
- 14 -
Jumper Settings
Row 1, Position S
Row 1, Position N (default)
Row 2, Position S
Row 2, Position N (default)
Row 3, Position S
Row 3, Position N (default)
Row 4, Position S
Row 4, Position N (default)
Unit
VDC Protected against transients and
VDC low-pass filtered
kHz @ 12 VDC input voltage level
kΩ In "normal digital input"-mode
