M2M Control CX320 Technical Manual V1.01

Digital outputs

The digital outputs control eight "high-side" switches. They function like contacts, where one side is
connected to the positive supply of the CX320 unit, and the other side is to the output. The switches
are protected against short circuits, ESD, and electronic kickback from inductive loads such as a relay.
The maximum switchable inductance is 20mH and must not be exceeded.
The digital output control circuit is supplied from the power supply connected to the DOUT SUPP
and DOUT GND. The DOUT GND is connected with the system GND internally
The CX320 unit offers advanced power management that can enable one or more outputs while the
device is in low power mode. Please consult the M2M Control IDE documentation for additional
information.
Digital output pins
Pin Name
30 DOUT SUPP
31 DOUT 1
32 DOUT 2
33 DOUT 3
34 DOUT 4
35 DOUT 5
36 DOUT 6
37 DOUT 7
38 DOUT 8
39 DOUT GND
Specification for each digital output
Type Min.
0
Push/Pull
-
-
Description
Digital output supply, positive (+) connector
Digital output 1
Digital output 2
Digital output 3
Digital output 4
Digital output 5
Digital output 6
Digital output 7
Digital output 8
Digital output ground, negative (-) connector
Max. Unit
36 VDC Short-circuit, Overload, Overvoltage, and ESD protected
1.5 A
140 mΩ On-state resistor per channel
Page 17 of 42
