SPECIFICATIONS
7.4

Semiconductor Fuses

Semiconductor fuses can be used with CSX soft starters to reduce the potential for damage to SCRs from
transient overload currents and for Type 2 coordination. CSX soft starters have been tested to achieve Type
2 coordination with semiconductor fuses. Suitable Bussman and Ferraz semiconductor fuses are detailed
below.
SCR I
CSX Model
007
015
018 10500
022 15000
030 18000
037 51200
045 80000
055 97000
075 168000
090 245000
110 320000
Page 10
Ferraz Fuse
2
T
European/IEC Style
(A 2 S)
(North American Style)
6.6URD30xxxA0063
1150
(A070URD30xxx0063)
6.6URD30xxxA0125
8000
(A070URD30xxx0125)
6.6URD30xxxA0160
(A070URD30xxx0160)
6.6URD30xxxA0160
(A070URD30xxx0160)
6.6URD30xxxA0160
(A070URD30xxx0160)
6.6URD30xxxA0250
(A070URD30xxx0250)
6.6URD30xxxA0315
(A070URD30xxx0315)
6.6URD30xxxA0315
(A070URD30xxx0315)
6.6URD31xxxA0450
(A070URD31xxx0450)
6.6URD31xxxA0450
(A070URD31xxx0450)
6.6URD31xxxA0450
(A070URD31xxx0450)
xxx = Blade Type. Contact Ferraz for options.
Bussmann Fuse
Square Body
(170M)
170M-1314
170M-1317
170M-1318
170M-1318
170M-1319
170M-1321
170M-1321
170M-1321
170M-1322
170M-3022
170M-3022
CSX
Bussmann Fuse
British Style (BS88)
63 FE
160 FEE
160 FEE
180 FM
180 FM
250 FM
250 FM
250 FM
500 FMM
500 FMM
500 FMM
710-02407-00G
