The AES-2000 Accessible Entry System provides both audio and
visual instructional assistance for those with varying disabilities.
The large 1/2" high LCD is back-lit and will display a directory of
tenants as well as directions and prompts.
recorder and announcer can also provide a supporting audio
message. When the EZ™ Access button is pressed, instructions
on how to use the system are both displayed and announced.
The built in directory can support up to 525 tenant names and
phone numbers and will dial a
Flush Mount
A
p
p
l
A
p
p
l
• High rise apartment buildings
• Condos
• Senior citizen buildings
• Assisted care centers
• Retirement homes
• Gated communities
S
p
e
c
S
p
e
c
Power: 120V AC/13.8V AC 1.25A, UL listed adapter provided
Dimensions: AES-2000S (Surface mount): 317.5mm x
247.6mm x 107.9mm (12.5" x 9.75" x 4.25"), AES-2000F (Flush
mount): 381mm x 317.5mm x 88.9mm (15" x 12.5" x 3.5")
Shipping Weight: 0.0 kg (0 lb)
Environmental: -26° C to 54° C (-15° F to 130° F) with 5% to
95% non-condensing humidity
Display: 16 position, 0.5" x 4.25" back-lit LCD
Relay Contacts: 5A @ 30V DC/250V AC max.
Connections: (1) 4 position terminal block, RJ-11
AES-2000
AES-2000
Accessible Entry
t
i
c
e
t
i
c
e
August 14, 2001
