  • Page 1 MITSUBISHI AUTO-SCANNING WITH DIGITAL CONTROL COLOR DISPLAY MONITOR NFJ9905SKHUW MODEL USER’S GUIDE For future reference, record the serial number of your display monitor in the space below: SERIAL No. The serial number is located on the rear cover of the monitor.
  • Page 2 The power cord provided with this monitor is designed for safety and must be used with a properly grounded outlet to avoid possible electrical shock. Do not remove the monitor cabinet as this can expose you to very high voltages and other hazards. ANMERKUNG: Dieser Monitor erfüllt die Anforderungen der deutschen Ergonomie-Norm ZH1/ 618/10.80 bei Verwendung der beiden folgenden Timing:...
  • Page 3 RADIO INTERFERENCE REGULATIONS STATEMENT FOR U.S.A. This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications.
  • Page 4 Congraturations! You have just purchased a TCO ‘95 approved and labelled product! Your choice has provided you with a product developed for professional use. Your purchase has also contributed to reducing the burden on the environment and to the further development of environmentally- adapted electronic products.
  • Page 5 In and after the middle of this page, you will find a brief summary of the environmental requirements met by this product. The complete environmental criteria document may be ordered from: TCO Development Unit S-114 94 Stockholm Sweden Fax: +46 8 782 92 07 E-mail (Internet): development @tco.se Current information regarding TCO’95 approved and labelled products may also be obtained via the Internet, using the address:...

  • Page 6: Table Of Contents

    User’s Guide CONTENTS 1. INTRODUCTION ... 6 1.1 Features ... 6 1.2 Internal Preset Memory Capability ... 7 1.3 Power Management Function ... 7 1.4 DDC ... 8 1.5 Location Considerations ... 8 1.6 Cleaning Your Monitor ... 8 1.7 Unpacking ... 9 1.8 Tilt/Swivel Base ...

  • Page 7: Introduction

    INTRODUCTION Congratulations on your purchase of the high resolution color monitor. We designed this monitor to provide you with years of reliable trouble-free operation. This guide tells you how to connect, adjust and care for your monitor. This guide also provides technical specifications and instructions for troubleshooting any basic problems you may experience with your monitor.

  • Page 8: Internal Preset Memory Capability

    Internal Preset Memory Capability To minimize adjustment needs, the factory has preset popular display standards into the monitor, as shown in Table 1. If any of these display standards are detected, the picture size and position are automatically adjusted. All of the factory presets may be overwritten by adjusting the user controls. The monitor is capable of automatically storing up to six additional display standards.

  • Page 9: Ddc

    The monitor includes the DDC 1 and DDC nication channel over which the monitor automatically informs the host system about its capabilities (e.g. each supported resolution with its corresponding timing). DDC is routed through previously unused pins of the 15-pin VGA connector. The system will perform “Plug and Play”...

  • Page 10: Unpacking

    Unpacking After you unpack the box you should have all of the items indicated in Figure 1. Save the box and packing materials in case you ship or transport the monitor. Complete and mail in warranty cards. Tilt/Swivel Base The monitor comes with a tilt/swivel base. This enables you to position the monitor to the best angle and tilt for maximum viewing comfort.

  • Page 11: Quick Operation Chart

    1.9 Quick Operation Chart To summarize the steps in connecting your computer with the color monitor and setting the necessary controls and switches, refer to the chart below. Connect the color monitor and computer with the necessary cords and cables. Turn on the computer.

  • Page 12: Part Name

    PART NAME Control Names See Figures 3 and 4 for the location of the user controls, indicator and connectors. Each part is identified by number and is described individually. 7. DOWNSTREAM PORT 3. INPUT CONNECTOR SELECT BUTTON 6. FUNCTION ADJUST BUTTONS BNC / D-SUB 4.
  • Page 13 REAR AC POWER CONNECTOR 8. UPSTREAM PORT 9. DOWNSTREAM PORT UPSTREAM PORT: To connect to USB equipped computer(s). DOWNSTREAM PORT: To connect to USB equipped peripherals, e.g, USB camera, keyboard, printer, etc. D-SUB COMP. SIGNAL INPUT CONNECTOR (DB9-15P) D-SUB SIGNAL INPUT CONNECTOR (BNC) Figure 4 - 1-12 - COMP.

  • Page 14: Installation And Connection

    INSTALLATION AND CONNECTION On the back of the monitor four kinds of plug-in connections are provided: AC power connector for the AC input, DB9-15P connector and BNC connector for video signal input and USB ports for USB communication. AC Power Connection One end of the AC power cord is connected into the AC power connector on the back of the monitor.

  • Page 15: Connecting To An Apple Macintosh Computer

    3.2.2 Connecting to An Apple Macintosh Computer Figure 6 shows the SC-B102 cable and AD-A205 Adapter to the video port in an Apple Macintosh. Power off, both the monitor and the computer. Set the DIP switches of Macintosh Adapter according to the setting chart. (See 7.3 Macintosh Adapter AD-A205 settings) Connect the 15-pin (DB-15P) end of the AD-A205 Adapter to the straight 15-pin connector on the Macintosh video port on the CPU or on the video board.

  • Page 16: Bnc Connection

    3.2.4 BNC Connection (1) IN CASE OF A COMPOSITE SYNC ON GREEN VIDEO SIGNAL (SYNC ON GREEN): Connect the R, G and B video signals to the BNC receptacles on the back of the monitor. (2) IN CASE OF EXTERNAL COMPOSITE SYNC SIGNAL: Connect the R, G and B video signals and the Composite sync signal to BNC receptacles on rear panel, respectively.

  • Page 17: Usb System Basic Application

    USB System Basic Application Upstream Ports Downstream Port Downstream Ports Scanner Keyboard N O T E The computer is required to have Windows 98 installed and USB functions. When connecting one computer, either Upstream port A or B is available. The Upstream port with that the computer is connected is detected automatically.
  • Page 18 CAUTION Use the included ferrite core with the USB cable which is connected to the USB connectors (Downstream) to reduce the possibility of causing interference to radio, television, and other electrical devices. USB CONNCTOR (DOWNSTREAM) USB CABLE FERRITE CORE HOW TO MOUNT THE FERRITE CORE Place the included ferrite core under the USB cable at approx.

  • Page 19: Installation Of Usb Function

    Installation of USB Function Power on the display monitor and computer. Enumerate Mitsubishi USB HUB using the following procedure. N O T E During the enumeration of Mitsubishi USB Hub, con- nect the keyboard and mouse equipped with USB function, to the computer and not to the downstream ports on the display monitor.
  • Page 20 Enumerate the Mitsubishi Monitor Function using the following procedure. (1) Insert Windows 98 CD-ROM into your computer. Then, Figure 11 will ap- pear. (2) Click “Next” on Figure 11 and Figure 12 will appear. (3) Click “Next” on Figure 12 and Figure 13 will appear.
  • Page 21 (4) Click “CD-ROM Drive(C)” and “(L)”, and click “Next”. Figure 14 will appear. (5) Click “Finish” on Figure 14 and Figure 15 will appear. Click “OK” on Figure 15 to complete Enumeration of Mitsubishi Moni- tor Function. You can confirm that Enumeration of Mitsubishi Monitor Function is successfull with the follow- ing method.
  • Page 22 Install “USB Monitor Control Software” into computer using the following procedure. (1) Install “SETUP.EXE” after inserting the included floppy disk in computer. CAUTION Close all Windows programs before running this Setup program. (2) Click “Next” to continue with the Setup program.
  • Page 23 You can confirm that the Setup program is successfully installed, with the following method Confirm that “Mitsubishi USB Moni- tor Console Application” is listed in the property of “Application Add/ Remove” under “Control Panel”. Confirm that “USB Monitor” tab is added in “Display”...
  • Page 24 N O T E The following should be observed in order to use the USB function reliably. • Make sure all connections are made firmly and correctly. • Make sure the operation of the devices connected to the downstream ports before changing USB Upstream ports.

  • Page 25: Osd(On Screen Display) Functions

    OSD(On Screen Display) FUNCTIONS How to adjust the screen The monitor has an OSD(On Screen Display) func- tion. The following procedure shows how to adjust the screen with using the OSD function. Turn on the monitor. SCROLL Press any button ( display the OSD screen.
  • Page 26 Fix the item icon by pressing the proceed ENTER button marks are blinking when fixed. ENTER BNC / D-SUB SCROLL Adjust by pressing BNC / D-SUB SCROLL ENTER To select another item, press once again. The fixed condition will be cancelled.

  • Page 27: Adjustment Items

    Adjustment Items Items CONTRAST Adjusts to the desired contrast level. BRIGHT Adjusts to the black level of the screen COLOR TEMPERATURE Adjusts the color temperature of the screen image. H-SIZE Adjusts the horizontal size of the image on the screen. H-PHASE Adjusts the horizontal position of the image on the screen.
  • Page 28 Item Group Item Icon Icon CONTRAST BRIGHT COLOR TEMPERATURE H-SIZE H-PHASE V-SIZE V-POSITION PCC-AMP PCC-PHASE PCC-CENTER TOP-PCC BOTTOM-PCC PIN-BALANCE KEY-BALANCE TOP-BALANCE ROTATION GEOMETRY RESET Press the Minus Button: Press the Plus Button: To decrease the contrast. To increase the contrast. To decrease the brightness.
  • Page 29 Item Group Item Icon Icon H-STATIC V-STATIC MOIRE CANCEL LEVEL CORNER PURITY (TL) CORNER PURITY (TR) CORNER PURITY (BL) CORNER PURITY (BR) CLAMP PULSE POSITION VIDEO LEVEL DEGAUSS POWER-SAVE CONTROL LOCK OSD POSITION DIAGNOSIS LANGUAGE N O T E CONTROL LOCK: This is to lock the OSD function to keep the OSD screen image you set.
  • Page 30 Item Group Item Icon Icon USB UP-STREAM USB PORT COMBINATION Press the Plus Button: Press the Minus Button: The USB functions of the The USB functions of the computer connected to computer connected to Upstream port ROOT-A Upstream port ROOT-B become active.

  • Page 31: Usb Monitor Control

    USB Monitor Control You can do monitor screen adjustments from your computer through the USB function equipped to the monitor, with the following procedure. (1) Open “display” in “control panel” to get “display property”. Select “USB monitor” tab. (2) Click the adjustment item and adjust with the horizontal and/or vertical slide bar. Adjustment Item To select a back- ground pattern for...
  • Page 32 USB Monitor Control Adjustement Items and Functions HORIZONTAL SLIDE BAR ADJUSTMENT ITEM Adjusts to the black level of the Brightness screen. Adjusts to the desired contrast Contrast level. Controls the horizontal size of Size the image. Controls the horizontal position Position of the image.

  • Page 33: Troubleshooting

    TROUBLESHOOTING Before calling your Authorized Product Support, please check that the items below are properly connected or set. In case of using a non-standard signal, please check the pin assignments and the signal timing of your computer with the specification outlined in 6. SPECIFICATION and 7. APPENDIX. PROBLEM •...
  • Page 34 PROBLEM • [Universal serial bus controller] is not listed in [Device Manager]. • [Mitsubishi USB HUB] (or [Generic USB HUB]) is not listed in [Device Manager]. No operation of the USB devices • On the OSD screen, the Upstream port to which the USB device you want to use is connected is not colored by blue.
  • Page 35 PROBLEM • Thin vertical black lines on one or both sides of Black vertical the screen. This minor condition is caused by lines are grille element overlap which can occur during visible on the shipping. We suggest slapping the cabinet sides screen.

  • Page 36: Specifications

    SPECIFICATIONS Size Mask type Deflection angle Phosphors Aperture grille pitch Face Plate Focusing method INPUT SIGNAL Video Sync SIGNAL INTERFACE Input Connector Input Impedance Function Interface SCANNING Horizontal FREQUENCY Vertical RESOLUTION (HxV) 1600dots x 1200lines Non-Interlaced maximum addressable resolution format at 75Hz WARM-UP TIME 30 minutes to reach optimum performance level BRIGHTNESS...

  • Page 37: Appendix

    APPENDIX Monitor Signal Input Connector (DB9-15P) (Female) DB9-15P MOUNTED ON THE REAR PANEL DDC ... DISPLAY DATA CHANNEL SDA ... SERIAL DATA SCL ... SERIAL CLOCK NC ... NO-CONNECTION SC-B102 Signal Cable Approx. 1.8m DB9-15P(Male) DB9-15P(Male) PIN ASSIGNMENTS Pin No. or COMPOSITE SYNC with GREEN VIDEO VERTICAL SYNC(VCLK) PIN ASSIGNMENTS...

  • Page 38: Macintosh Adapter Ad-A205 Settings

    Macintosh Adapter AD-A205 settings The AD-A205 Macintosh Adapter allows you to take an advantage of the built in video capabilities of your Macintosh computer with the monitor. Set the dip switches of the adapter, before connect to the computer. Set the dip switches according to the following chart. By using the following chart, you can choose a main resolution, quickly.
  • Page 39 - 1-38 -...
